ITEM Name
Communication
6
Cable
Parallel
7 Communication
Cable
Mounting
8
Screws
9 User Manual

2. Installation location

Make sure that the installation location meets the following conditions:
The area is completely water proof.
●
The floor is flat and level.
●
There are no flammable or explosive materials.
●
The ambient temperature is within the range from 0°C to 50°C (32℉ to 122℉).
●
The temperature and humidity is maintained at a constant level.
●
There is minimal dust and dirt in the area.
●
The distance from heat source is more than 2 meters
●
The distance from air outlet of inverter is more than 0.5 meters.
●
Do not install outside directly
●
Do not cover or wrap the battery case or cabinet.
●
Do not place at a children or pet touchable area.
●
The installation area shall avoid of direct sunlight.
●
There is no mandatory ventilation requirements for battery module, but please avoid of installa-
●
tion in confined area. The aeration shall avoid of high salinity, humidity or temperature.
ADC isolator is recommended to be add on the power circuit between inverter and battery,
●
recommended rating at 120Amps per set of external power cable.
CAUTION
If the ambient temperature is outside the operating range, the battery pack stops operating to
protect, itself. The optimal temperature range for the battery pack to operate is 0°C to 50°C (32℉
to 122℉). Frequent exposure, to harsh temperatures may deteriorate the performance and life of
the battery pack.
Specifications
Connects Battery to Other Brand Inverters
L=59.06in_Grey, FOR PCS
Connects Battery to Battery
L=9.84in_Black
SUS304_M5x12_triple combination machine
tooth screw
ALPHA 5 PRO Manual
-20-
Unit QTY Remark
PCS 1
PCS 1
PCS 6
PCS 1
