- Page 1 Easy Setup Guide RPS800...
- Page 2 Items Included Body (x1) (x1) Camera Support Acrylic Platform (x1) Caster Braker Caster (x2) Handle (x2) (x2) Support (x1) Base (x1) Screw Screw 1/4x3/4 Flange Nut (x2) 5/16x1” 1/4” 1/4” (x4) (x4) Acorn Nut 1/4” (x4) Washer Washer Socket Flat Head Regular Nut (x4) 1/4”x3/4”...
- Page 3 Place body(A) on base lining up bolts on base with holes on body(A), then secure the joint using ange nuts. Assemble Casters (I , J) to base (B). Two in front with brake and two in the back without brake. Assemble Acrylic Slide Camera Support (C) Platform (D) to...
- Page 4 Adjust Camera Support (C) height according to the size of your TV and then secure the position using two 1/4”x3/4” srews Refer to wall mount intructions. Assemble the handles (F) to the support (E) Hang the TV to the using the screws on the handle and 4 ang Support (E) nut (K).
- Page 5 Lock Assembly Pull Cilinder Slide Pull over Cylinder. The Flange must be as shown in the diagram Slide Cylinder through hole in glass as shown in diagram Twist Nut onto Cylinder as shown in diagram. Ensure that it’s placed in the correct posi- tion as shown in diagram.
