  • Page 1 ASUS UX5400ZB series Repair Manual...

  • Page 3: Service Overview

    Service Overview • ASUS is not responsible for direct, indirect, intentional o unintentional damages resulting from improper installation and operation. • Carefully read through this Service Guide for a look at various components of the device before performing any service and repairs.
  • Page 4 Pre-repair checklist • Read the entire manual before starting any service procedures and follow all instructions. • Back up the data on your device. • Place your device on a clean and stable surface. • Turn off your device. • Disconnect all connected peripherals and cables.
  • Page 5 ASUS UX5400 Overview Top View Bottom View ❶ Array Microphone ❶ Air vents ❷ Camera ❷ Audio speakers ❸ Camera indicator ❹ Display panel ❺ Keyboard ❻ Capital lock indicator ❼ Touchpad / ScreenPad ❽ Microphone indicator ❾ Camera off indicator ❿...
  • Page 6 Components Top View LCD MODULE (Touch) MAIN BOARD SP MODULE WIFI ANTENNA HINGE R IMR L IMR LCD Module (non touch) BEZEL SPEAKER SP Touch FPC MIPI_FPC IO BOARD IO FPC TP BD BOTTOM CASE BATTERY TP BD CABLE（touch） CAMERA CABLE(non touch) THERMAL MODULE ASSY KEYBOARD MODULE Back...
  • Page 7 Components Bottom View ACETATE TAPE L:,W:10,T:0.2 LCD MODULE（touch ） KEYBOARD MODULE THERMAL MODULE ASSY ACETATE TAPE L:15,W:10,T:0.2 BEZEL BOTTOM CASE LCD MODULE（ non touch） MAIN BOARD IO BOARD SCREENPAD GASKET MB ABSORBER BTM BATTERY SP MODULE TOP CASE EMI GASKET Back...
  • Page 8 Repair Overview This chapter describes disassembly and assembly (Assemble document please look up from the last page), please follow the information provided in this section to perform the complete disassembly procedure. Precautions: Before you perform any service or repair on the notebook, please pay special attention to the cautions prevent any damages to the notebook. 1.
  • Page 9 Appropriate Tools Please prepare and select the appropriate tools to disassemble/assemble for the notebook. Screwdriver Alcohol 95% Glove Dust-free Cloth Please accord to different screw specification to choose different screwdriver and head. Plastic Blade Thermal Pad (Substitute: G500 Thermal Grease) Plastic Tweezers Use a pair of tweezers to remove/insert/tidy cables.

  • Page 10: Bottom Case

    BOTTOM CASE Disassembly Notice Screws Spec Torque (kgf-cm) Step 1 : Remove BTM CASE FOOT B *2 pc and screws *10 pcs. SCREW M2*4.5L (4,0.8) (K) #1 2±0.1 Step 2 : Use plastic blade to pry the bottom case. SCREW M2*3.7+0.3(3,0.3)(K)+H 2±0.1 Start To avoid the bottom case hook,...

  • Page 11: Disconnect Battery

    Disconnect BATTERY Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Before disassembly battery connector, please be sure to pull out adapter and disconnect the battery more than ten seconds in order to IC damage. Step 1 : Disconnect the battery connector. Disconnect Lift up unlock...
  • Page 12 Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the screws *1 pc and remove the SSD. Screws Spec Torque (kgf-cm) Step 2 : Remove X545FJ THM SSD PAD & THM SSD GS. SCREW M2*2L (4.5,0.6) (K) #1 2.0±0.2 Step 3 : Remove UX392FN THM SSD PAD from the MB.
  • Page 13 BATTERY Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Before disassembly battery connector, please be sure to pull out adapter and disconnect the battery more than ten seconds in order to IC damage. Step 1 : Remove screws *6 pcs. Screws Spec Torque (kgf-cm)
  • Page 14 SPEAKER Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove ACETATE TAPE L:30, W:10 ,T:0.2 (yellow mark)*1 pc. Assembly Notice Step 2 : Disconnect the SPEAKER connector. Step 3 : Remove ACETATE TAPE L:15,W:10,T:0.2 (green mark)*4 pcs. 1.For SPEAKER assembly, please follow the mark below to tidy cable.

  • Page 15: Wlan Antenna

    WLAN ANTENNA Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the ACETATE TAPE L:30, W:10 ,T:0.2 (yellow mark)*1 pc, disconnect the WLAN cable. Step 2 : Remove the WLAN Antenna. Assembly Notice Disconnect 1.For WLAN assembly, please follow the mark below to tidy cable.

  • Page 16: Thermal Module

    THERMAL MODULE Screws Spec Torque (kgf-cm) Disassembly Notice Please be sure to pull out adapter and disconnect the battery. M2*4.5L (4,0.8) (K) #1 2.0±0.1 Step 1 : Remove ACETATE TAPE L:30, W:10 ,T:0.2*1 pc (Blue mark) and disconnect FAN connector. M2*2.5L K B-ZN #1 NY 2.0±0.1 Step 2 : Remove screws*8 pcs.

  • Page 17: Main Board

    MAIN BOARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Screws Spec Torque (kgf-cm) Step 1 : Remove ACETATE TAPE L:30, W:10 ,T:0.2*2pcs (green mark) and disconnect 5 connectors. Step 2 : Remove MB ABSORBER BTM (yellow mark), disconnect & remove IO BD FPC. M2*2L (K)W-NI NY(φ5.0) 2±0.1 Step 3: Disconnect LED CABLE(Blue mark), TP BD CABLE/(non touch)Camera CABLE(purple mark).
  • Page 18 MAIN BOARD Mainboard connector placement Touch BD cable/camera cable(non touch) EDP CABLE IO FFC FP FFC LCM FPC SP FFC SPEAKER BATTERY K/B FPC SP touch FPC BL FFC Back...
  • Page 19 MAIN BOARD Materials on mainboard GPU MYLAR MB FGP SH ASSY MB DECO MYLAR B MB DECO MYLAR A MB ABSORBER TOP EC MYLAR SHIELD CAN CLIP H0.8 MB MYLAR Back...
  • Page 20 IO BOARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove screw *1 pc. Screws Spec Torque (kgf-cm) Step 2 : Remove IO BOARD. M2*2L (K)W-NI NY(φ5.0) 2±0.1 USB ABSORBER TOP USB ABSORBER BTM Remove Remove Back...
  • Page 21 SCREENPAD MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Screws Spec Torque (kgf-cm) Step 1 : Disconnect and remove the SP TOUCH FPC. Step 2 : Release EMI GASKET (yellow mark) *1 pc, disconnect and remove the MIPI_ FPC. M2*2.5L D4.5(K)B-ZN,NY#1 2.0±0.1 Step 3 : Release SCREENPAD GASKET (green mark) *1 pc, remove screws *3 pcs &...

  • Page 22: Keyboard Module

    KEYBOARD MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the KEYBOARD MODULE. Open and remove Back...
  • Page 23 LCD BEZEL & HINGE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove BEZEL. Screws Spec Torque (kgf-cm) Step 2 : Remove screws *10 pcs. M2*2.5L D4.5(K)B-ZN,NY#1 2.0±0.1 Step 3 : Remove screws *4 pcs on hinges & hinge caps. M1.6*2L (3,0.4) (K) #0 2.0 ±...

  • Page 24: Lcd Module

    LCD Module Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove ACETATE TAPE L:30, W:10 ,T:0.2*1 pc . Step 2 : Disconnect TP BD CABLE (touch)/CAMERA CABLE(non touch) & FPC. Step 3 : Remove TP BD. Remove Remove CAMERA CABLE(non touch)
