Freestanding gas range
Hide thumbs Also See for NX58M9960P Series:
Table of Contents

Advertisement

Quick Links

Download this manual
GAS RANGES
FREESTANDING
GAS RANGES
MODELS AND
MODEL CODES:
NX58M9960P*
1.
Precautions
2. Specifications
3. Disassembly and Reassembly
4. Troubleshooting
5. PCB Diagrams
6. Schematic Diagrams
CONTENTS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NX58M9960P Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung NX58M9960P Series

Summary of Contents for Samsung NX58M9960P Series

  • Page 1 FREESTANDING GAS RANGES MODELS AND MODEL CODES: NX58M9960P* GAS RANGES CONTENTS Precautions 2. Specifications 3. Disassembly and Reassembly 4. Troubleshooting 5. PCB Diagrams 6. Schematic Diagrams...

  • Page 2: Table Of Contents

    • Contents 1. Precaution ................4 1-1 Forward .
  • Page 3 • Contents 4. Troubleshooting ............... .63 4-1 Failure Display Codes .

  • Page 4: Precaution

    • When the oven operates, the interior parts will be very hot. SAMSUNG Electronics assumes no responsibility for any repairs made on our products by anyone other than licensed technicians.

  • Page 5: Important Safety Instructions

    This document can not be used without Samsung’s authorization. 1. Precautions 1-3 Important Safety Instructions Read and follow all instructions before using or servicing the range to prevent death, personal injury, fire, explosion, and/or property damage. This guide does not cover every possible condition that may occur. For further assistance, contact a licensed technician or the manufacturer.

  • Page 6: Surface Burners

    This document can not be used without Samsung’s authorization. 1. Precautions SURFACE BURNERS • Use Proper Pan Size – This appliance is equipped with CAUTION one or more surface burners of different sizes. Select utensils having flat bottoms large enough to cover Do not store items of interest to children in the surface burner flames.

  • Page 7: Self-Clean Ovens

    This document can not be used without Samsung’s authorization. 1. Precautions SELF-CLEAN OVENS • Important Instruction – In the event the self-clean mode “F” code goes on or three long beeps sound, the oven is malfunctioning in the self-clean mode.

  • Page 8: Specifications

    This document can not be used without Samsung’s authorization. 2. Specifications 2-1 Features & Accessories Oven Features Surface burner Oven burner knobs Surface burners knobs(4 pcs) (mode, temperayure)(2 psc) Oven vent cover Cololing vent Removable oven door Kick panel Broil oven burner...
  • Page 9 This document can not be used without Samsung’s authorization. 2. Specifications Features & Accessories Oven Control Bake Broil Cancel the current operation. Bake food evenly using the Broil food using the upper oven lower oven burner. burner only. Roast Convection Bake...
  • Page 10 This document can not be used without Samsung’s authorization. 2. Specifications Features & Accessories Gas Cooktop LIGHTING A GAS SURFACE BURNER Make sure all surface burners are properly installed. 1. Push in and turn the control knob to the LITE position.

  • Page 11: Table Of Specifications

    This document can not be used without Samsung’s authorization. 2. Specifications 2-2 Table of Specifications Basic Model NX58K9850S*(Single mode) NX58M9960P* Color * = S,G(Stainless Steel, Black CMF) * = S,M(Stainless Steel, Matte Black) Controls Control Type - Oven Glass Touch...
  • Page 12 This document can not be used without Samsung’s authorization. 2. Specifications Table of Specifications Basic Model NX58K9850S*(Single mode) NX58M9960P* Cooktop Cooktop Type Stainless steel Stainless steel Number of Burners Total Power (BTU) 61,000 57,000 Right Front (BTU) 22,000 (Dual) 22,000 (Dual)
  • Page 13 This document can not be used without Samsung’s authorization. 2. Specifications Table of Specifications Basic Model NX58K9850S*(Single mode) NX58M9960P* Drawer Drawer capacity (cu.ft) Type Storage Kick Panel Drawer Heater Performance Warm. Drawer Temp. Settings Warm. Drawer Handle Accessories/Others Anti-Tip Device...
  • Page 14 This document can not be used without Samsung’s authorization. 2. Specifications Table of Specifications Basic Model NX58K9850S*(Single mode) NX58M9960P* Colour Stainless Steel Stainless Steel Controls Control Type - Oven Membrane Membrane + Film Touch Control Type - Cooktop Weighted Knob...
  • Page 15 This document can not be used without Samsung’s authorization. 2. Specifications Table of Specifications Basic Model NX58K9850S*(Single mode) NX58M9960P* Cooktop Cooktop Type Porcelain Enamel (Black) Porcelain Enamel (Black) Number of Burners Total Power (BTU) 56,000 58,500 Right Front (BTU) 17,000 (Single)
  • Page 16 This document can not be used without Samsung’s authorization. 2. Specifications Table of Specifications Basic Model NX58K9850S*(Single mode) NX58M9960P* Drawer Drawer capacity (cu.ft) Type Storage Storage Drawer Heater Performance Warm. Drawer Temp. Settings Warm. Drawer Handle Accessories/Others Anti-Tip Device Yes (Leg Brackets)

  • Page 17: Accessories

    This document can not be used without Samsung’s authorization. 2. Specifications 2-3 Accessories Item Description Code No. Quantity ASS’Y GRATE SIDE DG94-02209A (LEFT) ASS’Y GRATE SIDE DG94-02210A (RIGHT) ASS’Y WIRE RACK DG94-01486A RACK WIRE DG67-00124A ASS’Y Grate DG94-01517A Front Leg Cover...

  • Page 18: Disassembly And Reassembly

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3. Disassembly and Reassembly 3-1 Tool for assembly and disassembly Item How to use Pictures Screw Driver Use for assembly and disassembly of all screws Use for assembly and disassembly of tubing to...

  • Page 19: Basic Replacement Step

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-2 BASIC REPLACEMENT STEP WARNING Disconnect power before servicing the range. Replace all panels before operating range. Failure to do so can result in death or electrical shock.
  • Page 20 This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly BASIC REPLACEMENT STEP WARNING Disconnect power before servicing the range. Replace all panels before operating range. Failure to do so can result in death or electrical shock.

  • Page 21: Ass'y Frame Cooktop

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly BASIC REPLACEMENT STEP Parts Explanation Photo Explanation 8. Pull the side chassis panels backward and remove them with rolling each of them inward Remove 4 screws from the frame cooktop.

  • Page 22: Ass'y Control Box

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly BASIC REPLACEMENT STEP WARNING Disconnect power before servicing the range. Replace all panels before operating range. Failure to do so can result in death or electrical shock.
  • Page 23 This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly BASIC REPLACEMENT STEP Tip for assembly ASSY Control Box. (1) Disassembly 5 screws of Assy Cooktop/Assy Cooktop sub first. (2) Assembly Assy Control Box by Hold ing at supporter of Assy Cooktop sub careful to correct center hook.
  • Page 24 This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly BASIC REPLACEMENT STEP WARNING Disconnect power before servicing the range. Replace all panels before operating range. Failure to do so can result in death or electrical shock.
  • Page 25 This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly BASIC REPLACEMENT STEP WARNING Disconnect power before servicing the range. Replace all panels before operating range. Failure to do so can result in death or electrical shock.
  • Page 26 This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly BASIC REPLACEMENT STEP WARNING Disconnect power before servicing the range. Replace all panels before operating range. Failure to do so can result in death or electrical shock.
  • Page 27 This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly BASIC REPLACEMENT STEP WARNING Disconnect power before servicing the range. Replace all panels before operating range. Failure to do so can result in death or electrical shock.
  • Page 28 This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly BASIC REPLACEMENT STEP Parts Explanation Photo Explanation Follow the Step A, B, C, E and F.(E should be done before F). Remove 7 screws from guide cooktop rear and 2 screws from cooling motor.

  • Page 29: Component Replacement Step

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-3 COMPONENT REPLACEMENT STEP WARNING Disconnect power before servicing the range. Replace all panels before operating range. Failure to do so can result in death or electrical shock.

  • Page 30: Main Pcb & Sub Pcb

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-4 MAIN PCB & SUB PCB WARNING Disconnect power before servicing the range. Replace all panels before operating range. Failure to do so can result in death or electrical shock.

  • Page 31: Dimming Board & Smps

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-5 DIMMING BOARD & SMPS WARNING Disconnect power before servicing the range. Replace all panels before operating range. Failure to do so can result in death or electrical shock.

  • Page 32: Emi Filter

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-6 EMI FILTER WARNING Disconnect power before servicing the range. Replace all panels before operating range. Failure to do so can result in death or electrical shock.

  • Page 33: Wifi Pcb

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-7 WiFi PCB WARNING Disconnect power before servicing the range. Replace all panels before operating range. Failure to do so can result in death or electrical shock.
  • Page 34 This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly WiFi PCB Parts Explanation Photo Explanation WiFi hodler PCB Hook of Holder PCB Hook of Holder PCB 1. Follow the Step E and remove 1 screw of WiFi holder PCB.

  • Page 35: Bluetooth Pcb

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-8 BLUETOOTH PCB WARNING Disconnect power before servicing the range. Replace all panels before operating range. Failure to do so can result in death or electrical shock.
  • Page 36 This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly BLUETOOTH PCB Parts Explanation Photo Explanation Blutooth holderPCB Blutooth holderPCB Hook of Holder PCB Hook of Cover PCB 1. Follow the Step E and remove 1 screw of Bluetooth holder PCB.

  • Page 37: Spark Module

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-9 SPARK MODULE WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 38: Knob Led Pcb

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-10 KNOB LED PCB WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 39: Rotary Switch

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-11 ROTARY SWITCH WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 40: Electrode

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-12 ELECTRODE WARNING Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 41: Electrode (Dual Burner)

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-13 ELECTRODE (DUAL BURNER) WARNING Disconnect power before servicing the range. Replace all panels before operating range. Failure to do so can result in death or electrical shock.

  • Page 42: Burner Cup

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-14 BURNER CUP WARNING Disconnect power before servicing the range. Replace all panels before operating range. Failure to do so can result in death or electrical shock.

  • Page 43: Gas Orifice Nozzle

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-15 GAS ORIFICE NOZZLE WARNING Disconnect power before servicing the range. Replace all panels before operating range. Failure to do so can result in death or electrical shock.

  • Page 44: Valve Cooktop

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-16 VALVE COOKTOP WARNING Disconnect power before servicing the range. Replace all panels before operating range. Failure to do so can result in death or electrical shock.

  • Page 45: Switch Ignition

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-17 SWITCH IGNITION WARNING Disconnect power before servicing the range. Replace all panels before operating range. Failure to do so can result in death or electrical shock.

  • Page 46: Ass'y Motor And Tco

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-18 ASS’Y MOTOR and TCO WARNING Disconnect power before servicing the range. Replace all panels before operating range. Failure to do so can result in death or electrical shock.

  • Page 47: 3-19Ass'y Door Latch

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-19ASS’Y DOOR LATCH WARNING Disconnect power before servicing the range. Replace all panels before operating range. Failure to do so can result in death or electrical shock.

  • Page 48: Switch-Door Plunger

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-20 SWITCH-DOOR PLUNGER WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 49: Ass'y Lamp

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-21 ASS’Y LAMP WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 50: Sensor-Thermister

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-22 SENSOR-THERMISTER WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 51: Gasket Door

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-23 GASKET DOOR Parts Explanation Photo Explanation Open the oven door to its fully down position. Pull the ends of the gasket out of the liner holes.

  • Page 52: Glass-Inner

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-24 GLASS-INNER Parts Explanation Photo Explanation 1. Follow the Step D. 2. Remove 5 screws to remove the CHASSIS DOOR. GLASS-INNER 3. Remove 4 screws to remove the GLASS INNER SUB.

  • Page 53: Ass'y Power Cord

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-25 ASS’Y POWER CORD WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 54: Burner Broil

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-26 BURNER BROIL WARNING Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 55: Burner Broil

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-27 BURNER BROIL Parts Explanation Photo Explanation 4. Remove 4 screws of bracket-broil spreader to top of oven. 5. Support the burner-broil with one hand, remove 2 screw supporting the burner-broil to the front and the rear of the oven.

  • Page 56: Hot Surface Ignitor (Hsi) Of The Burner Broil, Nozzle Broil-Burner, Holder

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-28 HOT SURFACE IGNITOR (HSI) of the BURNER BROIL, NOZZLE BROIL-BURNER, HOLDER BROIL-BURNER WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 57: Burner Bake

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-29 BURNER BAKE WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 58: Hot Surface Ignitor (Hsi) Of The Burner Bake Nozzle Bake-Burner, Holder Bake

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-30 HOT SURFACE IGNITOR (HSI) of the BURNER BAKE NOZZLE BAKE-BURNER, HOLDER BAKE-BURNER WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 59: Conection Moteor(Upper/ Lower)

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-31 CONECTION MOTEOR(Upper/ Lower) WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 60: Heater Convection

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-32 HEATER CONVECTION WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.

  • Page 61: Ass'y Valve Safety

    This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly 3-33 ASS’Y VALVE SAFETY WARNING ELECTRICAL SHOCK HAZARD Disconnect power before servicing the range. Replace all panels before operating the range. Failure to do so can result in death or electrical shock.
  • Page 62 This document can not be used without Samsung’s authorization. 3. Disassembly and Reassembly ASS’Y VALVE SAFETY Parts Explanation Photo Explanation 8. Rremove 7 screws and the ASS’Y VALVE SAFETY, Tube Bake and Holder Bake Nozzle from the back wall of the opening.

  • Page 63: Troubleshooting

    This document can not be used without Samsung’s authorization. 4. Troubleshooting 4. Troubleshooting 4-1 Failure Display Codes Information code Meaning Solution 1. Disconnect power. Open the back cover. Disconnect sensor harness from control Measure sensor resistance :1080Ω at the Oven sensor opened room temperature (over 2950Ω)
  • Page 64 This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-1 Failure Display Codes “C-20” oven sensor Disconnect power Measure sensor resistance. Replace oven sensor. (1080Ω at the room temperature) Check the connecting condition of harness. (Oven sensor and CN320 of Main PCB)
  • Page 65 This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-1 Failure Display Codes Information code Meaning Solution 1. Disconnect power . Open the back cover . Disconnect sensor harness from control .Measure sensor resistance :1080Ω at the room temperature →...
  • Page 66 This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-1 Failure Display Codes Oven sensor error Failure code Cause Solution PCB Sensor Opened 1. Disconnect electrical Power to the range. Remove the back cover. Measure the sensor resistance 3900Ω at the room C-30 temperature →...
  • Page 67 This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-1 Failure Display Codes Safety error Failure code CAUSE Solution 1. Disconnect power. Open the rear cover. Disconnect the two harness connectors to the NTC sensor resistance:3900Ω at the...
  • Page 68 This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-1 Failure Display Codes Information code Meaning Solution 1. Check whether wire harness has been inserted into connector of Main PCB or Sub PCB. 2. Check for shorts at the connects between...
  • Page 69 This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-1 Failure Display Codes Information code Meaning Solution 1 . Disconnect power. Open the back cover. Check whether harness has been connected with door lock switch and motor. 2 . Confirm whether resistance value of door lock motor is normal.
  • Page 70 This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-1 Failure Display Codes Failure code Cause Solution Main ↔ SUB communication C-F0 Check wire harness. (Main PCB : CN470 , SUB : CN200) information “C-F0” Is the wire harness...

  • Page 71: Error Trouble Shooting

    This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-2 Error Trouble Shooting SYMPTOM DIAGNOSIS REMEDY * Measure the input voltage at the plug. * Check the circuit breaker or fuse for the range (120VAC) circuit. * Measure the input voltage at SMPS, * Make sure all wires are connected to the PCBs.
  • Page 72 This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-2 Error Trouble Shooting SYMPTOM DIAGNOSIS REMEDY * The oven temperature exceeds 400°F(202°C) within 10 minutes of * Repair or replace the faulty broil or bake relay. room temperature operation.
  • Page 73 This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-2 Error Trouble Shooting SYMPTOM DIAGNOSIS REMEDY * Check to see if the buzzer wire The buzzer does not * Check buzzer wire, connect. If wire is connected well.
  • Page 74 This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-2 Error Trouble Shooting SYMPTOM DIAGNOSIS REMEDY * Clean and/or replace the surface burner orifice. * Check for a dirty surface burner orifice. NOTE: Replacement of orifice should always be the same size as the removed one.

  • Page 75: Control Parts

    This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-3 Control parts Buzzer does not beep when Lamp switch turn on or Cooking start Buzzer does not beep when SET start. Faulty buzzer on PCB(Dimming board) Replace the Buzzer wire.
  • Page 76 This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-3 Control parts Cooktop burner not lighted [Gas malfunction] No cooktop burners will light * Make sure the gas supply valve *Fully open the gas supply valve. to the range is fully open.
  • Page 77 This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-3 Control parts Cooktop burners not lighted [Electric malfunction] No cooktop Burners will light *Plug in the power cord and * Make sure there is power to the range or reset the circuit breaker for the range.
  • Page 78 This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-3 Control parts One cooktop burner not lighted [Electric malfunction] One cooktop burner will not light. Check whether the burner head and Assemble the burner head and cap is properly assembled.

  • Page 79: Cooktop Parts

    This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-4 Cooktop parts Gas Leaked Gas Leaked Back Side (4 Points) Check gas pipes on back side are properly Assemble the gas pipes on the assembled. (4 points) right position.
  • Page 80 This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-4 Cooktop parts The flame looks abnormal. [Yellow tip / Lift flame] Plastic Cap Plastic Cap LP position LP position NG position NG position Yellow tip / Lift Flip Orifice...
  • Page 81 This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-4 Cooktop parts Flame size is too big or too small Flame size is too big or small. Check the orifice nozzle diameter. Replace the orifice nozzle. Reverse the direction of the orifice Check the orifice direction at GPR.
  • Page 82 This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-4 Cooktop parts Oven burner will not light [Broil / Bake burner] Oven burner will not light. Check the orifice nozzle diameter. Replace the orifice nozzle. Check the voltage(120V)

  • Page 83: Cooktop / Oven Parts

    This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-5 Cooktop / Oven parts Oven temperature rises too slowly [Electric malfunction] Oven Temp rises too slowly. Turn on the cooktop burners to check Open the gas valve. whether the gas is properly supplied.
  • Page 84 This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-5 Cooktop / Oven parts Oven temperature rises too fast. [Electric malfunction] Oven Temp rises too fast. *Check to see if oven exceeds *Repair or replace the harness. 400℉(202℃)with in 10 minutes of room temperature operation.

  • Page 85: Oven Parts

    This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-6 Oven parts Oven temperature rises too slow or too fast [Gas malfunction] Oven temperature rises too slow or too fast. * Make sure the gas supply valve * Fully open the gas supply valve.
  • Page 86 This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-6 Oven parts Oven overheating in all cooking modes. Oven overheating in all cooking modes. Check for “ C-21” on the hidden 7-seg display. (It appears when the oven Open the gas valve.
  • Page 87 This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-6 Oven parts Oven lamp not working Oven lamp is not working * Make sure the control Lamp *replace light switch. switch is working properly. *Reconnect securely or replace damaged...
  • Page 88 This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-6 Oven parts Convection fan not working Convection fan not working. Fan Motor Teminals Measure resistance value at the Motor Replace the Motor. terminal after taking off harness from Motor.
  • Page 89 A) Press Wi-Fi key on 4th knob.(Pull out the knob, then you can see Wi-Fi key) • Press Wi-Fi Key for 3 seconds.(press until it beeps.) • You can check Wi-Fi list in your smart phone, look for . “ [Range] Samsung” B) Remove the Wi-Fi module for the procedure.
  • Page 90 This document can not be used without Samsung’s authorization. 4. Troubleshooting 4-6 Oven parts Bluetooth(Hood) Connection is not working Bluetooth key Step.1 - Check whether Hood is connected and operating correctly . • If Hood disconnected, try Bluetooth(B/T) pairing again.

  • Page 91: Pcb Diagrams

    This document can not be used without Samsung’s authorization. 5. PCB Diagrams 5. PCB Diagrams 5-1 Picture of PCB MAIN and PCB SUB PCB MAIN(FM NEW MAIN) PCB SUB(PRORANGE SUB)
  • Page 92 This document can not be used without Samsung’s authorization. 5. PCB Diagrams BASIC REPLACEMENT STEP...
  • Page 93 This document can not be used without Samsung’s authorization. 5. PCB Diagrams BASIC REPLACEMENT STEP 1 : GND 8 : KEY-BL-R1-P26 2 : KEY-BL-L1-P21 9 : KEY-BL-R2-P27 3 : KEY-BL-L2-P22 10 : KEY-BL-R3-P28 1 : BT-SW-P4 7 : AUTO-POP-UP-SW-IN-P7 4 : KEY-BL-L3-P23 &...

  • Page 94: Explanation Of Main Pcb Parts

    This document can not be used without Samsung’s authorization. 5. PCB Diagrams 5-2 Explanation of Main PCB parts PART NO. PART NAME FUNCTION AND RULE RY201 RY-Source Relay This is relay which control source of DLB, Bake, Broil relay. "Broil relay(RY203), Bake relay(RY204), convection relay(RY205) will be on-off...
  • Page 95 This document can not be used without Samsung’s authorization. 5. PCB Diagrams PART NO. PART NAME FUNCTION AND RULE T201 DLB Terminal This is terminal to connect harness with DLB relay. T210 Convection-Heater T206 This is terminal to connect harness with convection-heater relay.

  • Page 96: Explanation Of Prorange Sub

    This document can not be used without Samsung’s authorization. 5. PCB Diagrams 5-3 Explanation of PRORANGE SUB PART NO. PART NAME FUNCTION AND RULE CNS210 Power Connector This is to supply power to Dimming PBA. CNS240 Dimming I2C Connector This is connector to I2C with Dimming PBA.

  • Page 97: Schematic Diagrams

    This document can not be used without Samsung’s authorization. 6. Schematic Diagrams 6. Schematic Diagrams 6-1 Schematic Diagram (NX58M9960P*)

  • Page 98: Wiring Diagram

    This document can not be used without Samsung’s authorization. 6. Schematic Diagrams 6-2 Wiring Diagram...
  • Page 99 North & Latin America gspn3.samsungcsportal.com China china.samsungportal.com This service manual is the property of Samsung Electronics Co., Ltd. © Samsung Electronics Co., Ltd. March, 2021 Any unauthorized use of this manual can be punished under applicable Printed in Korea international and/or domestic law.
