Analogue TV Tuner (PAL)
TV 5200
• Analogue TV Tuner PAL
(Standards B, G, D, K, I)
• Stand-alone Plug & Play Solution
• 4-times Antenna Diversity System
• Automatic Station Search
• Can store up to 12 Channels
(user presets)
• 2 x AV Input (e.g. for DV 6200,
Game Console etc.)
Application
TV 5200 guarantees high reception performance of analogue
TV programs in combination with various connection possibili-
ties for other Multimedia Components.
Reception Performance
The quality-tuner module in combination with a 4-times
Antenna Diversity provides great mobile TV entertainment.
Various Input Connection Possibilities
2 additional AV sources can be connected to the TV 5200. By
plugging i.e. a DVD Player (DV 6200) and a Game Console
to the standard RCA/Cinch-Connectors, TV 5200 becomes the
center of your Entertainment System.
2 Monitors addressable
The TV program as well as the further connected AV sources
are provided on 2 Monitor Outputs in parallel – a perfect
feature for your Rearseat Entertainment System.
• 1 x AV Output to connect a Monitor
(e.g. MM 2700),
Multimedia Interface (MI 2200),
Audio- or Navigation-System*
• 1 x additional Video Output
(e.g. to connect a further Monitor)
• Infrared Remote Control with
separate receiver
(cable length 5m)
Small dimensions
Its compact and flat design allows the installation as „hide-
away-unit" in many places of your car.
Plug & Play module
TV 5200 is an independent module and can be used „stand-
alone" (e.g. with the 7'' Entertainment Monitor MM 2700)
as well as in combination with Navigation Systems.
OSD Language
English
Product Information
• Recommended Antenna Set:
TVA 6500
*
Optional Adaptor Cable CA 1220 required for
direct connection to Navigation System;
CA 1220 is not compatible with Monitors
MM 2100 and MM 2700
