Wireless Mouse
DW Version
User Manual
V1.01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FK2-DW and is the answer not in the manual?

Questions and answers

Related Manuals for BenQ FK2-DW

Summary of Contents for BenQ FK2-DW

  • Page 1 Wireless Mouse DW Version User Manual V1.01...

  • Page 2: Copyright And Disclaimer

    Disclaimer BenQ Corporation makes no representations or warranties, either expressed or implied, with respect to the contents of this document. BenQ Corporation reserves the right to revise this publication and to make changes from time to time in the contents thereof without obligation to notify any person of such revision or changes.

  • Page 3: Benq Ecofacts

    ZOWIE Support BenQ ecoFACTS BenQ has been dedicated to the design and development of greener product as part of its aspiration to realize the ideal of the "Bringing Enjoyment 'N Quality to Life" corporate vision with the ultimate goal to achieve a low-carbon society.
  • Page 4 BenQ ecoFACTS label lists key eco-friendly design highlights of each product, hoping to ensure that consumers make informed green choices at purchase.

  • Page 5: Table Of Contents

    Table of contents Copyright and disclaimer ........2 BenQ ecoFACTS ........... 3 Compatible models ..........7 Package contents ........... 8 Product overview ...........10 Connections ............13 Wireless connections ........13 Connecting via 4K enhanced receiver ...13 Connecting via USB receiver ......16 Wired connection ..........18 Power supply ............19...
  • Page 6 Changing click response time ......29 Enabling motion sync .........31 Care and maintenance ...........32 Cleaning ..............32 Storage ..............32 Specifications ............34 2024/09/16 V1.01...

  • Page 7: Compatible Models

    Compatible models This user manual is for the following models: • FK2-DW • ZA13-DW • S2-DW...

  • Page 8: Package Contents

    Package contents When unpacking please check you have the following items. If any are missing or damaged, please contact the place of purchase for a replacement. Descriptions Mouse 4K enhanced receiver USB adapter USB receiver Spare skatez USB cable...
  • Page 9 Descriptions User documents • Quick start guide • Regulatory statements • Warranty card Note • Consider keeping the box and packaging in storage for use in the future when you may need to transport the product. • Always keep the product and accessories out of reach of small children.

  • Page 10: Product Overview

    Product overview Descriptions Left button Right button Scroll wheel Backward side button Front side button Power LED indicator...
  • Page 11 Descriptions USB-C port • For charging • For connection with USB cable in wired operation Enhanced antenna Polling rate button Optical sensor Pogo pin (for charging) DPI button Mode switch • Wireless mode via the USB receiver • Power off mode •...
  • Page 12 14 15 Descriptions Signal stability LED indicator (see page 14) Polling rate LED indicator (see page 25) Pogo pin (for charging)

  • Page 13: Connections

    Connections Wireless connections You are provided with 2 ways of wireless connections. Connecting via 4K enhanced receiver 1. Connect the 4K enhanced receiver to your computer by the supplied USB cable. 2. Switch to mode from the bottom of the mouse.
  • Page 14 White Flashing amber Signal stability (when using 4K enhanced receiver) LED status Connection status Dim white The mouse is properly connected. Flashing • (During mouse operation) The amber signal is not stable. • (When the mouse is inactive/ off) The mouse is going to be disconnected.
  • Page 15 Tips • Keep the mouse and the receiver aligned in the center for optimal performance. • For optimal performance, use the mouse approximately 20 cm away from the receiver at an angle of 50 degrees (left and right). This is for reference only.

  • Page 16: Connecting Via Usb Receiver

    Connecting via USB receiver 1. Connect the USB receiver to your computer. To ensure stable connectivity, use the supplied extension adapter (USB adapter) and USB cable to extend the distance of USB receiver. adapter receiver 2. Switch to mode from the bottom of the mouse.
  • Page 17 Tips • For optimal performance, use the mouse within a range of 20 cm of the USB receiver approximately. This is for reference only. • Keep the receiver at least 2 meters away from other signal interference such wireless routers. >2m <20cm...

  • Page 18: Wired Connection

    Wired connection Connect the mouse to your computer using the supplied USB cable. Note Regardless of the mode switched from the bottom of the mouse, the mouse is switched to wired operation and starts charging when it is connected to PC via the USB cable.

  • Page 19: Power Supply

    Power supply Battery power check To check the battery power level, switch to mode from the bottom of the mouse. Alternatively, charge the mouse . The power LED indicators on the mouse will light up and show the battery power level.

  • Page 20: Additional Low Battery Indicator With High Polling Rate

    Additional low battery indicator with high polling rate When the mouse works with a high polling rate (2000 Hz or 4000 Hz) and the battery power is very low, you will be notified by a red light on the 4K enhanced receiver. In this case, the battery will be drained in a few hours.

  • Page 21: Charging

    Charging Charing via 4K enhanced receiver When the 4K enhanced receiver is connected to PC via the supplied USB cable, place the mouse on the receiver with the pogo pin connectors attached. Charging via USB cable Connect the mouse to PC via the supplied USB cable.

  • Page 22: Charging Time And Battery Time

    Charging time and battery time It takes about 2 hours to fully charge the mouse. Battery time of a fully charged mouse varies by polling rate. Battery time Polling rate (with constant movement wirelessly) 1000 Hz Up to 80 hours 4000 Hz Up to 24 hours 80hr...

  • Page 23: Saving Power

    Saving power To save battery power, switch to from the bottom of the mouse to power off. As a moving mouse in a bag/suitcase keeps consuming power, you should switch power the mouse off before packing.

  • Page 24: Configurations

    Configurations Configure the sensitivity of your mouse to meet your preferences. Changing DPI setting Press DPI button from the bottom of the mouse repeatedly to cycle through different DPI options. You can tell the current setting by the LED indicator above the button.

  • Page 25: Adjusting Polling Rate

    Adjusting polling rate Press polling rate button from the bottom of the mouse repeatedly to cycle through different polling rates. You can tell the current setting by the LED indicator above the button. Available polling rates vary according to the receiver (4K enhanced or USB) used.
  • Page 26 High polling rate (2000 Hz or 4000 Hz) is set. Polling rate LED indicator Battery power is ≤ 10% with high polling rate A relatively lower polling rate is set. Note If the polling rate is set to 2000 Hz / 4000 Hz yet the corresponding LED indicator remains off, check signal stability and make sure the wireless connection is working properly (with dim white signal stability LED...

  • Page 27: Changing The Lift Off Distance (Lod)

    Changing the Lift Off Distance (LOD) You might want to change the LOD to work with your preferences or mouse pad properly. 1. Switch to from the bottom of the mouse to power off. Make sure the mouse is disconnected from PC. 2.
  • Page 28 LOD settings and combination buttons Lower LOD Medium LOD Higher LOD...

  • Page 29: Changing Click Response Time

    Changing click response time 1. Switch to from the bottom of the mouse to power off. Make sure the mouse is disconnected from PC. 2. While pressing and holding the following corresponding button for the desired setting, power on the mouse by switching to mode with another hand at the same time.
  • Page 30 Click response time settings and corresponding buttons LED status after setup Fast response time Normal response time LED status after setup...

  • Page 31: Enabling Motion Sync

    Enabling motion sync To improve mouse tracking experience, you can enable motion sync by pressing the corresponding combination buttons together. The polling rate indicators light up when the setup is completed. Motion sync on LED status after setup Motion sync off LED status after setup...

  • Page 32: Care And Maintenance

    Care and maintenance Cleaning • Dusts on the optical sensor may keep the mouse from working properly. Use a clean and dry brush to clean the optical sensor. • Clean the mouse by a clean and dry cleaning cloth. • Water stains may keep the optical sensor from working properly.

  • Page 34: Specifications

    Specifications Item Description Driver No driver needed. 400 / 800 / 1000 / 1200 / 1600 / 3200 Polling rate 125 / 500 / 1000 / 2000 / 4000 Hz USB 2.0 / 3.0 plug & play Buttons 7 buttons Click response Fast / Normal...
  • Page 35 Item Description Cable USB-A to USB-C (2 meters/6.6 feet)
  • Page 36 © 2024 BenQ Corporation. All rights reserved. Rights of modification reserved.
