Quick Start Guide
General Information
Read the instructions before commencing installation. The user is to retain the instructions for future reference.
• Espire Alarms have been designed and developed for fixed residential installation and use.
• After installation the Alarm is to be tested weekly: Press and hold the Test/ Hush button for at least 10 seconds to ensure the Alarm sounds and all
interconnected Alarms activate.
Product Description
• ES1CL Carbon Monoxide Alarm Powered by
a 10 Year Lithium Battery
• ES1CHL Carbon Monoxide and Heat
Multi-Sensor Alarm Powered by a 10 Year
Lithium Battery
The Alarm head must be fitted onto the supplied
Lock-In Base.
The RF-Link (ES1RF2) module is supplied with
the Alarm or available separately.
The Alarm battery is sealed and non-replaceable.
Alarm Installation
Step 1.
Using the base, mark the desired mounting
holes, drill and re-align the base, screwing into
place. Multiple mounting holes are available for
retro fit installations.
Alarm Testing
Test the Alarm after installation, and
weekly thereafter.
The CO Alarm's response times are designed to
act in accordance with BS EN 50291-1:2018;
Parts per Million
Time until Alarm
(PPM) of CO
50 60-90 minutes
100
Must alarm in less
300
than 3 minutes
Step 2.
Carefully line up the Alarm to the base and slide
on until secured and a 'click' is heard.
Step 1.
Press and hold the Test/Hush button for a
minimum of 10 seconds.
Alarm Powered by a Lithium Battery
with Optional RF-Link Module
Red Alarm LED
Sensor
Tunnel
10-40 minutes
Green Power LED
Step 3.
After the Alam is secured to the base the
CO Alarm will initiate a 3 minute self-test
on power up.
Step 2.
The Alarm will sound and the Red LED will flash,
the Green and Amber LED will also be visible.
ES1CL, ES1CHL
Amber
Fault LED
Test/Hush
Button
Sounder
