1.3 Main Features

Integrated Ethernet MAC, Physical chip and transceiver in one chip
Complies with
100Base-TX and IEEE802.3ab 1000Base-T standard
Compliant to PCI Revision 2.1/2.2
Supports Full Duplex Flow Control (IEEE 802.3x)
PCI local bus single-chip Ethernet controller
Supports ACPI, PCI power management
Supports Auto-Negotiation function, Auto-detects network speed
Contains two large independent receive and transmit FIFOs
One STP/UTP connector
Provides LEDs to indicate network Link/Activity/Speed
Supports smart remote boot ROM
Supports Wake on LAN function
Supports Drivers for NetWare 4.x,5.x,6.x,Windows 98/ME/2000/2003/XP/Vista, Windows NT,
Linux, Dos.

1.4 LED Status

The 1000M Link/Act LED of SMC9452TX-2 indicates Link/Act status when the Adapter works in
the 1000M mode. It will light when connection is built, and glitter when the Adapter is transmitting
or receiving data.
The 100M Link/Act of SMC9452TX-2 indicates Link/Act status when the Adapter is working in the
100M mode. It will light when connection is built, and glitter when the Adapter is transmitting or
receiving data.
SMC9452TX-2
the IEEE802.1P,
Gigabit PCI Ethernet Adapter User Guide
IEEE802.1Q, IEEE802.3
2
10Base-T, IEEE802.3u
