Cubicon Style Plus Quick Start Guide
1
MOUNT FILAMENT ROLL
Secure the included filament roll holder on
the back of the machine and place the
filament roll on it.
Note the direction of the filament roll. The
filament line should leave the roll from the
right side. When the filament unrolls, the
roll should unwind in a counter-clockwise
direction.
Mounting the roll properly will help to
avoid extra tension on the filament feeder.
3
START LOADING PROCESS
On the display, select:
Control
Filament
Loading
Start
Double check that the extruder temperature setting is correct for the
filament you're using.
Follow us on social to stay in the know!
Filament line on right side
3
LOAD FILAMENT
Insert the end of the filament into the
filament feeder up to the dotted line
shown here. This filament feeder will carry
the filament line into the machine and
directly into the extruder.
After starting the loading process in the
next step, it can take about 10 seconds for
the filament feeder motor to finish loading.
Do not forcibly remove the filament
during this process as it can damage the
3D printer.
4
START A PRINT
To start your first print, load up
your sliced file onto a USB drive
and insert it into the printer.
On the display screen, select:
File
Your Device (internal
memory or USB)
Navigate to your print file
