- Page 1 ASUS ZENBOOK UX5400ZF series Repair Manual...
- Page 3 Service Overview • ASUS is not responsible for direct, indirect, intentional o unintentional damages resulting from improper installation and operation. • Carefully read through this Service Guide for a look at various components of the device before performing any service and repairs.
- Page 4 Pre-repair checklist • Read the entire manual before starting any service procedures and follow all instructions. • Back up the data on your device. • Place your device on a clean and stable surface. • Turn off your device. • Disconnect all connected peripherals and cables.
- Page 5 ASUS ZENBOOK UX5400ZF Overview Top View Bottom View ❶ Array Microphone ❶ Air vents ❷ Camera ❷ Audio speakers ❸ Camera indicator ❹ Display panel ❺ Keyboard ❻ Capital lock indicator ❼ Touchpad / ScreenPad ❽ Microphone indicator ❾ Camera off indicator ❿...
- Page 6 Components Top View ⧫ BASE CASE ⧫ KEYBOARD MODULE ⧫ LCD MODULE (TOUCH) ⧫ LCD MODULE (NON-TOUCH) ⧫ LCD BEZEL ⧫ MAIN BOARD ⧫ IO BOARD ⧫ TOUCH CONTROL BD ⧫ BATTERY ⧫ SSD ⧫ HINGE ⧫ HINGE CAP ⧫ THERMAL MODULE ⧫...
- Page 7 Components Bottom View ⧫ BASE CASE ⧫ KEYBOARD MODULE ⧫ LCD MODULE (TOUCH) ⧫ LCD MODULE (NON-TOUCH) ⧫ LCD BEZEL ⧫ MAIN BOARD ⧫ IO BOARD ⧫ BATTERY ⧫ BATT AL FOIL MB ABSORBER BTM ⧫ BATT PROT MYLAR ⧫ FAN SCREENPAD MODULE Back...
- Page 8 Repair Overview This chapter describes disassembly and assembly (Assemble document please look up from the last page), please follow the information provided in this section to perform the complete disassembly procedure. Precautions: Before you perform any service or repair on the notebook, please pay special attention to the cautions prevent any damages to the notebook. 1.
- Page 9 Appropriate Tools Please prepare and select the appropriate tools to disassemble/assemble for ASUS ZENBOOK UX5400ZF series notebook. Screwdriver Alcohol 95% Glove Dust-free Cloth Please accord to different screw specification to choose different screwdriver and head. Plastic Blade Thermal Pad (Substitute: G500 Thermal Grease) Plastic Tweezers Use a pair of tweezers to remove/insert/tidy cables.
-
Page 10: Bottom Case
BOTTOM CASE Disassembly Notice Screws Spec Torque (kgf-cm) Step 1 : Remove BTM CASE FOOT B *2 pcs. SCREW M2*4.5L (4,0.8) (K) #1 2.0±0.1 Step 2 : Remove screws *10 pcs. Step 3 : Use plastic blade to pry the bottom case. SCREW M2*3.7+0.3(3,0.3)(K)+H 2.0±0.1 Remove... - Page 11 DISCONNECT BATTERY CONNECTOR Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Before disassembly battery connector, please be sure to pull out adapter and disconnect the battery more than ten seconds in order to IC damage. Step 1 : Use the non-conductive pry tool to push iron sheet.
- Page 12 Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the screws *1pc. Screws Spec Torque (kgf-cm) Step 2 : Remove SSD. SCREW M2*3L (K) B-ZN #1 NY 2.0±0.2 Step 3 : Remove THM SSD PAD & THM SSD GS form the SSD. Step 4 : Remove the Thermal PAD from Motherboard.
- Page 13 Please be sure to pull out adapter and disconnect the battery. Assembly Notice When installing the SSD, please keep the SSD Assembly the SSD. less then 15 degrees with motherboard, and 1. Paste the THM SSD PAD to the MB. then insert the SSD.
- Page 14 BATTERY Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Before disassembly battery connector, please be sure to pull out adapter and disconnect the battery more than ten seconds in order to IC damage. Step 1 : Remove screws *6 pcs. Step 2 : Remove battery.
- Page 15 SPEAKER Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove ACETATE TAPE (yellow mark)*1 pc. Step 2 : Disconnect the SPEAKER connector. Assembly Notice Step 3 : Remove ACETATE TAPE *4 pcs. Step 4 : Remove the SPEAKER.
- Page 16 ANTENNA Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the ACETATE TAPE (yellow mark)*1 pc. Step 2 : Disconnect the WLAN cable. Step 3 : Remove the WLAN Antenna. Remove Assembly Notice Please according to below image to assemble RF cable.
- Page 17 THERMAL MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove ACETATE TAPE and disconnect FAN connector. Assembly Notice Step 2 : Remove screws*8 pcs. Follow the screws number (yellow mark) to remove screws from thermal module. Step 3 : Remove thermal module(Thermal + FAN).
-
Page 18: Main Board
MAIN BOARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Screws Spec Torque (kgf-cm) Step 1 : Remove ACETATE TAPE *2 pcs and MB ABSORBER BTM. (Green mark) Step 2 : Disconnect connector* 9pcs.(Yellow mark) M2*2L (K)W-NI NY(φ5.0) 2.0±0.1 Step 3 : Remove screws *13pcs. - Page 19 MAIN BOARD Mainboard connector placement EDP CABLE Touch BD cable/camera cable(non touch SKU) USB CABLE FP FFC SPEAKER BATTERY BL FFC K/B FPC SP FFC LCM FPC SP touch FPC Back...
- Page 20 MAIN BOARD Materials on mainboard SHIELD CAN CLIP H0.8 VGA MYLAR UX5400ZA CPU BKT ASSY MB DECO MYLAR A MB DECO MYLAR B MB MYLAR EC MYLAR MB FGP SH ASSY MB ABSORBER TOP Back...
-
Page 21: Keyboard Module
KEYBOARD MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the KEYBOARD MODULE. Open and remove Back... - Page 22 IO BOARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove screw *1 pc. Screws Spec Torque (kgf-cm) Step 2 : Remove IO BOARD. Step 3 : Remove IO FPC and IO BD. M2*2L (K)W-NI NY(φ5.0) 2.0±0.1 Unscrew...
- Page 23 SCREENPAD MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Screws Spec Torque (kgf-cm) Step 1 : Release TOP CASE EMI GASKET and SCREENPAD GASKET and Remove screws *3pcs. Step 2 : Remove the Screenpad module. M2*2.5L D4.5(K)B-ZN,NY#1 2.0±0.1 Step 3 : Disconnect and remove the SP TOUCH FPC and MIPI_ FPC.
- Page 24 LCD BEZEL & HINGE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove BEZEL. Screws Spec Torque (kgf-cm) Step 2 : Remove screws *10 pcs. M2*2.5L D4.5(K)B-ZN,NY#1 2.0±0.1 Step 3 : Remove screws *4 pcs on hinges & hinge caps. M1.6*2L (3,0.4) (K) #0 2.0 ±...
- Page 25 LCD MODULE (TOUCH) Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove ACETATE TAPE *1 pc. Step 2 : Disconnect connectors *4pcs. Assembly Notice Step 3 : Remove TP BD. For TP board assembly, paste the ACETATE TAPE. Remove Disconnect LCD module(Touch/Non touch) can't be disassembly.
- Page 26 LCD MODULE (NON-TOUCH) Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove ACETATE TAPE and sponge and PANEL GASKET.(*1 pc) Step 2 : Disconnect and remove CAMERA CABLE. Assembly Notice For camera cable assembly, paste the ACETATE TAPE. Remove Disconnect and remove Disconnect...
