vego garden VGH0812PCBK Manual

Hide thumbs

Advertisement

Table of Contents

V E G O G A R D E N . C O M
V1.0 10/29/2024
Manual for
Vego Greenhouse Kit
Gardening Made Easier.
Copyright @ 2024 Vego
Anytime, Anywhere.
vegogarden.com
Contact Us
Model:
VGH0812PCBK
Vego Garden Academy
Dimensions:
vegogarden.com
vegogarden.com
Houston, TX
8.5' X 12.5' X 8.5' (H)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VGH0812PCBK and is the answer not in the manual?

Questions and answers

Tracy Borgen/Tagert Landscaping
April 1, 2025

can i use compacted gravel as a base

0
1 comments:
Mr. Anderson
April 1, 2025

The manual does not mention compacted gravel as a base option. It lists three options: a solid foundation, a solid frame, or installation on firm ground using heavy-duty landscape stakes. Therefore, compacted gravel is not specified as a recommended base.

This answer is automatically generated

0

Related Manuals for vego garden VGH0812PCBK

Summary of Contents for vego garden VGH0812PCBK

  • Page 1 V E G O G A R D E N . C O M V1.0 10/29/2024 Manual for Vego Greenhouse Kit Gardening Made Easier. Copyright @ 2024 Vego Anytime, Anywhere. vegogarden.com Contact Us Model: VGH0812PCBK Vego Garden Academy Dimensions: vegogarden.com vegogarden.com Houston, TX 8.5’ X 12.5’ X 8.5’ (H)

  • Page 2: Safety Advice

    Safety Advice 1. This product is designed to be used as a greenhouse. 2. It is important to assemble the product according to this manual, do not skip or modify any steps. 3. Wear gloves, shoes and safety glasses during assembling to avoid injury. 4.

  • Page 3: Tools Provided

    4. Loosely tighten bolts as you assemble. After the greenhouse is built, and still loosely Tools Packing Information connected, then tighten all bolts completely. Tools Provided Tools Required (Not Provided) product. 6. Clean the product with a mild soap and rinse with cold, clean water. 7.

  • Page 4: Packing Information

    Packing Information Extension Kit Boxes 1 boxes in total: Greenhouse Boxes E B O X 1 E B O X 2 a. Aluminum Frame & Hardware: B O X 1 E B O X 3 B O X 2 B O X 3 E B O X 4 b.
  • Page 5 Hardware List: Foundation Assembly STEP PART PART S03A Z02A BOX 2 BOX 2 M6X10 Ø4X16D Choose a hard, level surface. Clean and position the greenhouse using a level to ensure S03A Z02A BOX 6 EBOX 1 M6X10 Ø4X16D S03A Z08A EBOX 1 BOX 2 M6X10...
  • Page 6 STEP Lay out the foundation pieces as diagrammed, using the door location as a reference. PART QTY. BOX 6 DJ02 1290mm DJ02 DJ02 EBOX 4 DJ03 1245.6mm BOX 6 BOX 6 DJ02 DJ02 EBOX 4 D366 BOX 6 S03A M6X10 DJ03 DJ03 DJ02...
  • Page 7 STEP STEP Slide the heads of 26 S03A bolts in the grooves of the frame, on the inside and outside, Assemble 6 sets of Z1 and 4 sets of Z2 connection plates by loosely installing the bolts as shown below. These will hold the outside connectors and anchor brackets. and cap nuts.
  • Page 8 STEP STEP Slide Z1 & Z2 in the grooves of foundation pieces to connect each section and tighten Connect the 4 corners with D366 L brackets using the pre-slid bolts and nuts. D366 D366 DJ02 DJ02 D366 D366 DJ02 DJ02 DJ03 DJ03 DJ02...

  • Page 9: Base Assembly

    Base Assembly STEP Lay out the base frame pieces as shown in the diagram, noting that there are two types L08F J196L J196R L08A L08F of corner pieces. PART BOX 2 L08A EBOX 1 L08A BOX 2 L08D L08D L08E BOX 2 L08E BOX 2...
  • Page 10 STEP STEP When connecting the base frame to the Vego Foundation Frame Kit, connect D75 and Mark 18 anchor holes on ground per the template below. D76 brackets to the pre-slid S03A bolts, attach M24 nuts and slide the bracket assembly over the marked anchor holes.

  • Page 11: Wall Assembly

    Wall Assembly STEP Starting to the left of the door position, begin the vertical frame assembly. Loosely 25/64" PART BOX 3 L01A BOX 3 L01B BOX 3 L01E BOX 3 L01F BOX 3 L02A EBOX 1 L02A BOX 1 L03C BOX 1 L03D BOX 3...
  • Page 12 Note: For L02A frame: the cut ends face upward For L01A,B,E,F frames: the ends with holes drilled further from the edge face upward L02A L03C L03D L01B L03G L01A L02A S03A L01F L08F J196L/R L02A/L03C/L03D/L03G L01E L02A S03A L02A...
  • Page 13 STEP Attach a vertical frame piece, followed by a horizontal piece, moving around the greenhouse clockwise. It is important for structural stability during assembly to attach S03A S03A x 2 horizontal braces after each vertical component. Cap nuts always face inside. L05B PART BOX 1...
  • Page 14 STEP Door Frame Assembly L03A L03A PART S03A S03A BOX 1 L03A diagram. S27 A BOX 1 L03B BOX 2 L05C S27 A BOX 2 L08A S03A M6X10 L08A H137 x 2 S27A M5X12 L03B L03B H137 S03A S27 A L03B H137 x 2 L08A...
  • Page 15 STEP PART S21A M5X12 S21A BOX 3 L12A BOX 3 L12B BOX 4 EBOX 2 H158 L12A/L12B L12A S21A L12B L01A/L01B/L01E/L01F L12B Scan the QR code above or visit vegogarden.com to learn more about your Vego Greenhouse Kit. L12A...
  • Page 16 STEP PC Wall Panel Assembly Note: The white film indicates the UV-protected side of the panels. We recommend waiting to remove the white film until you have placed the panels in the frame, to ensure that the UV side is facing outwards. Insert panels in the grooves as shown in the diagram below, ensuring the UV side of the panels are facing outwards.
  • Page 17 STEP Secondary Horizontal Frame Assembly S03A x 2 Note: Hex tool required. Place S03A bolts on hex tool, load it into the hole between the gap of the two S03A Repeat this step for all holes in hard to reach spots. L04A L04A PART...
  • Page 18 STEP For D349 connectors shown in image 2, do not insert bolts into the middle top 2 holes Frame Connectors Assembly yet; this will be completed in a later step. Insert L07 into the slot at L02A’s end, as shown. L07A/L07B PART BOX 1...

  • Page 19: Roof Assembly

    STEP Roof Assembly D25 Gutter Connectors Slide 4 S03A bolts in the grooves of the frame, two from the front, two from the back, STEP Front & Back Gable Assembly and position them as shown in the diagram. Secure the D25 gutter connectors with M24 nuts. Top holes: S03A, M24 L07B L07A...
  • Page 20 STEP Upper Front and Back PC Panel Assembly L04C and should be installed facing outwards. PART BOX 4 L04B BOX 4 BOX 4 BOX 4 BOX 5 L03F BOX 5 H158 POLYCARBONATE PANEL White Film sheet Transparent Film S03A x 2 S03A x 2 M24 x 2 M24 x 2...
  • Page 21 STEP Roof Frame Assembly Slide the corresponding roof frame pieces over the PC panels, and bolt into place. S03A/M24 x 2 L01C/L01D PART BOX 3 L01C BOX 3 L01D S03A M6X10 L01C/L01D L01C L01D S03A/M24 S03A/M24 x 2 Scan the QR code above or visit vegogarden.com to learn more about your Vego Greenhouse Kit.
  • Page 22 PART BOX 2 L05E L05E EBOX 1 BOX 3 L02C EBOX 1 L02C BOX 2 D129 L01C EBOX 1 D129 L01D BOX 2 D348 EBOX 1 D348 S03A M6X10 L01D L01C Scan the QR code above or visit vegogarden.com to learn more about your Vego Greenhouse Kit.
  • Page 23 STEP Ridge and Roof Panel Assembly Assemble 2 sets of roof frame (G1) supports by connecting L02C pieces with D348 L05E with S03A bolts. The support bar then can be bolted to the underside of the roof Install roof frame G1 as shown. Secure with bolts and cap nuts. frame support as shown.
  • Page 24 Install horizontal roof frame pieces (L04E) facing the back of the greenhouse as shown. L02C PART S03A/M24 x 2 EBOX 1 L02B EBOX 1 L04E EBOX 3 M24 x 2 EBOX 3 S03A L04E M6X10 D349 H158 L06A/L06B L04E L04E S03A/M24 x 2 L06A S03A/M24 x 2...
  • Page 25 Slide Y8 PC panels, UV side out, into place. Slide Y9 panels into the peak of the greenhouse as shown, and secure to the ridge temporarily using painters tape. and cap nuts. L02B L09 as shown L02B Scan the QR code above or visit vegogarden.com to learn more about your Vego Greenhouse Kit.
  • Page 26 STEP L01C/L01D PART EBOX 1 L04D BOX 3 L12C BOX 3 L12D S03A x 2 S03A/M24 x 4 S03A/M24 x 2 M24 x 2 EBOX 2 L04D EBOX 3 S21A M5X12 S03A M6X10 S03A x 2 H158 L04D M24 x 2 M24 x 2 L04E L04D...
  • Page 27 Note: The white film indicates the UV-protected side of the panels. We recommend waiting to remove the white film until you have placed the panels in the frame, to will be on the left when you are facing the outside of the back. ensure that the UV side is facing outwards.
  • Page 28 STEP Roof Ridge PC Panel Assembly PART L04D BOX 2 S21A BOX 1 L06A EBOX 1 BOX 4 BOX 5 L01C/D L01C/D S03A M6X10 Z08A M4.2X16 H158 S21A x 10 L12C/D L01C/D Scan the QR code above or visit vegogarden.com to learn more about your Vego Greenhouse Kit.
  • Page 29 roof. and cap nuts. Z08A x 2 L06A L06A L04D S03A/M24 x 2 L04D L06A S03A/M24 x 2...
  • Page 30 Repeat same steps for frames and panels assembly and cap nuts. PART EBOX 1 L02B EBOX 1 L04E EBOX 3 EBOX 3 S03A M6X10 H158 L09 as shown L02B L02B Scan the QR code above or visit vegogarden.com to learn more about your Vego Greenhouse Kit.
  • Page 31 UV side out, secure to the ridge temporarily using painters tape. S03A/M24 x 4 S03A/M24 x 2 Painter’s tape S03A/M24 x 2 L04E M24 x 2 L04D L04E Scan the QR code above or visit vegogarden.com to learn more about your Vego Greenhouse Kit.
  • Page 32 Install another roof frame G1 and the last L06A ridge piece as shown. Secure with bolts L02C S03A/M24 x 2 PART NO QTY L06B BOX 1 L06A L02B BOX 3 BOX 2 L04E L06A D349 BOX 2 BOX 5 L06A/L06B S03A/M24*4 BOX 5 S03A...
  • Page 33 Repeat the same steps as you install the remaining frames and panels. Z08A x 2 S03A/M24 x 2 L04E L04E...
  • Page 34 shown. L01C/L01D PART L04D BOX 2 BOX 3 L12C BOX 3 L12D S03A*2 onto L09 as shown M24*2 BOX 4 L04D BOX 5 S21A L02B M5X12 S03A M6X10 S03A*2 H158 M24*2 L02B L04D L04D L04D S03A/M24 x 4 M24 x 2 S03A/M24 x 2 L04E...
  • Page 35 will be on the left when you are facing the door. L12D L12C Scan the QR code above or visit vegogarden.com to learn more about your Vego Greenhouse Kit.

  • Page 36: Vent Assembly

    Vent Assembly S21A STEP L01C/D L01C/D Repeat these steps to assemble a total of 8 vents, and trim any excess weather stripping from the ends. PART L11A BOX 2 S21A x 10 L15A L11A EBOX 1 L15A BOX 2 EBOX 1 L12C/D BOX 2 EBOX 1...
  • Page 37 STEP Z02A x 2 screws. PART L11A BOX 2 L15A S26A M5X12 Z02A Z19A M4.2X10 S03A M6X10 C1 x 6...
  • Page 38 S03A/M24 x 4 Door Assembly STEP PART BOX 1 L16A S03A/M24 x 2 BOX 2 L16B BOX 1 L16C BOX 1 L18A BOX 2 Z19A X 2 BOX 2 J193 BOX 4 L04E J193 BOX 2 L16B S26A X 2 J193 S03A M6X10...
  • Page 39 STEP S03A/M24 x 4 L18A L16A S03A/M24 x 4 L16C L16A L16B L16B L16B L16B Z02A x 8 Z02A x 8 S27A x 6 S27A x 6 A51 x 2 A51 x 2...
  • Page 40 STEP Door & Lock Installation S27A x 6 S27A x 6 PART BOX 2 H154 Z17 A M4.8X16 S27 A M5X12 DOOR-R DOOR-L S27A...
  • Page 41 STEP STEP Install Ridge End Caps Drainage Pipe Assembly placement in the image below. screws. J198 PART J197L/R BOX 2 J198 BOX 2 J197R Z08A x 2 BOX 2 J197L Z08A BOX 2 BOX 2 BOX 2 Z02A BOX 2 J199 BOX 2 H178...
  • Page 42 STEP Drainage Pipe Bracket Assembly connector. J199 J199 Z08A Z08A J199 J199 J199 J199...
  • Page 43 STEP STEP to the center of door frame. Apply silicone caulk around all the PC panels for water tightness.
