  • Page 5: Table Of Contents

    BEFORE YOU START..Thank you for purchasing our product which has been designed and manufactured to the highest standards and subjected to rigorous testing. Please read this information carefully and follow the all instraction outlined below.This will ensure the reliable operationand long service life of your radio. Keep this manual handy in your car for future reference.

  • Page 6: Technical Data

    PREPARATION TECHNICAL DATA Voltag e and polarity: The set must be Following data is applied for CD4506, connected to a 12V car battery with negative CD4526X, CD4626X terminal to earth (car chassis). Installation in • Temperature Range: - 2 0 ° C ~ + 7 5 ° C. vehicles not fulfilling these requirements could •...
  • Page 7 CONNECTOR C1* OTHERS CONNECTIONS (fig. 8) Pre-out (fig. 4) D1* Telephone in (fig.8) • Connect a power amplifier (with additional • You can connect an optional hands-free phone loudspeaker) to this set with an optional kit via the connector D. See mounting and adapter cable.

  • Page 8: Mounting

    MOUNTING at 2 places on each side. • Only use M5 self-tapping screws that are METAL SLEEVE (fig.10) not longer than 6mm. • Install the metal sleeve (dimension 182x53 mm) in the dashboard. For optimal performance of the CD REPLACING FUSE (fig. 9) player, the metal sleeve should be positioned •...

  • Page 9: Front Panel Presentation

    FRONT PANEL PRESENTATION For illustration, see page 3, figure A. MODE TUNER CHANGER* MP3* ITEM (+MP3 CDC) Select preset 1 Random track Store preset Select preset 2 Repeat track Store preset Select preset 3 Repeat track Store preset Scan track Select preset 4 Select the previous •...

  • Page 10: Security

    SECURITY AUDIO For theft protection this set is provided with ON / OFF / VOLUME the following security features: • Press rotary knob to switch on/off the set. • Turn to adjust the volume. DETACHABLE FRONT - The volume automatically increases of Take the detachable front with you when leaving decreases if the SMART Volume connection the car.

  • Page 11: Radio

    RADIO - The set gives a beep and then mutes. - When it has finished, you hear a beep followed WAVEBAND by the station stored on preset 1. • Press BAND to select the desired band : - Sometimes it may not be possible to find 5 stations.

  • Page 12: Cd/Mp3/Cd Changer Player

    Interrupting Traffic Announcement/News - The unit may not play the first session if the mode disc contains both CD audio tracks and MP3 If you do not wish to continue listening to a files. particular Traffic Announcement: - When playing a disc of 8kbps or Variable Bit Rate (VBR), the elapsed play time in the display •...

  • Page 13: Special Functions

    FAST REWIND / FAST FORWARD ( You can select the service distance unit • Long press the button for more than • See 'SAM', option 'UINT' (PAGE13). 2 seconds to quickly move rewind or forward You can select the inteval distance of service through the disc.

  • Page 14: Setup

    SETUP It is possible to modify many of the set's default settings according to your preferences via 'MENU'. • P r e s s SAM key to enter Setup Menu. • P r e s s to select one of the options in the menu you want to modify. •Adjust the Rotary Knob to select the value/setting.
  • Page 15 Playback on current source is automatically interrupted when the car phone is in use and the incoming call is played on the car speakers. - Select 'H FREE HI' or 'H FREE LO' if a VDO Dayton hands free kit connected to the Radio (see installation instructions).
  • Page 16 ANGLE [ -1, 0, +1, +2] Select the viewing angle of the set's display. REMOTE [SERVOFF,SERVON, Select 'SERV ON' to activate car service alert .select 'SERV SET' SERV SET] to reset the seting of the car service (only valid when car speed is calibrated ).

  • Page 17: Trouble Shooting

    TROUBLE SHOOTING Display shows 'NO TA', and set beeps at intervals. • The tuned station becomes too weak to enable There may be times when you suspect that your the reception of Traffic Announcements. Use car radio is not functioning as you would expect it search tuning to find another station.
