Summary of Contents for Trailer Valet STJS0010
- Page 1 STJS0010 Stabilizer Jack OPERATING MANUAL Rev 12.13.24...
-
Page 2: Table Of Contents
Failure to follow these guidelines may result in serious injury to persons and property for which Trailer Valet will not be held liable. Do not allow persons to operate or assemble this unit until they have read this manual and have developed a thorough understanding of how the unit works. -
Page 3: Important Safety Information
Product Dimensions (with Brackets Fully Extended): 14”x 6.3” x 77.2” Height Range: 6.3” to 26.6” There is no lifting weight capacity since the stabilizer jack should not be used for lifting The Trailer Valet StabilizerJack 1. Adjustable Mount Bracket 2. Position Locking Screw 3. -
Page 4: Assembly
Assembly STEP 1: Unpack and inspect the Stabilizer Jack before it is installed. If there is any shipping damage to the stabilizer jack, do not install it and contact the factory. STEP 2: Inspect and identify a section of the trailer frame where the Stabilizer Jack will be installed. - Page 5 Assembly STEP 8: Once a jack leg is selected, use the drill to raise the Stabilizer Jack close to the frame. Repeat for the jack leg on the other side. STEP 9: Raise the Stabilizer Jack up until it barely touches the frame. STEP 10: Use the proper bolts and fastening hardware to loosely connect the Stabilizer Jack mounting brackets to the frame.
-
Page 6: Operating Instructions
operating instructions OPTION 1: MANUAL OPERATION STEP 1: Attach the Hand Crank to the driveshaft located at the top of the unit. Turning the handle clockwise will extend the jack. Turning the handle counter-clockwise will retract the jack. STEP 2: Lower the drop leg as needed for additional extension of the jack. OPTION 2: DRILL OPERATION WITH THE DRILL ADAPTER STEP 1: After installation, shift the drive shaft to select a jack leg. -
Page 7: Limited Manufacturer's Warranty
WHATSOEVER CAUSED, INCLUDING THE REPLACEMENT OF EQUIPMENT AND PROPERTY. CUSTOMER RESPONSIBILITIES: Customers may be required to provide proof of purchase date, respond to questions designed to assist with diagnosing potential issues, and follow Trailer Valet’s directions to make a claim on your warranty. TO MAKE A WARRANTY CLAIM:... -
Page 8: Email: Support@Trailervalet.com
Copyright 2024 by Supertech S. Corporation. All rights reserved. No portion of this manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Supertech S. Corporation. For further information or if you have any questions, please contact: SUPERTECH S.
