Tactile Medical AffloVest Quick Start Manual

AffloVest Quick Start Guide
®
T H E B AT T E R Y M U S T B E F U L LY C H A R G E D B E F O R E F I R S T U S E
Use only the supplied rechargeable battery and the supplied power supply to ensure safe and reliable operation of AffloVest.
1
U NPACK AFF LOV ES T
Unpack the AffloVest and its accessories.
2
C H E C K / C H A R G E T H E B AT T E R Y L E V E L
To check the battery level, depress the battery level push button
to activate the battery level LEDs (Fig. 2-1). To charge the battery,
connect the power supply to a wall outlet and plug the power supply
plug into the battery port, into the small opening at the bottom of the
battery pouch (Fig. 2-2). The power
connected to the wall outlet (Fig. 2-3).
3
STAR T THER APY
Put on the AffloVest and buckle closed. To power on the AffloVest,
press and hold the
NAV I GATING THE CO NT ROLLER
To power On/Off. Press and hold the
Treatments may be started at any time by pressing the
the main treatment menu.
• While treatment is running, AffloVest may be paused by pressing the
button. This shall suspend treatment until the
GO will automatically start the Go Mode, the system will perform the following treatment
sequentially (by default):
• Percussion Mode, 10-minute duration at medium intensity (followed by a 10 second pause).
• Vibration Mode, 10-minute duration at medium intensity (followed by a 10 second pause).
• Drainage Mode, 10-minute duration at medium intensity.
I M P O R TA N T — R E A D T H I S F I R S T
supply LED will turn on when
GO
button. Press button to start therapy.
(Standby) button on the controller.
(Play/Pause) button is pressed again.
(Play/Pause) button from
(Play/Pause)
Fig. 2-1
Battery level
push button
Fig. 2-2
Power supply
connected to
battery
Fig. 2-3
Power supply
LED lit
