DT Research ACC-001-64 Basic Operation Manual

Battery Holster
BASIC OPERATION GUIDE
Thank you for purchasing the Battery Holster by DT Research.
The Battery Holster (ACC-001-64) is designed to be a charging
case as well as a portable power bank while three fully-charged
DR202 batteries (optional) are stored inside. The package
includes one Battery Holster which features three battery slots
with lockable gate as well as three DC-out connectors, one
holder and three cables.
Instructions:
Insert the DR202 batteries inside the Battery Holster one by
one in the correct direction and lock the lid. To use as a portable
power bank, connect the cable(s) to the Battery Holster and the
DT Research product and/or the peripheral(s).
To use the external LED indicator, connect the indicator's cable to
the Battery Holster. Make sure the pins are connected properly.
A�er connecting the cable(s) to the Holster, you may also attach
the cable holder onto the bottom of the Holster to fix the cable(s).
CAUTION:
This Battery Holster must only be used with the specific DR202 battery, DT Research product
models and peripherals for which it is designed. Failure to do so may result in tablet or charger
damage, or personal injury.
Package Contents:
1. Battery Holster with bracket
2. External LED indicator
3. Cables and the holder
4. Basic operation guide
5. AC-DC Power Adapter with
Power Cord
