- Page 1 Mighty CPS 2.0 (KB05MI-128)
- Page 2 Manufacturer: Kingsbox d.o.o. Partizanska 129, 6210 Sežana Slovenia Customer service: Write us on info@kingsbox.com or send us a message through our website at www.kingsbox.com/help Usage class: Studio (S) Designed in compliance with: ISO 20957 Warnings: - Freestanding equipment shall be installed on a stable and levelled base - All equipment designed with anchoring/attachement holes (e.g.
- Page 3 WARNING! If the structure (rig/rack) onto which this equipment is at- tached, is not secured to the ground and / or to the wall, it may overturn and / or cause damage to person or object in the immediate vicinity. The fixing bolts for wall and / or floor are not included in the pack- age, since different types of anchor bolts must be used for dif- fer-ent wall / floor types.
- Page 4 Assembly elements: Position 1 Position 2 Position 3 Upright 1x Side profile 4x Pulley profile 2x Position 4 Position 5 Position 6 Pulley Cart Plate LH Pulley Cart Plate RH Pulley fi114 7x Position 7 Position 8 Position 9 Pulley Cart Spacer Roller 3x Cart Tube 1x...
- Page 5 Assembly elements: Position 10 Position 11 Position 12 Spacer fi48 Rubbery Rubber Pad 1x Pulley Bush fi25 12x Position 13 Position 14 Position 15 Cable Ending Ball 2x Cable 8,7m 1x Screws M10x100 Position 16 Position 17 Position 18 Screws M10x110 Screws M10x120 Screws M8x120...
- Page 6 Assembly elements: Position 19 Position 20 Position 21 Screws M12x110 Nuts M10 Washers M10 Position 22 Position 23 Position 24 Nuts M8 Washer M8 Nuts M12 Position 25 Position 26 Washers M12 Screw M8x25...
-
Page 7: Tools Needed
Tools needed: Wrench 19 Wrench 17 Wrench 13 Allen Key 6... -
Page 8: Assembly Instruction
Assembly instruction: STEP: 1 STEP: 2... - Page 9 Assembly instruction: STEP: 3 STEP: 4...
- Page 10 Assembly instruction: STEP: 5 STEP: 6...
- Page 11 Assembly instruction: STEP: 7 STEP: 8...
- Page 12 Assembly instruction: STEP: 8 STEP: 9 - cable path...
- Page 13 Assembly instruction: STEP: 10 End of assembbly.
- Page 14 Note: Free area around the training equipment should be >0,6m than the training area in the direction from which the equipment is accessed. Max. loading / training mass:...
-
Page 15: Maintenance
Maintenance: - Rollers: Check the rollers regularly for any wear and tear and replace them if needed. It is normal for the rollers to show some run-in marks after the first use, but exces- sive wear may lead to improper movement of the trol- ley.
