- Page 1 Install Guide RPS-500S | RPS-500S-BASIC | RPS-500L RPS-500-CSB55 | RPS-500-CSB70...
-
Page 2: Package Contents
PACKAGE CONTENTS * RPS-500-CSB55/70 does not include the following parts: J, K, L, M, N * RPS-500S-BASIC does not include the following parts: F, G, J, K, L, M, N, Included with RPS-500 Carts: x2-4 A. Leg [x2] G. 10/32 Rack screw [x4] M. - Page 3 (C) using [x3] washers (E) and [x3] screws (D) for each union. STEP 3 Skip this step for RPS-500S-BASIC. Attach shelf to rack rails • Attach [x1] shelf (F) to the rack rails with [x4] rack screws (G).
- Page 4 • Secure the display mount (H) to the front of the cart as shown using the [x4] UM kit (I). STEP 5 For RPS-500-CSB55/70 and RPS-500S-BASIC, skip to step 7. Attach brackets to display mount • Attach [x2] brackets (J) to the center back of the display mount (H) using [x4] philips head screws (K) and [x4] washers (L).
- Page 5 STEP 6 Attach camera mount to display mount • Attach [x1] camera mount (M) to brackets (J) using [x4] screws (K), [x8] washers (L) and [x4] nuts (N). STEP 7 Attach uprights to display • Using the display mount hardware, bolt the uprights (O) to the rear of the display.
