- Page 1 Installation Manual Orbital Tank (OT8911-E) 5-06-0037 Publication date 2025-01-28...
- Page 2 All rights reserved. No part of this document may be reproduced or copied in any form or by any means without written permission from Orbital Systems. The English language version of this document contains the original instructions. All other language versions are translations of the original instructions.
-
Page 3: Table Of Contents
Table of Contents Thank you for your purchase ....................4 Service ..........................4 System overview ........................5 Technical specification ......................6 Installation requirements ....................... 7 Wall installation ........................8 Seal mountings in wet zone ..................8 Component overview ......................9 Product measurements ....................... -
Page 4: Thank You For Your Purchase
Repairs should only be carried out by Orbital Systems. If the supply cord is damaged, it must be replaced by Orbital Systems to avoid a hazard. Contact us • support@orbital-systems.com •... -
Page 5: System Overview
System overview Tank Pump Page 5 of 28... -
Page 6: Technical Specification
Technical specification General performance Savings rate: Up to 100% water savings of water used in sink Size and weight Tank: 440 x 270 x 65 mm, 1.2 kg Pump: 197 x 296 x 140 mm, 3.5 kg AC/DC power 152 x 63 x 30 mm, 420 g supply: Water supply Incoming Cold... -
Page 7: Installation Requirements
Installation requirements B = max. 6m A. The bottom valve outlet must be placed higher than the inlet on the Tank (minimum 1% inclination). B. The Pump and toilet can be placed at a maximum distance of 6 meters. The Pump should not be placed at a higher position than the Tank. -
Page 8: Wall Installation
Wall installation The total weight of all components is approximately 10 kg when the Tank is filled with water. The surrounding structure must be able to support the forces that will stress the attachment points. Seal mountings in wet zone Seal the drill holes in accordance with applicable industry standards. -
Page 9: Component Overview
Component overview Tank with fastening kit Pump with wall bracket and fastening kit AC/DC power adapter Cable organizer Bottom valve Bottom valve flange Fresh Mesh Bottom valve outlet Additional components needed: • Wall socket 220 V, x1 • Flex hose G 1/2" to 3/8", x1 •... -
Page 10: Product Measurements
Product measurements 65 mm 270 mm 30 mm 63 mm Ø 32 mm 140 mm 296 mm Page 10 of 28... -
Page 11: Recommended Installation Measurements
Recommended installation measurements Ø 45-55 mm min. 400 mm min. 65 mm A = Area with open surface for mounting the wall mounted components. 600 mm 400 mm Ø40 mm 60 mm 130 mm B = Area where the electrical outlet can be placed. C = Area where the drain, hot and cold incoming water and toilet connection can be placed. - Page 12 NOTE The recommended commode height of 600 mm is only applicable for complete coverage of the components. You can use a commode with a lower height without affecting the product's functionality. Page 12 of 28...
-
Page 13: Installation
Installation In the scenario displayed in this manual, the commode is 600 mm wide. Prepare bathroom Prepare the installation area for incoming hot and cold water, drain, and electricity. B = Area where the electrical outlet can be placed. 600 mm Ø40 mm 60 mm Install the connection to the toilet cistern. - Page 14 Apply wall covering, tiling, and commode according to industry rules and the supplier's instructions. Page 14 of 28...
-
Page 15: Install The Bottom Valve Outlet
Install the bottom valve outlet Place the bottom valve flange in the sink. Mount the bottom valve outlet. Page 15 of 28... - Page 16 Place the bottom valve with the Fresh Mesh in the bottom valve flange. Page 16 of 28...
-
Page 17: Install Tank
Install Tank Before drilling, make sure the components fit and that the overflow outlet on the Tank is located at a higher point than the drain. >0 mm Pre-drill holes for the Tank fastening kit. CAUTION • The length of the plugs is 40 mm. Adapt placement according to the piping. - Page 18 Insert the plugs, screws, and the long spacers. 4. Attach the Tank. Add the thin washers, and secure with the nuts. Page 18 of 28...
-
Page 19: Install Pump
Install Pump Measure and pre-drill holes for the wall bracket. Insert the plugs and screw the wall bracket in place. Page 19 of 28... - Page 20 Attach the Pump by threading the back piece onto the bracket from the left and sliding the Pump in place. 4. Lock the Pump in place by tightening the screw on the left side with a straight 4 mm Allen key. Add the rubber plug to cover the hole. Page 20 of 28...
-
Page 21: Connect To Water And Drain
Connect to water and drain Install the mixer (not included with Orbital Tank) according to the supplier's instructions. Connect incoming hot and cold water to the mixer, and incoming cold water to the tank (3/8"). Connect the Tank to the Pump, and the Pump to the toilet. Page 21 of 28... - Page 22 Connect the sink's bottom valve outlet to the Tank. Proceed by connecting the outlet of the Tank to the drain. Page 22 of 28...
-
Page 23: Connect All Components
Connect all components Attach the AC/DC power adapter in an available space using two screws. Connect the power adapter to the Tank. Page 23 of 28... - Page 24 Connect the Tank to the Pump. 4. Mount the cable organizer in a suitable place in the commode and attach the cables. Page 24 of 28...
- Page 25 Connect the power adapter to the socket. When the system is connected to power, the Tank will fill up about 4 dl of water, to make sure there is water to flush with even if the faucet has not been used. Flush the toilet twice to ensure the Pump starts and the toilet cistern is refilled.
-
Page 26: Prerequisites And Approvals
Board of Housing and Building & Planning regulations (BBR). Orbital Tank is CE-marked based on certificate and test reports from third party labs. If industry regulations and instructions in this manual are followed, Orbital Systems guarantees a functional system. Page 26 of 28... -
Page 27: Eu Declaration Of Conformity
EN IEC 61000-6-4:2019 EN 60335-1:2012;A11;A13;A1;A14;A2;A15 EN IEC 61000-6-2:2019 ETSI EN 301 489-1 V2.2.3 EN 62233:2008 EN IEC 61000-6-3:2021 ETSI EN 301 489-17 V3.2.4 Signed for and on behalf of Orbital Systems AB Place Date Name Position Malmö 2024-04-08 Mehrdad Mahdjoubi... - Page 28 C E R T I F I E D S P A C E T E C H N O L O G Y...
