- Page 1 TV 5200 Owner’s manual and mounting instruction Mode d’emploi et manuel d’installation Bedienungs- und Einbauanleitung Gebruiksaanwijzing en inbouwhandleiding Istruzioni d’uso e d’installazione Instrucciones de manejo y de montaje Betjeningsvejledning og monteringsanvisning...
- Page 2 Mounting...
-
Page 3: Table Of Contents
Contents Contents Installation instructions ........4 IMPORTANT INFORMATION . -
Page 4: Installation Instructions
Installation instructions IMPORTANT INFORMATION The system must only be installed by trained personnel. Observe automotive industry quality standards. Fire hazard. When drilling, take care not to damage concealed wiring harnesses, the fuel tank or fuel lines. Never drill into supporting or safety-relevant body parts. It is essential to observe the following when installing components in the passenger compartment: Ensure that the driver has a clear all-round view. -
Page 5: Scope Of Delivery
Modes of installation Whether the TV 5200 TV tuner is connected to MS 5XXX navigation systems depends on whether a MI 2x00 or MC 5400 multimedia interface box is connected or whether the adapter cable CA 1220 is used. -
Page 6: Installing Tv Tuner
Installation instructions Installing TV tuner Before installing When installing the TV tuner and the other multimedia components, ensure suitable cable routing and that the required cable length is available. In positioning the tuner, allow ample space for plugging the connector plug into and out of the TV tuner whenever necessary. - Page 7 Insert adapter cable CA 1220 as per marking between the computer and the monitor cable and connect the AV output of the TV 5200 to the Cinch sockets of the CA 1220. Plug the 4-pin 3.5mm jack of the CA 1220 into the “Remote Input” socket on the TV 5200.
-
Page 8: Connecting Accessories
The audio outputs of the TV tuner’s AV output can be connected to a free input on the car radio (e.g. AUX) in order to output the TV 5200 audio signal over the vehicle’s loudspeakers. WT 5100 (infrared audio transmitter) and WH 5100 (IR headphones) The stereo output signal from the TV tuner can be transmitted via the infrared audio transmitter WT 5100 and received wirelessly via the infrared headphones WH 5100. -
Page 9: Operation
Antenna diversity switching for the best reception quality Infrared remote control For road safety reasons, the TV 5200 features a locking function which blanks the screen whenever the vehicle is in motion. The warning “TV-MODE DISABLED WHILE DRIVING” is displayed on the monitor. The image only appears when the vehicle is standing and the... -
Page 10: Remote Control
Operation Remote control POWER V.SEL FUNCTION AUTO MODE BAND 1 POWER: ..Press briefly: Switch on TV tuner. Press and hold: Switch off TV tuner. 2 AUTO: ..Switch search mode type AUTO -> SEEK -> MANUAL -> AUTO -> ... 3 MODE: . -
Page 11: Switching On / Off
Operation Switching on / off Briefly press the POWER button to turn on the TV tuner. The LED in the remote control receiver lights up when the TV tuner is switched on. Press and hold the POWER button to turn off the TV tuner. The LED on the remote control receiver goes out. - Page 12 Operation Auto-store function - AME Using the auto-store function, a maximum of 6 stations with good reception can be programmed on memory level TV-1 at the channel memory locations 1 ... 6. Press the AME button. The station search is started. The station at the first channel memory location is then displayed on the screen.
- Page 14 TV 5200 IFU 06/2005 ri www.vdodayton.com...
