Cubicon Single Plus Quick Start Guide
1
Setup filament skates
Locate the two filament "skates" from your
printer's kit and set them to the right of the
printer. Place the spool on the skates as
shown.
Note the direction of the filament roll. The
filament line should leave the roll from the
back side.
Insert the filament into the tapered input
port at the upper-rear of the circular
compartment.
3
START LOADING PROCESS
On the display, select:
Filament
PLA (default)
Loading
Wait for heating
Start
Double check that the material setting
matches the filament you are loading.
Follow us on social to stay in the know!
Filament line on back side
5
3
LOAD FILAMENT
Continue feeding the filament by hand
until it emerges from the translucent white
tube inside the machine.
Insert the filament into opening on the top
of the extruder.
Hold down the release paddle on the left
side of the extruder, and push the filament
in until it stops.
4
START A PRINT
To start your first print, load your
sliced file onto a USB drive and
insert it into the printer.
On the display screen, select:
File
USB
Select your print file
Start
