Wine racks America GRANDCELLAR Large Format Cubbies Assembly Manual

888.373.6057
Top Piece
Side Panel
Before you Begin
• Recomeneded 2-person assembly
• Read all instructions before assembly
• Inspect all parts for damage and missing parts before assembly
• Please verify you have the correct parts and quantity of hardware before proceeding
• Open package in a clean, flat area
• Carefully remove all components from the box and remove banding or protective wrapping
• If parts are missing or broken, please contact our customer service department at 1(888) 373-6057
• The hardware quantities listed above are required for proper assembly Some extra hardware may
also have been included
Objects measuring over 36 inches in height, whether they stand alone or are stacked, must be
!
securely attached to the wall to prevent potential shifting or tipping. It is also recommended to
use screws or finish nails to join stacked units together.
Package Contents
Wood Screw - Actual size
1-6 columns (12X)
7-8 columns (18X)
Top and Bottom Piece (2X)
wineracksamerica.com
Large Format Cubbies
|
Assembly Guide
Bottom Piece
Side Panels (2X)
Center Divider. (7-10 columns) (1X)
Part #: INFOGCHCM
Side Panel
Center Divider
REQUIRED
Screwdriver
SUGGESTED
Cordless Drill
7/64" Drill Bit
Recommended for drilling
pilot holes for all screws
to avoid splitting wood
Page 1
