Summary of Contents for KingsBox CCO
- Page 1 Static Kit for CCO...
- Page 2 Assembly elements: SAMPLE picture position position 1 position 2 QTY. CCO Upright CCO Adj. Pulley part name Pullej Cart Profile Up position 3 position 4 position 5 CCO Adj. Pulley CCO Connecting CCO Leg Profile Bottom Plate position 6 position 7 position 8 CCO Height Adj.
- Page 3 Assembly elements: position 9 position 10 position 11 CCO Addon_SPS Pulley fi114 Pulley Bush fi25 Cart position 12 position 13 position 14 Bolt M10x100 Bolt M10x110 Bolt M10x120 position 15 position 16 position 17 Bolt M10x70 Washer M10 Nut M10...
- Page 4 Assembly elements: position 18 position 19 position 20 Bolt M12x110 Washer M12 Nut M12 position 21 position 22 position 23 Zaključek Rower Roller Cart SPS kabla - Uho position 24 position 25 Position 7 CCO Plate_Pulley Puša fi14-10 Kroglica Cart...
- Page 5 Assembly instruction: STEP: 1 Allready assembled Allready assembled STEP: 2 4x Imbus zatiè M5x20...
- Page 6 Assembly instruction: Allready assembled STEP: 3 Allready assembled STEP: 4...
- Page 7 Assembly instruction: STEP: 5 STEP: 6...
- Page 8 Assembly instruction: STEP: 7 STEP: 8 tighten the bolt tighten the bolt tighten the bolt tighten the bolt tighten the bolt tighten the bolt...
- Page 9 Assembly instruction: STEP: 9 1x M10x60 2x M10 washer 1x M10 nut STEP: 10...
- Page 10 Assembly instruction: STEP: 11 STEP: 12 1x M10x70 2x M10 Washer 1x M10 Nut...
- Page 11 Assembly instruction: STEP: 13 STEP: 14 Cable Path Cable lenght: 8,5m...
- Page 12 Assembly instruction: STEP: 15 1) Insetr the cable 2) Tighten the Screws...
