- Page 1 OPERATION & SERVICE MANUAL Model: AGE17073A RAT Ground Test Tool 01/2020 Rev. 02 Tronair, Inc. Phone: (419) 866-6301 | 800-426-6301 1 Air Cargo Pkwy East Web: www.tronair.com Swanton, OH 43558 Email: sales@tronair.com...
- Page 2 REVISION DATE TEXT AFFECTED 08/2014 Original release 01/2020 Major revision...
- Page 3 Model: AGE17073A Ground Test Motor Ram Air Turbine TABLE OF CONTENTS PAGE PRODUCT INFORMATION ............................1 DESCRIPTION ..............................1 MODEL & SERIAL NUMBER .......................... 1 MANUFACTURER ............................1 FUNCTION ..............................1 LIST OF DRAWINGS ............................1 RELEVANT STANDARDS ..........................1 MATING COUPLINGS AND PLUGS .......................
- Page 4 Model: AGE17073A Ground Test Motor Ram Air Turbine TROUBLESHOOTING GUIDE ........................5 10.0 PROVISION OF SPARES ............................. 6 10.1 SOURCE OF SPARE PARTS ......................... 6 10.2 RECOMMENDED SPARE PARTS LISTS ....................... 6 11.0 IN SERVICE SUPPORT ..............................6 12.0 GUARANTEES/LIMITATION OF LIABILITY ........................
- Page 5 Ground Test Motor Ram Air Turbine This product can not be modified without the written approval of Tronair, Inc. Any modifications done without written approval voids all warranties and releases Tronair, Inc., it suppliers, distributors, employees, or financial institutions from any liability from consequences that may occur.
- Page 6 Model: AGE17073A Ground Test Motor Ram Air Turbine SAFETY INFORMATION USAGE AND SAFETY INFORMATION To insure safe operations please read the following statements and understand their meaning. Also refer to your equipment manufacturer’s manual for other important safety information. This manual contains safety precautions which are explained below.
- Page 7 Tronair does not provide training materials beyond the scope of this manual. It is the employer’s responsibility to provide any training requirements beyond the scope of this manual.
- Page 8 Model: AGE17073A Ground Test Motor Ram Air Turbine OPERATION OPERATING PARAMETERS Ground checkout tests Temperature Range: -10 F thru +120 F (-23 C thru +49 C) NUMERICAL VALUES AND LIMITS 6.2.1 General Phosphate Ester fluid, Type IV or V ...
-
Page 9: Troubleshooting Guide
Model: AGE17073A Ground Test Motor Ram Air Turbine PACKAGING AND STORAGE PACKAGING REQUIREMENTS This tool is provided with a storage case that is suitable for shipment. METHODS OF HANDLING The GTM case can be rolled freely by hand. - Page 10 GUARANTEES/LIMITATION OF LIABILITY Tronair products are warranted to be free of manufacturing or material defects for a period of one year after shipment to the original customer. This is solely limited to the repair or replacement of defective components. This warranty does not cover the...
- Page 11 Model: AGE17073A Ground Test Motor Ram Air Turbine Parts List When ordering replacement parts/kits, please specify model, serial number and color of your unit. Item Part Number Description HC-2576 Motor, RAT V-2565 Label, PE Fluid Only N-2841-05-S-E Connector, Straight Thread (16-8)
- Page 13 APPENDIX I Declaration of Conformity...
-
Page 15: Declaration Of Conformity
DECLARATION of CONFORMITY The design, development and manufacture is in accordance with European Community guidelines GROUND TEST TOOL AGE17073A Relevant directive complied with by the machinery: 2006/42/EC Relevant standards complied with by the machinery: EN ISO 4413:2010 APR 1247D EN 1915-1:2013...
