Qolsys IQ Panel 2 Image Sensor ADC-IS-221-LP - Installation Guide
Product summary
The Image Sensor is a pet immune PIR (passive infrared) motion detector with a built-in camera. The sensor is
designed to capture images during alarm or non-alarm events when motion is detected. Users can also initiate image
capture on-demand to Peek-In on their property. Images are stored locally and uploaded either automatically when
motion is captured during alarm events or manually when requested by the user. Once uploaded, images are available
for viewing on the Alarm.com website or an Alarm.com smart phone app. The sensor is battery powered, all wireless,
and simple to install and operate. A subscription to an Alarm.com service package is required.
Highlighted features
• Battery operated
• Communicates wirelessly to the security control panel
• 35 feet by 40 feet detection coverage area
• Configurable PIR sensitivity and pet immunity settings
• Image: QVGA 320x240 pixels
• Color Images (except in night vision)
• Night vision image capture with infrared flash (black & white)
• Tamper detection, walk test mode, supervision
Service package requirement
Image capture features require a service package that includes one of the following Image Sensor add-ons:
• Images - Alarms: Includes upload of images from panel alarm events only.
• Images - Limited: Includes uploads of images from panel alarm events and disarm events.
• Images - Plus: Includes upload of images from panel alarm events, disarm events, and non-alarm events.
For additional information about Image Sensor add-ons, see
https://answers.alarm.com/ADC/Partner/Installation_and_Troubleshooting/Image_Sensor/Image_Sensor_Version_2/Alarm.co...
What do the Image Sensor service packages
include?.
Updated: Thu, 15 Apr 2021 13:54:59 GMT
1
Advertisement
Table of Contents
Related Manuals for QOLSYS ADC-IS-221-LP
Summary of Contents for QOLSYS ADC-IS-221-LP
- Page 1 Qolsys IQ Panel 2 Image Sensor ADC-IS-221-LP - Installation Guide Product summary The Image Sensor is a pet immune PIR (passive infrared) motion detector with a built-in camera. The sensor is designed to capture images during alarm or non-alarm events when motion is detected. Users can also initiate image capture on-demand to Peek-In on their property.
-
Page 2: Hardware Compatibility
Hardware compatibility Qolsys IQ Panel 2 with the Image Sensor daughtercard installed Important: Verify that the Image Sensor daughtercard is Panel installed in the panel. Not all IQ Panel 2s are shipped with the Image Sensor daughtercard installed. If an IQ... - Page 3 Image Sensors remotely, see Enroll an Image Sensor on a Qolsys IQ Panel To enroll the Image Sensor locally on a Qolsys IQ Panel 2: Important: For smoothest installation, learn in one Image Sensor at a time. Insert batteries only after initiating learn mode at the panel.
- Page 4 enrolled in groups 15, 17, 20, 25 or 35. ◦ To change the sensor group after the sensor is enrolled using the control panel: a. Tap Settings. b. Tap Advanced Settings. c. Enter the installer code. d. Tap Installation. e. Tap Devices. f.
- Page 5 4. Choose applicable mounting bracket for customer scenario. ◦ The sensor hardware packet contains two mounting brackets for different mounting scenarios. Use the provided large screws and anchors to attach the bracket to the wall. ◦ Mark location of bracket holes on mounting surface at a height of eight feet for maximum coverage area. ◦...
- Page 6 40%. The signal strength must be greater than 30% for sensor to function properly. Signal strength can fluctuate depending on environmental conditions and interference, so be sure that the signal is consistently in range. To verify signal strength using the Qolsys IQ Panel 2: 1. Tap Settings.
- Page 7 To request test images from the panel: 1. Tap Settings. 2. Tap Advanced Settings. 3. Enter installer code. 4. Tap System Tests. 5. Tap Image Sensor Config. 6. Tap to select View for the Image Sensor in test. 7. Tap Sensor Tests. 8.
-
Page 8: Mounting Guidelines
As indicated in Figure 2, the camera coverage area is narrower than the PIR coverage area. When installing, mount sensor where subjects are likely to be centered in or across PIR and camera field of view. Mounting guidelines Before permanently mounting the Image Sensor, evaluate potential locations and consider the following factors to ensure optimal performance and false alarm protection: •... - Page 9 Additional considerations for Image Sensor mounting • If possible, locate sensor within 100 feet of the panel especially if there are many walls between the sensor and panel, or if the panel and sensor are located on different floors. While the transmitter may have an open air range of 400 feet, installation site conditions can reduce range considerably.
- Page 10 To enter the 3 minute test mode using the IQ Panel 2: 1. Tap Settings. 2. Tap Advanced Settings. 3. Enter the installer code. 4. Tap System Tests. 5. Tap Image Sensor Config. 6. Tap View for the Image Sensor to test. 7.
- Page 11 Service package add-on Includes • Captures motion-activated images while the system is Armed Away to catch potential intruders before the alarm sounds. Continues to capture images until the system is Disarmed. • Captures motion-activated images on an instant alarm (i.e., panic, etc.) or an alarm from Armed Stay after an initialization period (up to a 30 second delay).
-
Page 12: Battery Replacement
1. Insert a paperclip into the hole on the front of the sensor to access the reset button. 2. Press and hold a full 10 seconds until the sensor LED flashes rapidly to reset the sensor and clear it from its network. -
Page 13: Troubleshooting
▪ If the battery type is switched between Ultimate Lithium and Alkaline, verify the battery type is also updated on Alarm.com. This ensures accurate low battery reporting. For more information about updating the battery type, see To update the battery information. - Page 14 closer to the control panel, verify signal strength, and see if communication resumes. If applicable, verify the Image Sensor daughterboard antenna is correctly routed as described in the installation procedure. • Replace batteries: Check the battery level in the panel's Image Sensor menu, and install fresh Energizer Ultimate Lithium batteries if needed.
- Page 15 LED pattern Device status or error Duration of LED pattern Approximately first 5 seconds after Solid for 5 Seconds Sensor Power- Up powering. First 5 seconds after sensor joins a Solid for 5 Seconds Sensor Joins or Rejoins Network new network (during enroll process) or rejoins its existing network.
-
Page 16: Technical Specifications
Technical specifications Alarm.com model number ADC-IS-221-LP Qolsys part number QS9201-1230-84092 Optimal: 2 AA 1.5v Energizer Ultimate Lithium Batteries. Power source Acceptable: 2 AA 1.5v alkaline batteries (battery life may be reduced significantly). - Page 17 6° for large coverage area and rooms greater than 30 ft Recommended mounting angle (“teeth up” on mounting arm); 18° for rooms less than 30 ft (“teeth down” on mounting arm) Normal (up to 30 ft, default) Motion profiles and sensor range High (up to 35 ft) Low (up to 25 ft) https://answers.alarm.com/ADC/Partner/Installation_and_Troubleshooting/Image_Sensor/Image_Sensor_Version_2/Alarm.co…...
