InkSmith Makerforge Quick Start Manual

InkSmith Makerforge Quick Start Guide
1
MOUNT FILAMENT ROLL
Secure the included filament roll holder on
the right side of the machine and place
the filament roll on it.
Note the direction of the filament roll. The
filament line should leave the roll from the
right side. When the filament unrolls, the
roll should unwind in a counter-clockwise
direction.
Mounting the roll properly will help to
avoid extra tension on the filament feeder.
3
START LOADING PROCESS
On the display, select:
Control
Filament
Loading
Start
'Start' will stay greyed out
until the nozzle (EXT) reaches
loading tempurature.
You may have to push the
filament into the extruder until
you can feel it latch on and
pull on its own.
Follow us on social to stay in the know!
Filament line on right side
Double check that the extruder
temperature setting is correct
for the filament you're using.
2
LOAD FILAMENT
Insert the end of the filament into the
silicone hole (A). From the top, reach
in to feed the filament into the sensor.
Pull the filament through the sensor (B)
and gently place into the top hole of
the extruder.
4
START A PRINT
To start your first print, load up
your sliced file onto a USB drive
and insert it into the printer.
On the display screen, select:
File
Your Device
(internal memory or USB)
Navigate to your print file
Start
A
B
