AnS-Q Module Conversion
Adapter
User's Manual
A1SADP-Q-SET1
A1SADP-Q-SET2
Thank you for purchasing the Mitsubishi MELSEC-AnS series programmable controllers.
Before using this product, please read this manual and relevant manuals carefully to handle the
product correctly.
MODEL
MODEL CODE 13J229
IB(NA)-0800540-C(1607)MEE
 2014 MITSUBISHI ELECTRIC CORPORATION
A1SADP-U

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A1SADP-Q-SET1 and is the answer not in the manual?

Questions and answers

Related Manuals for Mitsubishi Electric A1SADP-Q-SET1

Summary of Contents for Mitsubishi Electric A1SADP-Q-SET1

  • Page 1 A1SADP-Q-SET1 A1SADP-Q-SET2 Thank you for purchasing the Mitsubishi MELSEC-AnS series programmable controllers. Before using this product, please read this manual and relevant manuals carefully to handle the product correctly. MODEL A1SADP-U MODEL CODE 13J229 IB(NA)-0800540-C(1607)MEE  2014 MITSUBISHI ELECTRIC CORPORATION...

  • Page 2: Safety Precautions

    SAFETY PRECAUTIONS (Read these precautions before using this product.) Before using this product, please read this manual and the relevant manuals carefully and pay full attention to safety to handle the product correctly. In this manual, the safety precautions are classified into two levels: " WARNING"...
  • Page 3 [Design Precautions] WARNING ● In an output circuit, when a load current exceeding the rated current or an overcurrent caused by a load short-circuit flows for a long time, it may cause smoke and fire. To prevent this, configure an external safety circuit, such as a fuse. ●...
  • Page 4 [Installation Precautions] CAUTION ● Use the programmable controller in an environment that meets Page 28 General Specifications in this manual. Failure to do so may result in electric shock, fire, malfunction, or damage to or deterioration of the product. ● To mount the AnS-Q module conversion adapter (module part), mount the adapter after fully insert the adapter fixing projection(s) in the lower part of the adapter into the hole(s) in the base unit, and tighten the adapter mounting screws with the specified torque.
  • Page 5 [Wiring Precautions] CAUTION ● Individually ground the FG and LG terminals of the programmable controller with a ground resistance of 100 ohms or less. Failure to do so may result in electric shock or malfunction. ● Use applicable solderless terminals and tighten them within the specified torque range. If any spade solderless terminal is used, it may be disconnected when the terminal screw comes loose, resulting in failure.
  • Page 6 [Startup and Maintenance Precautions] CAUTION ● When connecting a peripheral with the programmable controller CPU or connecting a personal computer with an intelligent function module to modify data of a running programmable controller, configure an interlock circuit in the sequence program to ensure that the entire system will always operate safely.
  • Page 7 PRÉCAUTIONS DE SÉCURITÉ (Lire ces précautions avant toute utilisation du produit.) Avant d'utiliser ce produit, lire attentivement ce manuel ainsi que les manuels auxquels il renvoie, et toujours considérer la sécurité comme de la plus haute importance en manipulant le produit correctement.
  • Page 8 [Précautions lors de la conception] AVERTISSEMENT ● Configurer des circuits de sécurité extérieurs à l'automate programmable pour garantir la sécurité du système dans son ensemble à la survenance d'une anomalie dans l'alimentation externe comme dans l'automate programmable. Faute de quoi, une instruction de sortie incorrecte ou un dysfonctionnement pourrait être à...
  • Page 9 [Précautions lors de la conception] AVERTISSEMENT ● Dans un circuit de sortie, si le courant de charge excède la valeur nominale ou si une surintensité causée par un court-circuit à la charge persiste longtemps, il peut en résulter un dégagement de fumée avec départ de feu. Pour éviter cela, il faut configurer un circuit de sécurité, avec un fusible par exemple.
  • Page 10 [Précautions d'installation] ATTENTION ● Utiliser l'automate programmable dans un environnement en conformité avec Page 28 General Specifications (Spécifications générales) ce manuel. Faute de quoi, il a risque d'électrocution, de départ de feu, de dysfonctionnement, d'endommagement ou de détérioration du produit. ●...
  • Page 11 [Pécautions de câblage] ATTENTION ● Mettre à la terre individuellement les bornes FG et LG de l'automate programmable avec  une résistance de terre inférieure à 100 . Faute de quoi, il y a risque d'électrocution et de dysfonctionnement. ● Utiliser des bornes sans soudure de type approprié et serrer au couple de serrage prescrit. Si on utilise des bornes sans soudure de type embrochable, il y a risque de déconnexion et de panne au cas où...
  • Page 12 [Précautions de mise en service et de maintenance] AVERTISSEMENT ● Ne toucher à aucun des bornes quand le système est sous tension. Faute de quoi, il y a risque d'électrocutions et de dysfonctionnements. ● Couper l'alimentation externe utilisée pour le système (sur toutes les phases) avant de procéder au nettoyage du module ou au resserrage des vis de bornes des vis de connecteur ou des vis de fixation du module.
  • Page 13 [Précautions de mise au rebut] ATTENTION ● Lors de sa mise au rebut, ce produit doit être traité comme un déchet industriel.

  • Page 14: Conditions Of Use For The Product

    CONDITIONS OF USE FOR THE PRODUCT (1) Mitsubishi programmable controller ("the PRODUCT") shall be used in conditions; i) where any problem, fault or failure occurring in the PRODUCT, if any, shall not lead to any major or serious accident; and ii) where the backup and fail-safe function are systematically or automatically provided outside of the PRODUCT for the case of any problem, fault or failure occurring in the PRODUCT.

  • Page 15: Table Of Contents

    CONTENTS SAFETY PRECAUTIONS ........... . . 2 CONDITIONS OF USE FOR THE PRODUCT .
  • Page 16 Disconnecting procedure ..........39 Setting Parameters .

  • Page 17: Terms

    TERMS Unless otherwise specified, this manual uses the following terms. Term Description  Series Q series The abbreviation for Mitsubishi MELSEC-Q series programmable controller AnS series The abbreviation for Mitsubishi MELSEC-A series small type programmable controller AnS-Q module conversion adapter AnS-Q module conversion adapter The module part of the AnS-Q module conversion adapter.

  • Page 18: Compliance With Emc And Low Voltage Directives

    Use of EMI gaskets (sealing the clearance) can suppress undesired radiated emissions. The tests were conducted by Mitsubishi Electric Corporation using a control panel having damping characteristics of 37dB (maximum) and 30dB (average) (measured at 3m distance, 30 to 300MHz).

  • Page 19: Overview

    OVERVIEW About This Manual This manual describes the system configuration, specifications, part names, settings, and procedures before operation of the AnS-Q module conversion adapter. AnS-Q Module Conversion Adapter The AnS-Q module conversion adapter is an adapter to mount a Q series module such as I/O module and intelligent function module on the AnS series base unit.

  • Page 20: Packing List

    Packing List The following items are included in the package of this product. • A1SADP-Q-SET1 Item Model Quantity AnS-Q module conversion adapter (module part) A1SADP-Q AnS-Q module conversion adapter (base unit part) A1SADP-Q51B  Base unit installation screw (M414) ...

  • Page 21: Restrictions For Using The Adapter

    Restrictions for Using the Adapter Installation location When connecting the AnS-Q module conversion adapter, reserve the space to connect it. Consider the system configuration and check the external dimensions of the module to be mounted to reserve the space. (Page 52 External Dimensions) System configuration For the restrictions on the number of mountable modules, applicable modules, and connectable extension cables, refer to the following.

  • Page 22: System Configuration

    SYSTEM CONFIGURATION System Configuration Example The following system can be configured using the AnS-Q module conversion adapter. AnS-Q module conversion adapter (module part) (Up to three adapters can be mounted on one base unit.) AnS series main base unit Q series AnS-Q module conversion AnS series extension cable...

  • Page 23: Applicable Ans Series Base Units

    Applicable AnS Series Base Units The following table lists the AnS series base units where the AnS-Q module conversion adapter (module part) can be mounted. Series Type Model AnS series Main base unit A1S32B, A1S33B, A1S35B, A1S38B, A1S32B-E, A1S33B-E, A1S35B-E, A1S38B-E, A1S38HB, A1S38HBEU Extension base unit A1S65B, A1S68B, A1S65B-S1, A1S68B-S1, A1S52B,...

  • Page 24: Mountable Q Series Modules

    Mountable Q Series Modules The following table lists the Q series modules that can be mounted on the AnS-Q module conversion adapter (base unit part). Name Model Input module QX10, QX28, QX40, QX40-S1, QX41, QX41-S1, QX42-S1, QX41-S2, QX42, QX80, QX81, QX81-S2, QX82-S1, QX70, QX71, QX72 Output module QY10, QY18A, QY40P, QY41P, QY42P, QY50, QY22, QY68A, QY80, QY81P, QY82P, QY71...

  • Page 25: Connectable Extension Cables

    Restrictions The following restrictions apply to the Q series module mounted on the AnS-Q module conversion adapter (base unit part).  Function • The auto refresh function and dedicated instructions of intelligent function modules and network modules cannot be used. •...

  • Page 26: Software Packages

    Software Packages Set the parameters of the Q series module mounted on the AnS-Q module conversion adapter (base unit part). Applicable software packages The following table lists the software packages applicable to the AnS-Q module conversion adapter (module part). Software Version GX Works2 1.20W or later...

  • Page 27: Available Functions

    Available functions The following functions of the programming tool can be executed when connected to the AnS-Q module conversion adapter (module part). • Functions to read, write, verify, and delete parameters Functions Online function Read from PLC , Write to PLC, Verify with PLC , Format PLC memory, Delete PLC data *1 To store data in the standard ROM of the AnS-Q module conversion adapter (module part), execute the online function to the standard ROM.

  • Page 28: Specifications

    0m. Doing so may cause malfunction. When using the programmable controller under pressure, please consult your local Mitsubishi Electric representative. *2 This indicates the section of the power supply to which the equipment is assumed to be connected between the public electrical power distribution network and the machinery within premises.

  • Page 29: Performance Specifications

    Performance Specifications This section describes the performance specifications of the AnS-Q module conversion adapter. Item Specifications A1SADP-Q A1SADP-Q51B A1SADP-Q52B Internal current consumption (5VDC) 360mA 30mA 30mA External dimensions 130mm 98mm 98mm 34.5mm 77.0mm 102mm 117.2mm 44.1mm 44.1mm Weight 0.20kg 0.11kg 0.14kg...

  • Page 30: Part Names And Settings

    PART NAMES AND SETTINGS AnS-Q Module Conversion Adapter (Module Part) To open the cover, put your finger here. Name Application RUN LED (green) Indicates the operating status of the AnS-Q module conversion adapter. ■Indication states of the RUN LEDERR.LED ERR. LED (red) OnOff: Normal operation OnOn: Self-diagnostic error detected (The operation continues.) OnFlashing: Self-diagnostic error detected (The operation stops.)

  • Page 31: Dip Switch Setting

    DIP switch setting Set the DIP switches as follows in accordance with the CPU module or remote I/O station used and the type of Q series module mounted on the AnS-Q module conversion adapter (base unit part). • SW1, SW2 (CPU module and remote I/O station type setting switches) CPU module type DIP switch setting AnSCPU...

  • Page 32: Ans-Q Module Conversion Adapter (Base Unit Part)

    AnS-Q Module Conversion Adapter (Base Unit Part) • A1SADP-Q51B (one-slot type) • A1SADP-Q52B (two-slot type) Name Application Extension cable connector A connector to be connected to the AnS-Q module conversion adapter (module part). An extension cable is connected here. Base cover A protective cover of the extension cable connector Module connector A connector for mounting a Q series module...

  • Page 33: Procedures Before Operation

    PROCEDURES BEFORE OPERATION This chapter describes the procedures required to start operation of the Q series module mounted on the AnS-Q module conversion adapter (base unit part). Precautions This section describes the precautions for handling the AnS-Q module conversion adapter. •...

  • Page 34: Calculation Example

    Calculation example The voltage drop calculation example when the AnS-Q module conversion adapter (module part) is mounted on the main base unit (A1S35B) is shown below.  Conditions The voltage at the connector of the AnS-Q module conversion adapter (base unit part) is 4.75VDC or higher.
  • Page 35 Slot where Voltage drop of each slot on the main base unit Sum of the AnS-Q voltage module drops (Vk) conversion adapter (module part) is mounted )     Slot 0 )    Slot 1 )  ...

  • Page 36: Mounting/Removing The Ans-Q Module Conversion Adapter

    Mounting/Removing the AnS-Q Module Conversion Adapter Mounting procedures Mount the AnS-Q module conversion adapter (module part) on the AnS series base unit, and the Q series module on the AnS-Q module conversion adapter (base unit part), following the procedures below. AnS-Q module conversion adapter (module part) Mount the AnS-Q module conversion adapter (module part) on the AnS series base unit.

  • Page 37: Removing Procedures

    Removing procedures Remove the AnS-Q module conversion adapter (module part) from the AnS series base unit, and the Q series module from the AnS-Q module conversion adapter (base unit part), following the procedures below. AnS-Q module conversion adapter (module part) The AnS-Q module conversion adapter (module part) can be removed in the same way as the AnS series module is removed.

  • Page 38: Connecting/Disconnecting Extension Cables

    Connecting/Disconnecting Extension Cables Precautions • When connecting an extension cable to the AnS-Q module conversion adapter (base unit part), keep the base cover attached. • When laying extension cables, maintain the minimum bending radius of 55mm or more. Failure to do so may cause malfunction due to characteristic deterioration or cable disconnection.

  • Page 39: Disconnecting Procedure

    Hold the connector part of the cable, and insert it to the connectors of the AnS-Q module conversion adapter (module part) and AnS-Q module conversion adapter (base unit part). AnS-Q module conversion adapter (base unit part) Connector Q series extension cable Fix the cable with the fixing screws (tightening torque: 0.20Nm).

  • Page 40: Setting Parameters

    Setting Parameters This section describes parameters required to operate the Q series module mounted on the AnS-Q module conversion adapter (base unit part). Setting procedure The following are the basic steps for setting parameters. Create a project using the programming tool connected. Set parameters required to operate the Q series module.

  • Page 41: Settable Parameters

    Setting parameters Set PLC parameters and intelligent function module parameters required to operate the Q series module mounted on the AnS-Q module conversion adapter (base unit part).  Settable parameters The following table lists the parameters that can be set to the AnS-Q module conversion adapter (module part).
  • Page 42  Precautions for the I/O assignment setting When using the Q series module that is the two slot type where the first has empty 16 points, open "I/O assignment setting" to change the setting: For the point of "Empty" at the first slot, change the default 16 points to 0 points;...
  • Page 43 Writing the parameters Write the set parameters to the AnS-Q module conversion adapter (module part), following the procedure below. Directly connect a programming tool to AnS-Q module the AnS-Q module conversion adapter conversion adapter USB cable (module part) with a USB cable. (module part) Programming tool Q series...

  • Page 44: Troubleshooting

    TROUBLESHOOTING This chapter describes the errors that may occur while the AnS-Q module conversion adapter is being used, error causes, and actions to be taken. Troubleshooting Procedure Perform troubleshooting, following the procedure below. Step Check item Action Check an error with the CPU module. If the error was found to have occurred in the AnS-Q module conversion adapter, check the RUN LED and ERR.

  • Page 45: Troubleshooting Using The Programming Tool

    Troubleshooting using the Programming Tool Error information can be checked using the programming tool. How to check The methods of checking an error that has occurred in the AnS-Q module conversion adapter differ between the AnS-Q module conversion adapter (module part) and AnS-Q module conversion adapter (base unit part).

  • Page 46: Error In The Ans-Q Module Conversion Adapter

    Error in the AnS-Q module conversion adapter The error in the AnS-Q module conversion adapter can be checked by executing PLC diagnostics from the programming tool connected to the AnS-Q module conversion adapter (module part). When the AnS-Q module conversion adapter is used, error information is displayed on the PLC diagnostics window of GX Developer as shown below.

  • Page 47: Error In The Q Series Module

    Error in the Q series module The error in the Q series module mounted on the AnS-Q module conversion adapter (base unit part) can be checked by executing system monitor from the programming tool connected to the AnS-Q module conversion adapter (module part). The error information is displayed on the system monitor window as shown below.

  • Page 48: Error Codes

    Error Codes The following table lists the codes and causes of errors detected by the AnS-Q module conversion adapter. Error ERR. Error cause code  The mounted AnS-Q module conversion adapter (base unit part) is not the available type.  The DIP switches (SW1, SW2) are incorrectly set.

  • Page 49: Appendices

    APPENDICES Appendix 1 Non-Replaceable Modules The following table lists the modules that cannot be replaced from the AnS series module to the Q series module by means of the AnS-Q module conversion adapter. Name Model Alternative suggestion (AnS series) Output module A1SY28A Consider replacing it with the QY40P + FA-TH16YSR20S.
  • Page 50 (For details, please consult your local Mitsubishi representative.) Serial communication A1SJ71UC24- Consider replacing it with the Q series. module MODBUS Interface A1SJ71UC24-R2- Consider replacing it with the Q series. Module A1SJ71UC24-R4- *1 The FA-TH16YSR20S is the renewal tool manufactured by Mitsubishi Electric Engineering Co., Ltd.

  • Page 51: Appendix 2 Restriction Of The Positioning Module

    Appendix 2 Restriction of the Positioning Module When using the QD75D type/QD75P type positioning module by means of the AnS-Q module conversion adapter, an address of 0 to 8151 only allows access from the AnS series CPU module to the buffer memory. If the data is set by a program, some necessary data cannot be set, which involves the following restriction: •...

  • Page 52: Appendix 3 External Dimensions

    Appendix 3 External Dimensions • A1SADP-Q 34.5 23.6 93.6 (Unit: mm) • When an extension cable is connected 93.6 (128) (Unit: mm)
  • Page 53 • A1SADP-Q51B 15.5 44.1 (Unit: mm) • A1SADP-Q52B 15.5 44.1 (Unit: mm)
  • Page 54 MEMO...

  • Page 55: Revisions

    This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent licenses. Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property rights which may occur as a result of using the contents noted in this manual.

  • Page 56: Warranty

    WARRANTY Mitsubishi will not be held liable for damage caused by factors found not to be the cause of Mitsubishi; machine damage or lost profits caused by faults in the Mitsubishi products; damage, secondary damage, accident compensation caused by special factors unpredictable by Mitsubishi;...
  • Page 58 20 Waterford Office Park, 189 Witkoppen Road, Avenida Adelino Cardana, 293, 21 andar, Fourways, South Africa Bethaville, Barueri SP, Brazil Tel : +27-11-658-8100 Tel : +55-11-4689-3000 Germany MITSUBISHI ELECTRIC EUROPE B.V. German China MITSUBISHI ELECTRIC AUTOMATION (CHINA) Branch LTD. Mitsubishi-Electric-Platz 1, 40882 Ratingen, No.1386 Hongqiao Road, Mitsubishi Electric...
