Specifications - Rich Solar ALPHA 5 PRO User Manual

2. Compact series features
Cathode material is made from LiFePO4 with safety performance and long cycle life;
●
Battery management system (BMS) has protection functions including over-discharge,
●
over-charge, and over-current and high/low temperature;
The system can automatically manage charge and discharge state and balance current and
●
voltage of each cell;
Adopted self-cooling mode rapidly reduced system entire noise;
●
The module has less self-discharge, up to 3 months without charging it on shelf, no memory
●
effect, excellent performance of shallow charge and discharge;
The working temperature range is from -20℃ to 60℃ (-4℉ to 140℉), the charging temperature
●
range is from 0℃ to 60℃ (32℉ to 140℉), and the discharging temperature range is from -20℃ to
65℃ (-4℉ to 149℉). The battery offers excellent discharge performance and an extended cycle
life.
Equipped with monitoring LCD display, can provide basic data visualization, more convenient for
●
users to observe the operation of the system.

3. Specifications

452.0
465.0
479.1
496.6
Outline dimensional drawing
80.0
-07-
