- Page 1 OPERATION & SERVICE MANUAL Models: AGE17075A Ground Test Tool Falcon 7X Ram Air Turbine 01/2015 Rev. 01 Tronair, Inc. Phone: (419) 866-6301 | 800-426-6301 1 Air Cargo Pkwy East Web: www.tronair.com Swanton, OH 43558 Email: sales@tronair.com...
- Page 2 REVISION DATE TEXT AFFECTED 01/2015 Original release...
- Page 3 Models: AGE17075A Ground Test Tool Ram Air Turbine TABLE OF CONTENTS PAGE PRODUCT INFORMATION .............................. 1 FUNCTION................................1 LIST OF DRAWINGS ............................1 RELEVANT STANDARDS ..........................1 OVERVIEW ................................. 1 MATING COUPLINGS AND PLUGS: ......................... 1 SAFETY INFORMATION ..............................1 EXPLANATION OF WARNING AND DANGER SIGNS ..................
- Page 4 Ground Test Tool Ram Air Turbine This product can not be modified without the written approval of Tronair, Inc. Any modifications done without written approval voids all warranties and releases Tronair, Inc., it suppliers, distributors, employees, or financial institutions from any liability from consequences that may occur.
- Page 5 Models: AGE17075A Ground Test Tool Ram Air Turbine SAFETY INFORMATION (continued) PERSONAL PROTECTIVE EQUIPMENT Operators must use personal protective equipment in accordance with their employer’s requirements See airframe/RAT manufacturer’s information on maximum sound levels during ground check out SAFETY GUIDELINES ...
- Page 6 Models: AGE17075A Ground Test Tool Ram Air Turbine INSTALLATION INSTALLATION REQUIREMENTS Hydraulic Cart requirements: 16.5 gpm @ 3,000 psi (62.5 lpm @ 207 bar), MIL-PRF-5606 fluid WARNING! Do not exceed 3,100 psi (214 bar) rated supply pressure to motor.
- Page 7 This GTT Operation and Maintenance Manual does not provide qualified training to perform aircraft RAT ground checkout tests. TRAINING PROGRAMS, MANUALS, METHODS, SUPERVISORS, AND OPERATORS Tronair does not provide training materials beyond the scope of this manual. It is the employer’s responsibility to provide any training requirements beyond the scope of this manual. MAINTENANCE DESCRIPTION OF EQUIPMENT Hydraulic Motor –...
-
Page 8: Troubleshooting Guide
GUARANTEES/LIMITATION OF LIABILITY Tronair products are warranted to be free of manufacturing or material defects for a period of one year after shipment to the original customer. This is solely limited to the repair or replacement of defective components. This warranty does not cover the... - Page 9 Models: AGE17075A Ground Test Tool Ram Air Turbine This page left blank intentionally. 01/2015 | Rev. 01 Page | 6...
- Page 10 Models: AGE17075A Ground Test Tool Ram Air Turbine Parts List NOTES: Install Items 4 & 5 to motor, safety wire together. Same location, opposite side. Pressure hose (Item 7) must be connected to “-6 Size” port Return hose (Item 6) must be connected to “-8 Size” port.
- Page 11 Models: AGE17075A Ground Test Tool Ram Air Turbine Parts List Item Part Number Description HC-2581 Motor, RAT Falcon 7X V-2287 Label, Serial number V-1975 Label, MIL-PRF-5606 N-2841-05-S-B Connector, Straight Thread (16-8) N-2841-06-S-B Connector, Straight Thread (12-6) TF-1117-27*240 Assembly, Hose -16...
- Page 13 APPENDIX I Declaration of Conformity...
-
Page 15: Declaration Of Conformity
DECLARATION of CONFORMITY The design, development and manufacture is in accordance with European Community guidelines GROUND TEST TOOL AGE17075A Relevant directive complied with by the machinery: 2006/42/EC Relevant standards complied with by the machinery: EN ISO 4413:2010 APR 1247D EN 1915-1:2013...
