2. Hardware Installation
Adapter Configuration
32/16MB SGRAM on board
TV-Out encoder chip(Optional)
Composite output(Optional)
Bios
S-Video output(Optional)
To monitor
NTSC Jp1, Jp2;2-3 Short
PAL
Jp1, Jp2;1-2 Short
Riva TNT2 VGA chip set
32MB SDRAM on board
TV-Out encoder chip(Optional)
Composite output(Optional)
S-Video output(Optional)
Bios
To monitor
NTSC Jp1, Jp2;2-3 Short
J
PAL
p1, Jp2;1-2 Short
Riva TNT2 VGA chip set
MVGA-NVTNT2A
1 3
Jp2
MVGA-NVTNT2AL
3
HARDWARE INSTALL
