- Page 1 TX3141E-W Wireless Manual Call Point Installation and Operation Manual TANDA DEVELOPMENT PTE. LTD. Copyright ©2017, All right reserved.
- Page 2 TX3141E-W Wireless Manual Call Point Installation & Operation Manual Product Safety To prevent severe injury and loss of life or property, read the instruction carefully before installing the detector to ensure proper and safe operation of the system. European Union directive...
- Page 3 TX3141E-W Wireless Manual Call Point Installation & Operation Manual Table of Content 1 General .....................................4 2 Characteristics ................................4 3 Technical Parameters ..............................4 4 Structural features and operating principle ......................4 5 Installation instructions ..............................6 6 Usage and Operation ..............................6 6.1 Registering and networking ..........................
- Page 4 TX3141E-W Wireless Manual Call Point Installation & Operation Manual 1 General TX3141E (LoRa) is wireless alarm button (hereinafter referred to as manual call point). When fire is manually confirmed, press the wireless alarm button and send alarm signal to fire alarm controller.
- Page 5 TX3141E-W Wireless Manual Call Point Installation & Operation Manual Fig 1 Outline diagram for wireless manual call point 4.2 Wireless alarm button base dimension diagram, as shown in Fig. 2 (unit: mm) ST3.5×25FA Plastic expansion pipe 塑料膨胀管 螺钉 Screw Fig. 2 wireless alarm button base and fixed accessories 4.3 Operating principle...
- Page 6 TX3141E-W Wireless Manual Call Point Installation & Operation Manual 5 Installation instructions 1. Appropriate installation position: ①TX6934 handheld equipment is used to detect network signal. Wireless alarm button is installed where network signal is best. ② Wireless alarm button shall be installed where it is obvious and easy for operation. When it is installed on the wall, the bottom shall be 1.3～1.5m from the floor.
- Page 7 TX3141E-W Wireless Manual Call Point Installation & Operation Manual 7 Product notes 1. Wireless signals for wireless alarm button and household fire alarm controller will be affected by external environment, such as wall obstruction and absorption, other wireless signal interference etc;...
