DT Research 507T Basic Operation Manual

I/O Ports

The Medical-Grade Integrated LCD System has a comprehensive set of I/O ports. The following
ports are located along the bottom side of the unit.
Front
Bo�om
A B C D E
A F
Power button USB 3.0 ports
B Programmable buttons G Ethernet ports (RJ45)
C Speakers H Audio jack
DC-in USB 2.0 ports
D I
E HDMI output COM ports
J
Potential equalization
K
conductor (optional)

Cleaning the Screen

• A screen cleaning solution that is alcohol-free and non-abrasive can be used to clean the
touch screen.
• Cleaning with a micro-fiber cloth is recommended.
• Please spread the solution onto the cloth and then clean the touch screen.

Cleaning the Anti-microbial Enclosure

• Use a soft/non-abrasive cloth moistened with water to clean the enclosure.
• If using a cleaner, an alcohol-free and oxide-free cleaning liquid is recommended.
• To prevent scratching the anti-microbial coating, please wipe gently.
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131
Copyright © 2021, DT Research, Inc. All Rights Reserved.
signage dtri com
Back
F G H I C J K
BOG081621 504T/ 507T ENG
Medical-Grade Integrated LCD System
504T/ 507T

INTRODUCTION

Thank you for acquiring DT Research's Medical-Grade Integrated LCD System. With a 23.8-
inch or 27-inch TFT display and powered by the Intel® Core™ i processor, the Medical-Grade
Integrated LCD System offers optimal combinations of performance and power savings. With
fully-integrated point-of-care modules within an elegant, space-saving design, the Medical-Grade
Integrated LCD System is the optimum solution to enhance workflow and service.
Please take a few moments to review the contents of this document to ensure that the setup
and startup proceed smoothly. The Medical-Grade Integrated LCD System is ready for use, out of
the box, in its default configuration when powered by the power source provided. The following
documentation offers guidance on the hardware elements and features of the computer. Please
refer to your device provider for information pertaining to the software operating system or
software applications.

PACKAGE CONTENTS

• 504T/ 507T
• AC-DC power adapter with power cord
• Basic operation guide
MEDICAL – GENERAL MEDICAL EQUIPMENT
AS TO ELECTRICAL SHOCK, FIRE AND MECHANICAL
HAZARDS ONLY IN ACCORDANCE WITH ANSI/AAMI
ES60601-1 (2005) + AMD (2012) & "CAN/CSA-C22.2
No. 6060-1 (2008) + (2014)
