T
ECHNICAL
Chassis Specs
Capacity: 12 slots – up to 12 converters
Chassis: Aluminium, Steel
Power: Up to two load sharing, hot swappable power supplies
LEDs: 3 Red for fan status,
12 Green for slot power status,
1 Red for each power supply.
Cooling: Three 42.5 cfm rear-mounted fans
Dimension: 440 x 290 x 133 mm (L x W x H)
Weight: 7.6 kg (with one power supply)
Power Supply Specs for AC
AC input: 100 ~ 240V AC @ 47 ~ 63Hz
DC Output: Norm. +12V, Min. +11.88V, Max +12.12V, 75Watts
Load: Min. OA, Full. 6.4A
Total Reg.: +/- 1.0%, Rip. 120mV, Load 2.0%, Line 0.5%
Overload Protection: All outputs protected against short circuit
conditions, automatic recovery
Over volts Protection: Output level exceeding + 13.2V causes
shutdown – automatic recovery
(EIA 3U)
13 kg (loaded with 12 standalone converters)
S
PECIFICATIONS
19
