- Page 1 ASUS ZENBOOK UX582H series Repair Manual...
- Page 3 Service Overview • ASUS is not responsible for direct, indirect, intentional o unintentional damages resulting from improper installation and operation. • Carefully read through this Service Guide for a look at various components of the device before performing any service and repairs.
- Page 4 Pre-repair checklist • Read the entire manual before starting any service procedures and follow all instructions. • Back up the data on your device. • Place your device on a clean and stable surface. • Turn off your device. • Disconnect all connected peripherals and cables.
- Page 5 ASUS ZENBOOK UX582H series Overview Top View Bottom View ❶ Camera indicator ❷ Camera ❸ Touch Screen panel ❹ Capital lock indicator ❺ Keyboard ❶ Air Vents ❻ Function key lock indicator ❷ Audio speaker ❼ Power button ❽ Touchpad/NumberPad Right View ❶...
- Page 6 Components Top View LCD MODULE MAIN BOARD SPEAKER SSD PAD SUB HINGE SUB HINGE BASE L MAIN LCD TOUCH CABLE TOUCHPANEL CONTROL BD LED MODULE SUB HINGE BASE R LCD PANEL (SMALL BOARD) BATTERY BASE CASE HINGE CAP COVER L HINGE CAP COVER R WIFI ANTENNA TOUCHPAD MODULE...
- Page 7 Components Bottom View KEYBOARD MODULE LCD PANEL TOUCHPANEL CONTROL BD MB TOP MYLAR (SMALL BOARD) BASE CASE TOUCHPAD MODULE THERMAL MAIN BOARD Back...
- Page 8 Repair Overview This chapter describes disassembly and assembly (Assemble document please look up from the last page), please follow the information provided in this section to perform the complete disassembly procedure. Precautions: Before you perform any service or repair on the notebook, please pay special attention to the cautions prevent any damages to the notebook. 1.
- Page 9 Appropriate Tools Please prepare and select the appropriate tools to disassemble/assemble for the ASUS ZENBOOK UX582 series notebook. Screwdriver Alcohol 95% Glove Dust-free Cloth Please accord to different screw specification to choose different screwdriver and head. Plastic Blade Thermal Pad G500 Thermal Grease Plastic Tweezers Use a pair of tweezers to remove/insert/tidy cables.
-
Page 10: Bottom Case
BOTTOM CASE Disassembly Notice Remove bottom case Step 1 : Remove 3 BOT SCREW MYLARS. Step 2 : Use T6 Screwdriver to remove 11 screws. Step 3 : Use plastic blade to pry the bottom case. Step 4 : Remove bottom case. Screws Spec Torque (kgf-cm) - Page 11 SPEAKER Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Before disassembly battery connector, please be sure to pull out adapter and disconnect the battery more than ten seconds in order to IC damage. Step 1 : Disconnect the battery connector. Assembly Notice Step 2 : Disconnect the SPEAKER connector.
- Page 12 BATTERY Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Screws Spec Torque(kgf-cm) Step 1 : Remove 9 screws. Step 2 : Remove BATTERY. SCREW M2*4L (K) B-ZN,NY 2.0±0.2 Assembly Notice For battery assembly, when you replace a new battery please remember paste 2 new BATTERY AL FOIL(red mark) &...
- Page 13 Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Torque (kgf-cm) Step 1 : Remove 1 screw. Screws Spec Step 2 : Remove SSD Pad and SSD. SCREW M2*3L (K) B-ZN 2.0±0.2 Remove SSD Pad Remove 1 screw Back...
- Page 14 LED MODULE AND ANTENNA Assembly Notice Disassembly Notice Please be sure to pull out adapter and disconnect the battery. For Antenna assembly, please follow the mark Step 1 : Disconnect the Keyboard module connector from the MAIN BOARD (red mark). below to tidy cable.
-
Page 15: Thermal Module
THERMAL MODULE (WITH MAIN BOARD) Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Release the tape*2pcs (red mark) & LCD CABLE SPONGE *2 pcs(green mark). Screws Spec Torque (kgf-cm) Step 2 : Disconnect (yellow mark) connectors *6pcs. SCREW M2*2.5L (K) B-ZN,NY 2.0±0.2 Step 3 : Remove screws *5pcs. - Page 16 THERMAL MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Tear off the VGA AL FOIL . Step 2 : Follow the Screws number to remove from thermal (Yellow mark), screws*6pcs(the screws are spring screws ,no need to take them off the thermal. Assembly Notice Step 3 : Remove Thermal from the MB.
- Page 17 Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect (Blue mark) connector*2pcs. Screws Spec Torque (kgf-cm) Step 2 : Remove screws *4pcs. SCREW M2*4L (K) B-ZN,NY 2.0±0.2 Step 3 : Remove FAN *2pcs. Assembly Notice Step-1 Please follow the screws numbers to lock screws *4pcs.
- Page 18 MAIN BOARD CONNECTOR TOUCH PANNEL CONTROL Mainboard connector placement CABLE EDP cable speaker cable BL cable K/B cable BATTERY TP FFC LED Module Second Panel Cable Back...
-
Page 19: Main Board
MAIN BOARD Notice: These sub material is not in 60 BOM, Materials on mainboard when L3/L4 repair finished, no need to add new one.(green color) MB COVER MYLAR UX582HM TOP MOS HP ASM RF TOP ABSORBER HDMI MYLAR MB BOT CPU RF ABSORBER TYPE C MYLAR TOP CASE LED RUBBER MB TOP MYLAR2... -
Page 20: Touchpad Module
TOUCHPAD MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove screws *3pcs. Screws Spec Torque (kgf-cm) Step 2 : Remove the TOUCHPAD MODULE. Step 3 : Tear off the type (Red mark),disconnect the TP FFC from the TOUCHPAD MODULE. SCREW M2*1.5L (4.5,0.5) (K)W-NI 1.2±0.1 Assembly Notice... - Page 21 SECOND LCD MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Tear off the Mylar on the top case. Screws Spec Torque (kgf-cm) Step 2 : Remove 8 Screws from hinges. SCREW M2*3L (K) B-ZN 2.0±0.2 Step 3 : Remove sub hinges.
- Page 22 LCD MODULE & KEYBOARD MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove 8 Screws from Hinge. Screws Spec Torque (kgf-cm) Step 2 : Separate Keyboard module and LCD module. SCREW M2.5*3.5L (K) B-ZN NY #1 2.5±0.1 Step 3 : Remove the hinge cover.
