Remington R1000, R1001, R36A Manual

Also See for R1 Series:

Table of Contents

PARTS

Parts Overview

Not shown

It is recommended to fully charge your appliance before using it for the first time.
Ensure the product is switched off.
Connect the product to the USB cable and then connect the USB end of the cable to a powered USB port.

Run time from fully charged is up to 30 mins.
Charge time from empty is 8 hours.
Do not recharge your product after each use as this will shorten the life of the battery.
Note: To preserve the life of your batteries, let them run out every 6 months then fully charge.

Slide the power switch to turn on.
Stretch the skin with your free hand so the hairs stand upright.
Only apply light pressure on the shaving head while shaving (pressing too hard can damage the heads and make them vulnerable to breakage).
Use short, circular strokes.

Ensure your skin is dry. Always hold the shaver at right angles to the skin so that all three heads are touching the skin with equal pressure.
Use moderate to slow stroking movements. The use of short circular motions in stubborn areas may obtain a closer shave, especially along the neck and chin line.
DO NOT press hard against the skin in order to avoid damage to the rotary heads.

Care for your appliance to ensure a long lasting performance. We recommend you clean your appliance after each use.
Ensure the appliance is switched off and unplugged from the mains before cleaning.

Open the shaver head by pressing the release button.
Empty out any hair clippings.
Pull the shaver head upwards to remove it from the body.
Rotate the circular button in the centre of the retainer counter clockwise to release the retainer. Once released, lift it out of the shaver head. Make a note of the correct orientation of the retainer to make refitting easier.
Carefully brush away any hairs from the cutters.
For a more thorough cleaning, lift out the three cutters.
Wash the shaving head under running water. Allow to dry thoroughly.
Carefully refit the three cutters.
Refit the retainer. Rotate the button clockwise to lock the retainer in place.
Once the shaver head is assembled, align the spring hinge with the slot at the back of the hair pocket and press into place. Close the shaver head.

TRIMMER
Lubricate the teeth of the trimmer every six months with a drop of sewing machine oil.

Read all instructions before using (this appliance).
When using an electrical appliance, basic precautions are required to always be followed, including the following:

To reduce the risk of electric shock:

Do not reach for an appliance that has fallen into water. Unplug immediately from receptacle.
Do not use while bathing or in a shower.
Do not place or store appliance where it is able to fall or be pulled into a tub or sink. Do not place in or drop into water or other liquid.
Except when charging, always unplug this appliance from the electrical outlet immediately after using.
Unplug this appliance before cleaning.

To reduce the risk of burns, fire, electric shock, or injury to people:

This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
Use this appliance only for its intended use as describe in this manual. Do not use attachments not specified by the manufacturer.
Never operate this appliance when it has a damaged cord or plug, when it is not working properly, after it has been dropped or damaged, or after it has been dropped into water. Return the appliance to a service center for examination and repair.
Keep the air openings free of lint, hair, and similar objects.
Never drop or insert any object into any opening.
Do not use outdoors or operate while aerosol (spray) products are being used.
Do not use this appliance with a damaged or broken comb, as it has the potential to result in facial injury.
Always attach plug to appliance first, then to outlet. To disconnect, turn all controls to off position (e.g. "0") then remove plug from outlet.
Use only with a USB Power Source on a certified product, such as on a computer, receptacle, lamp, class 2 power supply or automotive adaptor.
