TV Stand
Model 443098
Share your journey!
to order replacement parts, view video assembly tips, or chat with a live rep.
1-800-445-1527
.
Your holder for all
things awesome.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-28
Français pg 29-32
Español pg 33-36
Lot # 911259
Purchased: __________________
05/28/24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 443098 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sauder 443098

Summary of Contents for Sauder 443098

  • Page 1 Customer Service is available Monday-Friday - 8:30 a.m. to 5:00 p.m. EST (except holidays) Your holder for all things awesome. TV Stand NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Model 443098 PLEASE READ AND KEEP FOR FUTURE REFERENCE. English pg 1-28 Français pg 29-32 Español pg 33-36 Share your journey!
  • Page 2 • Check the size and weight of your TV. Compare it to the diagram below – before you begin assembly! • This Sauder unit is designed for use with flat panel televisions weighing less than 95 pounds. Never use with a TV that weighs more.

  • Page 3: Part Identification

    Use this part identification to help identify similar parts. TOP (1) REAR BASE (1) DOOR (4) BOTTOM (1) FRONT BASE (1) LEFT END (1) UPRIGHT (1) SIDE BASE (2) RIGHT END (1) ADJUSTABLE SHELF (2) BACK (1) www.sauder.com/service 443098 Page 3...

  • Page 4: Hardware Identification

    N5 NAIL - 32 P182 APPLIQUE CARD - 1 SHELF PIN - 8 S33 9/16" FLAT HEAD SCREW - 16 1/2" PAN HEAD SCREW - 4 S244 13/16" MACHINE SCREW - 8 3-5/16" HEX HEAD SCREW - 6 Page 4 443098 www.sauder.com/service...
  • Page 5 Look for this icon. It means a video assembly tip is Hardware Usage Guide available at www.sauder.com/service/tips Find the numbered video or scan the QR code. HOW TO USE A HIDDEN CAM & CAM SCREW OR CAM DOWEL NOTE: Various CAM SCREWS or a CAM DOWEL may be used.
  • Page 6 å Assemble your unit on a carpeted floor or on the empty carton to avoid scratching your unit or the floor. Remember: Righty tighty. å Turn six CAM SCREWS (F13) into the TOP (A). Lefty loosey. Page 6 443098 www.sauder.com/service...
  • Page 7 Meet Part (K). This component has Arrow been engineered to be lighter, stronger, faster… well ok. Not technically faster. But definitely makes for a sturdier TV Stand that’ s easier to assemble and friendlier to the environment. www.sauder.com/service 443098 Page 7...
  • Page 8 BACK fastened. The unit may collapse. å NOTE: Be sure the WOOD DOWEL in the TOP inserts into the END. Edge with holes S u r f a c i t h H I D D E N Page 8 443098 www.sauder.com/service...
  • Page 9 Push two HIDDEN CAMS (F12) into the RIGHT END (L). å NOTE: Be sure to fully insert the HIDDEN CAMS into the holes. You may need to use your screwdriver to completely insert the HIDDEN CAMS. Arrow Part (L). Another sturdier, easier, friendlier component! www.sauder.com/service 443098 Page 9...
  • Page 10 Insert one WOOD DOWEL (F14) into the TOP (A). å Fasten the RIGHT END (L) to the TOP (A). Tighten two HIDDEN CAMS. å NOTE: Be sure the WOOD DOWEL in the TOP inserts into the END. Edge with holes Page 10 443098 www.sauder.com/service...
  • Page 11 Push two HIDDEN CAMS (F12) into the UPRIGHT (C). å NOTE: Be sure to fully insert the HIDDEN CAMS into the holes. You may need to use your screwdriver to completely insert the HIDDEN CAMS. Arrow www.sauder.com/service 443098 Page 11...
  • Page 12 NOTE: Be sure the WOOD DOWEL in the TOP inserts into the UPRIGHT. S u r f a c i t h H I D D E N For support, place packing material or books here. Page 12 443098 www.sauder.com/service...
  • Page 13 Step 8 å Turn ten CAM SCREWS (F13) into the BOTTOM (B). www.sauder.com/service 443098 Page 13...
  • Page 14 3-5/16" HEX HEAD SCREWS (S244) using the L-WRENCH (M30). å NOTE: Be sure the WOOD DOWELS in the BOTTOM insert into the UPRIGHT and ENDS. i t h f a c S u r S244 3-5/16" HEX HEAD SCREW (6 used in this step) Page 14 443098 www.sauder.com/service...
  • Page 15 NOTE: Be sure to fully insert the HIDDEN CAMS into the holes. You may need to use your screwdriver to completely insert the HIDDEN CAMS. å Turn four CAM SCREWS (F13) into the BASES (E and F). Arrow Arrow Arrow Arrow Arrow Arrow www.sauder.com/service 443098 Page 15...
  • Page 16 (Optional, but HIDDEN CAMS. recommended.) å NOTE: Be sure the WOOD DOWELS insert into the SIDE BASES. Edge without holes Edge with tack glides Surface with HIDDEN CAMS Edge with tack glides Edge without holes Page 16 443098 www.sauder.com/service...
  • Page 17 Insert eight WOOD DOWELS (F14) into the BOTTOM (B). å Fasten the BASES (E, F, and G) to the BOTTOM (B). Tighten ten HIDDEN CAMS. å NOTE: Be sure the WOOD DOWELS in the BOTTOM insert into the BASES. (8 used) Angled edge www.sauder.com/service 443098 Page 17...

  • Page 18: Back Installation

    NOTE: Be sure to tap NAILS into the holes that line up over the UPRIGHT (C). 1/2" PAN HEAD SCREW (4 used in this step) NAIL (32 used in this step) These holes must line up over the UPRIGHT (C). Page 18 443098 www.sauder.com/service...
  • Page 19 Carefully stand your unit upright. å Insert the SHELF PINS (R4) into the hole locations of your choice in the UPRIGHT (C) and ENDS (K and L). Set the ADJUSTABLE SHELVES (D) onto the SHELF PINS. (8 used) www.sauder.com/service 443098 Page 19...
  • Page 20 Note the differences between the two HINGES for your unit and be sure to keep them separated. High curve The rivets on the HIGH CURVED HINGE are more angled. Low curve The rivets on the LOW CURVED HINGE are more in line. Page 20 443098 www.sauder.com/service...
  • Page 21 Step 16 å Fasten the HIGH CURVED HINGES (H40) to two DOORS (J). Use eight 9/16" FLAT HEAD SCREWS (S33). 9/16" FLAT HEAD SCREW (8 used in this step) www.sauder.com/service 443098 Page 21...
  • Page 22 Fasten one PULL (K91) to the DOOR (J). Use two 13/16" MACHINE SCREWS (S44). å Repeat this step for the other DOOR (J) with HIGH CURVED HINGES. å See Step 20 for DOOR adjustments. 13/16" MACHINE SCREW (4 used for the PULLS) Page 22 443098 www.sauder.com/service...
  • Page 23 Step 18 å Fasten the LOW CURVED HINGES (H41) to two DOORS (J). Use eight 9/16" FLAT HEAD SCREWS (S33). 9/16" FLAT HEAD SCREW (8 used in this step) www.sauder.com/service 443098 Page 23...
  • Page 24 Fasten one PULL (K91) to the DOOR (J). Use two 13/16" MACHINE SCREWS (S44). å Repeat this step for the other DOOR (J) with LOW CURVED HINGES. å See the next step for DOOR adjustments. 13/16" MACHINE SCREW (4 used for the PULLS) Page 24 443098 www.sauder.com/service...

  • Page 25: Door Adjustments

    To adjust the DOOR in or out (depth), loosen the mounting screw one turn and move the DOOR in or out, as needed. Tighten the mounting screw after making adjustments. Mounting screw (depth) Adjusting screw (horizontal) (vertical adjustment) www.sauder.com/service 443098 Page 25...
  • Page 26 Step 21 å Peel BUMPERS from the BUMPER CARD (M34) and stick them onto the ADJUSTABLE SHELVES (D) where they will Almost time to come into contact with the DOORS. celebrate! With a nap. Page 26 443098 www.sauder.com/service...
  • Page 27 Nota: Esta e tiqueta es permanente. Remarque: Cette étiquette est No i ntente quitarla. C ausará daño a permanente. Ne pas essayer de la la superficie retirer. Causer des dommages à 12/22 la surface. www.sauder.com/service 443098 Page 27...
  • Page 28 NOTE: Please read the back pages of the instruction booklet for important safety information. å This completes assembly. Clean with a damp cloth. Wipe dry. And to celebrate, why not share your success story at Walmart.com or P182 Page 28 443098 www.sauder.com/service...
