Confidential
Disassembly and Reassembly
730QDA (Apollon2-13)
Mobile communications Division
Jan. 11
th
2021
- 1 -
Mobile communications Division

Advertisement

loading
Need help?

Need help?

Do you have a question about the 730QDA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung 730QDA

Summary of Contents for Samsung 730QDA

  • Page 1 Confidential Disassembly and Reassembly 730QDA (Apollon2-13) Mobile communications Division Jan. 11 2021 - 1 - Mobile communications Division...
  • Page 2 1. Main System Confidential Assembly order is reverse of disassembly Common 1. Make sure to separate the AC adapter before disassembling the system. 2. Put the Computer on the flat as the picture showing . - 2 - Mobile communications Division...
  • Page 3 1. Main System Confidential Assembly order is reverse of disassembly Common 3. Remove the rubber foot on case rear. 4. Disassembly the screw on case rear. SCREW-MACHINE (6001-003312) 4 PCS Torque : 2.3 ~ 2.7Kgfcm - 3 - Mobile communications Division...

  • Page 4: Main System

    1. Main System Confidential Assembly order is reverse of disassembly 5. Remove the case rear as arrow direction. Common - Disassemble the Case front and Case rear at the edge first. - And then disassemble case rear . - 4 - Mobile communications Division...
  • Page 5 1. Main System Confidential Assembly order is reverse of disassembly Common 6. (1) Disassemble screws of battery. (2) Remove battery cable. SCREW-MACHINE (6001-003313) 4 PCS Torque : 2.3 ~ 2.7Kgfcm ※ First disassemble screw, then disassemble battery cable. - 5 - Mobile communications Division...
  • Page 6 1. Main System Confidential 7. Connector cable disassemble point FAN CABLE LCD Cable KBD Backlight Power board Antenna Cable FINGER PRINT SPEAKER -L SPEAKER -R KBD Membrane MAIN TO SUB TP FFC - 6 - Mobile communications Division...
  • Page 7 1. Main System Confidential Assembly order is reverse of disassembly ※ First disassemble screw, then disassemble fan Common cable, Antenna-Main/Aux and FPC sub to main . 7-1. (1) Disassemble screws of fan. (2) Remove fan cable , Antenna-Main/Aux and FPC sub to main . SCREW-MACHINE (6001-001650 ）...
  • Page 8 1. Main System Confidential Assembly order is reverse of disassembly Common 8. (1) Remove screw of SSD. (2) Remove SSD. (3) Remove B/L FPC, F/P FPC, power board FPC ,Speaker-R cable , KBD Mem brane , FFC-Touchpad , LCD Cable , Spe aker-L Cable .
  • Page 9 1. Main System Confidential Assembly order is reverse of disassembly SCREW-MACHIN Common (6001-001650) 7 PCS 10. (1) Remove the screws on Bracket main port. Torque : 2.3 ~ 2.7Kgfcm (2) Remove the screws on Front. (3) Remove the screws on Main board. (4) Remove Bracket main port and Main board.
  • Page 10 1. Main System Confidential Assembly order is reverse of disassembly Common 11 . (1) Remove the screws on Bracket sub port. (2) Remove the screw on Sub board. (3) Remove Bracket sub port and Sub board. SCREW-MACHINE (6001-001650) 5 PCS Torque : 2.3 ~ 2.7Kgfcm - 10 - Mobile communications Division...
  • Page 11 Confidential 1. Main System – Finger Print 12. Finger Print disassembly ① Remove the Tape Insulator Sub Disassembled F/P ② - 11 - Mobile communications Division...
  • Page 12 Confidential 1. Main System – Touchpad 13-1. Touchpad disassembly ① Remove GASKET-TOUCHPAD, INSULATOR-EMC2 Remove INSULATOR-EMC2 Remove GASKET-TOUCHPAD ③ Remove 4ea screw on Touchpad bracket (6001-001925, M1.4, L1.5) - 12 - Mobile communications Division...
  • Page 13 Confidential 1. Main System – Touchpad 13-2. Touchpad disassembly ④ Disassembly Disassemble touchpad assy from front - 13 - Mobile communications Division...
  • Page 14 1. Main System Confidential Assembly order is reverse of disassembly Common SCREW-MACHINE 15. Remove screws between hinge and case-front. (6001-001650) 4 PCS - 14 - Mobile communications Division...

  • Page 15: Lcd Disassembly

    Confidential 2. LCD Disassembly [LCD Assy can’t disassemble] Assembly order is reverse of disassembly Common 1. Remove the Cover-hinge as arrow direction. - 15 - Mobile communications Division...

  • Page 16: Cable Routing

    3. Cable routing Confidential LCD Cable KBD Backlight Cable Fan Cable SSD Slot1 WLAN Cable SPK CABLE- T/P FFC Fingerprint FPC USB FPC KBD Membrane Battery Cable SPK CABLE-R - 16 - Mobile communications Division...
