- Page 1 Confidential Disassembly and Reassembly 730QED(VESTA-13) Mobile communications Division 2021/12/21 - 1 - Mobile communications Division...
- Page 2 1. Main System Confidential Assembly order is reverse of disassembly 1. Make sure to separate the AC adapter before disassembling the system. 2. Put the Computer on the flat as the picture showing . - 2 - Mobile communications Division...
- Page 3 1. Main System Confidential Assembly order is reverse of disassembly 3. Remove the rubber foot on case rear. 4. Disassembly the screw on case rear. SCREW-MACHINE (6001-003313) 4 PCS Torque : 2.3 ~ 2.7Kgfcm - 3 - Mobile communications Division...
- Page 4 1. Main System Confidential Assembly order is reverse of disassembly 5. Remove the case rear with Jig as below. - Press the cover-hinge, then pull the rear with the suction jig. - And then disassemble case rear . Pull with jig Press - 4 - Mobile communications Division...
- Page 5 1. Main System Confidential Assembly order is reverse of disassembly 6. (1) Disassemble screws of battery. (2) Remove battery cable. (3) Remove battery SCREW-MACHINE (6001-003313) 4 PCS Torque : 2.3 ~ 2.7Kgfcm - 5 - Mobile communications Division...
- Page 6 1. Main System Confidential 7. Connector cable disassemble point FINGER PRINT LCD Cable DIG Cable FAN CABLE Antenna Cable SPEAKER -R SPEAKER -L KBD Backlight KBD Membrane MAIN TO SUB TP FFC - 6 - Mobile communications Division...
- Page 7 1. Main System Confidential Assembly order is reverse of disassembly 8. (1) Disassemble screws of fan. (2) Remove fan. SCREW-MACHINE (6001-002749) 3 PCS Torque : 2.3 ~ 2.7Kgfcm - 7 - Mobile communications Division...
- Page 8 1. Main System Confidential Assembly order is reverse of disassembly 9. (1) Remove screw of SSD. (2) Remove SSD. SCREW-MACHINE (6001-002795) 1 PCS Torque : 2.3 ~ 2.7Kgfcm Screw - 8 - Mobile communications Division...
- Page 9 1. Main System Confidential Assembly order is reverse of disassembly MAIN 10. (1) Remove the screws on Main board and Hook-PCB. SCREW-MACHIN (2) Remove HOOK-PCB. (6001-002749) 5 PCS (3) Remove Main board. Torque : 2.3 ~ 2.7Kgfcm HOOK -PCB Screw - 9 - Mobile communications Division...
- Page 10 1. Main System Confidential Assembly order is reverse of disassembly 11. (1) Remove the screws on Bracket sub port. (2) Remove Bracket sub port and Sub board. SCREW-MACHINE (6001-002749) 4 PCS Torque : 2.3 ~ 2.7Kgfcm Screw - 10 - Mobile communications Division...
- Page 11 1. Main System Confidential Assembly order is reverse of disassembly 12. (1) Remove screw of ANT. (2) Remove ANT and SPK SCREW-MACHINE (6001-002749) 2 PCS Torque : 2.3 ~ 2.7Kgfcm Screw Screw - 11 - Mobile communications Division...
- Page 12 Confidential 1. Main System – Finger Print Assembly order is reverse of disassembly 13. Finger Print disassembly Remove BRACKET-POWER SCREW (6001-002261) 3 PCS Torque : 2.3 ~ 2.7Kgfcm (2) Remove BRACKET-POWER Disassembled Fingerprint - 12 - Mobile communications Division...
- Page 13 Confidential 1. Main System – Touchpad Assembly order is reverse of disassembly 1. [Touchpad Assy] Disassemble/Reassemble method change ㅁ Disassemble before : Rear Case remove → Battery disconnect → TP screw remove → TP Assy remove ㅁ Disassemble after : Rear Case remove → Battery disconnect → Removable Tape remove → TP Assy remove Screw Removable tape Remove method...
- Page 14 Confidential 1. Main System – Touchpad 2. Introduction of Touchpad removable tape paste ASSY TOUCHPAD-SVC (BA98-03175A/B) Insert from lower side hook of Release paper Bracket Touchpad remove Use Rear disassemble jig remove ASSY TOUCHPAD-SVC Front Check Bracket Touchpad lower side hook insert well Control Up/Down/Left/Right Gap and paste...
- Page 15 Confidential 1. Main System – Touchpad 3. Touchpad Removable Tape paste method introduction Assembly guide (T/P Glass corner) - 15 - Mobile communications Division...
- Page 16 Confidential 2. LCD Disassembly [LCD Assy can’t disassemble] Assembly order is reverse of disassembly SCREW-MACHINE (6001-002795) 4 PCS 15. Remove screws between hinge and case-front. Torque : 2.3 ~ 2.7Kgfcm ASSY COVER-HINGE L BA98-03165A/B ASSY COVER-HINGE R BA98-03166A/B - 16 - Mobile communications Division...
- Page 17 Confidential 2. LCD Disassembly [LCD Assy can’t disassemble] Assembly order is reverse of disassembly 1. Remove the Cover-hinge as arrow direction. - 17 - Mobile communications Division...
- Page 18 3. Cable routing Confidential FINGER PRINT LCD Cable DIG Cable FAN CABLE Antenna Cable SPEAKER -R SPEAKER -L KBD Backlight KBD Membrane MAIN TO SUB Battery Cable TP FFC - 18 - Mobile communications Division...
