- Page 1 GUIDE DE OWNER'S L'UTILISATEUR MANUAL UPAS PORTABLE AIR CONDITIONER UPAS05KC610C UPAS06KC630C THANK YOU FOR YOUR PURCHASE! QUESTION? PROBLEM? CONTACT STELPRO CUSTOMER SERVICE. WWW.UNIWATT.CA CONTACT@STELPRO.COM 1-844-STELPRO...
-
Page 2: Table Of Contents
PLEASE BE SURE TO READ THIS USER MANUAL CAREFULLY BEFORE USING YOUR DEHUMIDIFIER. IF YOU HAVE ANY FURTHER QUESTION, PLEASE CONTACT OUR CUSTOMER SERVICE FOR HELP. IMPORTANT: THE REMOTE CONTROL AND HARDWARE NECESSARY TO USE YOUR NEW DEVICE ARE INCLUDED INSIDE THE BOX. YOU WILL FIND THEM INSERTED IN THE STYROFOAM WITHIN THE BOX. - Page 3 Remote Control Manual ....................23 Point the remote control at the sensor on the appliance..........23 Inserting or Replacing The Batteries ................24 Turning the Appliance On/Off ..................24 Cool mode ........................24 Fan Mode ........................25 Dry Mode ........................25 Sleep Function ......................
-
Page 4: Important Instructions
IMPORTANT INSTRUCTIONS This appliance is for household use only. • Disconnect the appliance from its power source during service and when replacing parts and cleaning. • Please note: Check the nameplate for the type of refrigerant gas used in your appliance. -
Page 5: Electrical Connections
• Always grasp the plug when plugging in or unplugging the appliance. Never unplug by pulling on the cord. It can result in the risk of electrical shock and damage. • Install the appliance on a sturdy, level floor capable of supporting up to 110lbs(50kg). Installation on a weak or unlevel floor can result in the risk of property damage and personal injury. -
Page 6: Information For Qualification Of Workers
Ventilated area (open doors and windows) 11. Ensure that the working area is open or well ventilated before turning on the system or performing hot work. Ventilation should be maintained during operation. Ventilation quickly displaces safely diluted leaked refrigerant into the atmosphere. 12. - Page 7 1. Personnel who do not need to open the refrigeration system of combustible refrigerant products, such as relevant personnel of transportation enterprises Regular Hold a Class B certificate and general maintenance contacts issued by the competent personnel of product personnel authority, available online after-sales department, etc.
- Page 8 TOOLING NAMES USE REQUIREMENT Explosion-proof vacuum pump: ensure a certain Small vacuum pump accuracy, vacuum degree should be less than 10Pa. Special explosion-proof charging equipment: with Filling equipment certain accuracy, the charging amount deviation is less than 5g. Regular calibration: annual leakage rate is not higher Leak detector than 10g.
-
Page 9: Repairs To Sealed Components
7. It is necessary to avoid the places where there are other electrical products, power switch plugs and sockets, kitchen cabinet, bed, sofa and other valuables right under the lines on two sides of the indoor unit, and also prevent mechanical damage from occurring. -
Page 10: Charging Procedures
CHARGING PROCEDURES ln addition to conventional charging procedures,the following requirements shall be followed: • Ensure that contamination of different refrigerants does not occur when using charging equipment. Hoses or lines shall be as short as possible to minimise the amount of refrigerant contained in them. -
Page 11: Recovery
RECOVERY When removing refrigerant from a system, either for servicing or decommissioning, it is recommended good practice that all refrigerants are removed safely. When transferring refrigerant into cylinders, ensure that only appropriate refrigerant recovery cylinders are employed. Ensure that the correct number of cylinders for holding the total system charge are available. - Page 12 1.5 Presence of fire extinguisher If any hot work is to be conducted on the refrigeration equipment or any associated parts, propriate fire extinguishing equipment shall be available to hand. Have a dry powder or CO fire extinguisher adjacent to the charging area. 1.6 No ignition sources No person carrying out work in relation to a refrigeration system which involves exposing any pipe work that contains or has contained flammable refrigerant shall use any sources...
-
Page 13: According The Us And Canada Ruler
ACCORDING THE US AND CANADA RULES CAN ICES-003 (B)/NMB-003(B) FCC CAUTION This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 14: Installing The Air Conditioner
INSTALLING THE AIR CONDITIONER PARTS NAME 1. Control panel 6. Intake grille 2. Remote control receiver 7. Air outlet grille 3. Deflector 8. Intake grille 4. Handle (both sides) 9. Plug fixer 5. Casters 10. Condenser drain 11. Power cable INCLUDED ACCESSORIES 1 exhaust hose 1 hose outlet... -
Page 15: Location
Note: All the illustrations in this manual are for explanatory purposes only. Your appliance may be slightly different. Be sure all accessories are removed from the packing before use. LOCATION In the Cool Mode, the appliance must be placed close to a window or opening so that the warm exhaust air can be ducted outside. -
Page 16: Installing The Exhaust Hose
INSTALLING THE EXHAUST HOSE First, position unit on a flat level floor and make sure there is a minimum of 18” (45cm) clearance around the unit, and is within reach of a single circuit outlet power source. 1. Extend either side of the hose (Fig. 3) 2. -
Page 17: Assembly
ASSEMBLY 1. Slide Panel B into Panel A and size Fig. 7 to widow width. Windows sizes vary. When sizing the window width, be sure that the window kit assembly is free from gaps and/or air pockets when taking measurements. Cut on opposite side 2. -
Page 18: Vertical Window
5. Cut the foam seal (adhesive type) to the proper length and attach it on the top of the window. 6. Close the window securely against the window slider kit. 7. Secure the window slider kit to the window sash. 8. -
Page 19: Operating The Air Conditioner
OPERATING THE AIR CONDITIONER SWING FUNCTION This serial unit have no auto swing function. Open the deflector before use the appliance. 1. Hold the horizontal deflectors and move up and down for comfort. 2. Hold the vertical deflectors and move left or right for comfort. -
Page 20: Description Of The Display Screen
DESCRIPTION OF THE DISPLAY SCREEN The control panel is on the top of the appliance, enables you to manage part functions without remote controller, but to fully exploit its potential, you must use the remote controller. 1. Timer button H. Cool symbol 2. -
Page 21: Fan Mode
The most suitable temperature for the room during the summer varies from 24°C to 27°C (75°F to 81°F). You are recommended, however, not to set a temperature much below the outdoor temperature. The fan speed difference is more noticeable when the appliance is under Fan mode but may not be noticeable under Cool mode. -
Page 22: Switch From Celsius To Fahrenheit
Programming shut down 1. When the appliance is running, press the " " button, the screen starts to flash. 2. Press the " " / " " to adjust the set time from 0.5-24 hours. 3. In 5 seconds without the operation, the timer start function, then the " "... -
Page 23: Remote Control Manual
REMOTE CONTROL MANUAL On/Off button Mode button Sleep button Increase temperature button Decrease temperature button Swing button Fan speed button Timer button Unit Switch button POINT THE REMOTE CONTROL AT THE SENSOR ON THE APPLIANCE • The remote control must be no more than 23 ft (7 meters) away from the appliance (without obstacles between the remote control and the receiver). -
Page 24: Inserting Or Replacing The Batteries
INSERTING OR REPLACING THE BATTERIES 1. Remove the cover on the rear of the remote control. 2. Insert two "AAA" 1.5V batteries in the correct position (see instructions inside the battery compartment). Note : • If the remote control unit is replaced or disposed of, the batteries must be removed and discarded in accordance with current legislation as they are harmful to the environment. -
Page 25: Fan Mode
FAN MODE When using the appliance in this mode, the air hose does not need to be attached. To set this mode correctly: 1. Press the " Mode " button a few times until the " " symbol appears. 2. Select the required fan speed by pressing the " "... -
Page 26: Setting The Timer
The SLEEP function can be canceled at any time during operation by pressing the “ ”, " Mode " or " " button. In DRY and SMART mode, SLEEP function is still available. SETTING THE TIMER This timer can be used to delay the appliance start-up or shutdown, this avoids wasting electricity by optimizing operating periods. -
Page 27: Tips For Correct Use
TIPS FOR CORRECT USE To get the best from your appliance, follow these recommendations: • Close the windows and doors in the room to be air conditioned (Fig. 5). When installing the appliance semipermanently, you should leave a door slightly open (as little as 1 cm) to guarantee correct ventilation;... -
Page 28: Water Drainage Methods
WATER DRAINAGE METHODS Lorsqu'il y a un excès de condensation d'eau à l'intérieur de l'unité, l'appareil s'arrête de fonctionner et affiche « » ( RÉSERVOIR PLEIN comme mentionné dans l'AUTODIAGNOSTIC ). Ceci indique que l'eau de condensation doit être évacuée en suivant les procédures suivantes : MANUAL DRAINING Water may need to be drained in high humidity... -
Page 29: Cleaning And Maintenance
CLEANING AND MAINTENANCE Before cleaning or maintenance, turn the appliance off by pressing the " " button on the control panel or remote control, wait for a few minutes then unplug from the mains socket. CLEANING THE CABINET You should clean the appliance with a slightly damp cloth then dry with a dry cloth. •... -
Page 30: Start Of Season Checks
START OF SEASON CHECKS Make sure the power cable and plug are undamaged and the earth system is efficient. Follow the installation instructions precisely. END OF SEASON OPERATIONS To empty the internal circuit completely of water, remove the cap. Run off all water left into a basin. When all the water has been drained, put the cap back in place. -
Page 31: Troubleshooting
TROUBLESHOOTING Occasionally, you may encounter some problems that are of a minor nature and a service call may not be necessary. Use this troubleshooting guide to identify possible problems you may be experiencing. PROBLEM POSSIBLE CAUSES SOLUTIONS • There is no current •... -
Page 32: Assistance
ASSISTANCE Distributed by Stelpro Design inc. www.stelpro.com contact@stelpro.com 1 844-STELPRO Before returning the unit to the retailer, for any problem related to the installation, use or proper functioning of the unit; contact our customer support department. One of our agents will guide you through the next steps.
