The Handy THLCHCM Instruction Manual

Electric horizontal cement mixer
Hide thumbs Also See for THLCHCM:
Table of Contents

Advertisement

Quick Links

Download this manual
LIGHT CONSTRUCTION
INSTRUCTION MANUAL
ELECTRIC HORIZONTAL
CEMENT MIXER
MODEL NO: THLCHCM -- PRODUCT NO: 193821002
EN - ORIGINAL INSTRUCTIONS
TWO PERSON LIFT - ASSEMBLY REQUIRED
SAVE THESE INSTRUCTIONS
SUPPORT: 01793 333212
FOR YOUR SAFETY
WARNING: PERSONS SHOULD NEVER RIDE IN THE CEMENT MIXER
Please read & understand this manual, paying attention to the safety instructions, before use.
Incorrect use of the product could put the operator or machine in danger.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, our policy
of continuous improvement determines the right to make modifications without prior warning.
Images used are for illustration purposes only
05-11-2024 v2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the THLCHCM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for The Handy THLCHCM

Summary of Contents for The Handy THLCHCM

  • Page 1 LIGHT CONSTRUCTION INSTRUCTION MANUAL ELECTRIC HORIZONTAL CEMENT MIXER MODEL NO: THLCHCM -- PRODUCT NO: 193821002 EN - ORIGINAL INSTRUCTIONS TWO PERSON LIFT - ASSEMBLY REQUIRED SAVE THESE INSTRUCTIONS SUPPORT: 01793 333212 FOR YOUR SAFETY WARNING: PERSONS SHOULD NEVER RIDE IN THE CEMENT MIXER Please read &...
  • Page 2 Copyright Notice Copyright © Handy Distribution Permission is granted to reproduce this publication for personal & educational use only. Commercial copying, redistribution, hiring or lending is prohibited. No part of this publication may be stored in a retrieval system or transmitted in any other form or means without written permission from Handy Distribution.

  • Page 3: Specifications

    CONTENTS SPECIFICATIONS IMPORTANT INFORMATION GENERAL SAFETY INSTRUCTIONS OPERATING INSTRUCTIONS MAINTENANCE & STORAGE ASSEMBLY PARTS DIAGRAM & LIST DECLARATION OF CONFORIMITY WARRANTY ASSEMBLY IS REQUIRED - MINIMUM TWO PERSONS • This product requires assembly before use. • See “Assembly” section for instructions. •...

  • Page 4: Specification

    The manufacturer reserves the right to change the product specification and livery according to continued product improvements. Consistent with our policy of continuous improvement, The Handy reserves the right to change the design and configuration of any of its products without notice or obligation. Therefore, please treat the text and images in this manual for illustrative purposes only.

  • Page 5: Intended Use

    IMPORTANT INFORMATION INTENDED USE WARNING Read this instruction manual carefully before operating this machine. Make sure that you are familiar with the controls and properly operate the machine. Following these instructions can reduce the risk of personal injury. The Electric Cement Mixer is for DIY home and garden and designed and manufactured for thorough, even mixing of concrete and mortar.

  • Page 6: General Safety Instructions

    GENERAL SAFETY INSTRUCTIONS It is important that you read & understand the owner’s manual & labels affixed to the machine. Learn its application & limitations as well as the specific potential hazards. Retain these instructions for future reference. The operator is responsible for following the warnings & instructions in this manual and on the product.

  • Page 7: Important Safety Warnings

    Disconnect from power supply Double insulated or class 2 when not in use, before moving, electrical appliances are making adjustments, changing products that have been parts, cleaning, or working on the designed in a way so as not to mixer. Never open the motor require a safety connection to cover before disconnecting the electrical earth (These...

  • Page 8: Slope Operation

    personal injury. 8. Stay in the operator zone behind the handles and keep children, bystanders, helpers, and pets at least 20 metres from the mixer while it is in operation. Stop the machine if anyone enters area. 9. Always wear safety glasses or safety goggles during operation and while performing an adjustment or repair to protect your eyes.

  • Page 9: Electrical Safety

    SERVICE General Service: 1. Before cleaning, repairing, or inspecting, make certain the drum and all moving parts have stopped. Disconnect the electrical plug from the power source to prevent unintended starting. 2. Check the drum & blades at frequent intervals for proper tightness. Also, visually inspect for damage. Replace with the original equipment manufacture’s (O.E.M.) parts only, listed in this manual.

  • Page 10: Personal Safety

    PERSONAL SAFETY 1. This machine is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the machine by a person responsible for their safety. 2.

  • Page 11: Set Up & Preparation For Operation

    SET UP & PREPARATION FOR OPERATION This product must be assembled correctly before use. Carefully remove the product and any accessories from the carton. Inspect the product carefully to make sure there are no breakages or missing items during shipping. Do not discard the packing material and carton until you have carefully inspected and satisfactorily operated the product.
  • Page 12 ASSEMBLY Follow the assembly instructions below carefully, you should be able to assemble the machine in a short period. WARNING If any parts are damaged or missing do not operate this product until the parts are replaced. Failure to heed this warning could result in serious personal injury.
  • Page 13 With the frame lying on its side, attach the support leg as shown. Insert two M8x70 hex bolts through the holes from one side, followed by flat washers, lock washers and nuts from the other side. Tighten fully. Turn the frame over and attach the axle bracket with wheel frame in the same manner. Make sure all bolts and nuts are tightened.
  • Page 14 STEP 2 – THE BOTTOM DRUM Slide the bearing block onto the shaft. Hold it in place with Ø42 spiral ring. Carefully, and with two people, set the bottom drum with support arm onto the side supports of the stand as shown, so that the bearing blocks slot into the channels provided by the side supports.
  • Page 15 STEP 4 – THE UPPER DRUM Position the upper drum onto the bottom drum over the rim, making sure the mounting holes align in both as well as the labeled arrows. Screw a M8x16 hex bolt with lock and flat washers into each threaded hole in the rim/ring gear.
  • Page 16 Insert the spring with the washer on the top into the sleeve on the tipping wheel. Slide the wheel over the larger diameter shaft until the holes in the bracket line up with the hole drilled. Insert a M10x65 hex bolt with a flat washer and screw on a nut with a flat washer from the other side.
  • Page 17 STEP 6 – THE TRANSMISSION Lining up the keyways, slide the transmission case over the pinion shaft. Secure the case to the frame with washer & M8 nut.

  • Page 18: Operation

    OPERATION • Before operating the machine, please ensure you are fully aware of the instructions below, failure to do so, could invalidate your manufacturer’s warranty. • Completely unwind any extension cable. Connect it to the mixer first, before plugging into the mains power supply.

  • Page 19: Maintenance And Storage

    DRUM LOADING For best results, proceed as follows: • Add the required amount of gravel into the drum. • Add the required amount of cement into the drum. • Add the required amount of sand into the drum. • Pour the required amount of water into the drum. DRUM EMPTYING Empty the drum with the drum rotating.

  • Page 20: Electrical Connection

    NOTE: When storing any type of power equipment in an unventilated or material storage shed, − Care should be taken to rust-proof the equipment. Using a light oil or silicone, coat the equipment, especially cables and all moving parts. − Be careful not to bend or kink cables. ELECTRICAL CONNECTION Do not connect either core to the earth pin.
  • Page 21 PARTS DIAGRAM – THLCHCM (193821002)
  • Page 22 PARTS LIST– THLCHCM (193821002)
  • Page 23 & 3 years of the warranty. The Handy (including Light Construction), Platinum (Petrol & Electric), a) 2 years from the original date of sale to the first domestic user. b) 90 days from the original date of sale to the professional/commercial user.
  • Page 24 Webb Dynamic, Heritage & Legacy (Red Products), Platinum (All non-Petrol & Electric), Q-Garden. a) 1 year from the original date of sale to the first domestic user. b) 90 days from the original date of sale to the professional/commercial user. 90 days from the original date of sale when used for hire.

  • Page 25: Declaration Of Conformity

    DECLARATION OF CONFORMITY We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product: Designation: Electric Horizontal Cement Mixer Model(s): THLCHCM Product Number: 193821002 Rated Power: 550w S6 30% Rated Voltage: 230V~50Hz Drum Speed: 26.6rpm Type/Serial No: As per rating label on machine Complies with the following directives: 2006/42/EC –...
  • Page 26 NOTES...
  • Page 28 For spares or support of your handy product, please contact us: Tel: 01793 333212 Email: cs@thehandy.co.uk Opening Hours Weekdays: Monday to Friday 08:00 – 17:00 (CLOSED WEEKENDS, BANK HOLIDAYS & BUSINESS CLOSURES) To see our range of garden machinery & equipment visit: www.thehandy.co.uk Making home &...
