Installing the converter
Once the converters have been attached to the brackets, it can be
installed into the Chassis. The converters can go into the Chassis
in any order and can be placed in any available slot. Special care
must be taken to ensure the correct mating of the power connector.
Choose an available slot and align the converter so that it fits
between the upper and lower guide rails.
12-slot Media Converter Chassis
If necessary, you may gently move the converter up & down
or left & right to ensure that the plug and socket align correctly.
Warning
Always ensure that the converter's power socket
is positioned at the base of the Chassis.
Warning
Never force the converter into the Chassis – check
power socket position and alignment.
Installing the converter
7
