Check that you have all your
parts and accessories.
DRILL ATTACHMENT
JX2-C UNIT
ROTATION PIN
CRANK HANDLE
JX5-C UNIT
JX2-C
FOOTPLATE
1.
Detach footplate and install
Center Jack into trailer coupler
(bolts included)
JX5-C
1.
Detach footplate and install
Center Jack into trailer coupler
(bolts included)
To use the JX with a drill, read the manual for
step-by-step instructions. For supporting
documents, visit us at
MANUAL
TRAILER VALET JX SERIES
Quick Start Guide
Top View
2.
Attach footplate and the crank
handle
Top View
2.
Attach footplate and the crank
handle
support.trailervalet.com.
3.
Extend jack and start lifting!
*Please note that the max
extension is 14 in (35.5 cm).
3.
Extend jack and start lifting!
*Please note that the max
extension is 14 in (35.5 cm).
Scan the QR code to access some
helpful videos to help you get started
and #MoveForward.
