Installation Guide
5-Port Gigabit Ethernet PoE+ Unmanaged
Essentials Switch (63W)
Model GS305Pv3
5-Port Gigabit Ethernet PoE+ Unmanaged
Essentials Switch (83W)
Model GS305PPv3
Package contents
•
Model GS305Pv3 or GS305PPv3 Unmanaged Essentials Switch
•
DC power adapter
•
Detachable power cable (varies by region)
•
Wall-mount kit screws
•
Four rubber footpads
•
Installation guide
NOTE: We recommend that you use a Category 5e (Cat 5e) cable or a higher
rated cable for Gigabit Ethernet connections.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for NETGEAR GS305Pv3
Summary of Contents for NETGEAR GS305Pv3
- Page 1 Essentials Switch (63W) Model GS305Pv3 5-Port Gigabit Ethernet PoE+ Unmanaged Essentials Switch (83W) Model GS305PPv3 Package contents • Model GS305Pv3 or GS305PPv3 Unmanaged Essentials Switch • DC power adapter • Detachable power cable (varies by region) • Wall-mount kit screws •...
-
Page 2: Register The Switch
From a computer or mobile device that is connected to the Internet, visit my.netgear.com. Log in to your NETGEAR account. NOTE: If you don’t have a free NETGEAR account, you can create one. The Your Registered Products page displays. Click the REGISTER NEW PRODUCT button. -
Page 3: Connect To Power And Check The Leds
The switch provides PoE+ or PoE power on ports 1–4 up to 30W PoE to each port. Model GS305Pv3 provides a PoE power budget of 63W across all active PoE ports. Model GS305PPv3 provides a PoE power budget of 83W across all active PoE ports. - Page 4 Description Power LED On. The switch is receiving power. Off. The switch is not receiving power. Ports 1–5 On.1 Gbps link on this port. left LED On. 100 Mbps or 10 Mbps link on this port. Blinking. 1 Gbps activity on this port. Blinking.
- Page 5 (from port 1 to port 4), with a total power budget of 63W for model GS305Pv3 and 83W for model GS305PPv3. If the power requirements for the attached powered devices (PDs) exceed the total power budget of the switch, the PD on the highest-numbered port is disabled to make sure that the PDs that are connected to the higher-priority, lower-numbered ports are supported first.
-
Page 6: Mount The Switch On A Wall
Model GS305Pv3: 67.5W maximum; 1.02W standby Model GS305PPv3: 90.0W maximum; 1.01W standby PoE power budget Model GS305Pv3: 30W maximum per PoE+ port with a total PoE power budget of 63W for the switch Model GS305PPv3: 30W maximum per PoE+ port with a... - Page 7 Support and Community Visit netgear.com/support to get your questions answered and access the latest downloads. You can also check out our NETGEAR Community for helpful advice at community. netgear.com. Regulatory and Legal Si ce produit est vendu au Canada, vous pouvez accéder à ce document en français canadien à...
