ON DEMAND WATER HEATER DIRECT
VENT GAS WITH DIRECT SPARK IGNITION
676 Broadway Street | Dayton, TN 37321 USA
423.775.2131 | www.Airxcel.com/Suburban
WARNING
If the information in these instructions is not
followed exactly, a fire or explosion may result
causing property damage, personal injury or
death.
-
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity of
this or any other appliance.
-
WHAT TO DO IF YOU SMELL GAS
Evacuate all persons from the vehicle.
•
Shut off the gas supply at the gas container
•
or source.
•
Do not touch any electrical switch, or use
any phone or radio in the vehicle.
Do not start the vehicle's engine or electric
•
generator.
Contact the nearest gas supplier or qualified
•
service technician for repairs.
If you cannot reach a gas supplier or
•
qualified service technician, contact the
nearest fire department.
Do not turn on the gas supply until the gas
•
leak(s) has been repaired.
-
Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
PN: 206357
INSTALLATION, OPERATION and
MAINTENANCE MANUAL
More information https://www.caravansplus.com.au
FOR INSTALLATION IN
RECREATIONAL VEHICLES
FREEZE WARNING
Drain or fill with RV approved antifreeze if subject
to freezing temperatures when storing for winter.
WARNING
Installation of this appliance must be made in
accordance with the written instruction provided in
this manual. No agent, representative or employee
of Suburban or other person has the authority
to change, modify or waive any provision of the
instructions contained in this manual.
Improper
adjustment,
maintenance or installation can cause serious
injury or death.
Read and follow all instructions and precautions
in this manual. Installation and service must be
performed by a qualified service agency or the gas
supplier.
AN ODORANT IS ADDED TO THE GAS USED BY THIS
•
WATER HEATER.
DO NOT SPRAY AEROSOLS IN THE VICINITY OF
•
THIS APPLIANCE WHILE IT IS IN OPERATION.
DO NOT USE OR STORE FLAMMABLE MATERIALS
•
IN OR NEAR THIS APPLIANCE.
DO NOT PLACE ARTICLES ON OR AGAINST THIS
•
APPLIANCE.
DO NOT MODIFY THIS APPLIANCE
•
THIS APPLIANCE IS NOT INTENDED FOR USE BY
•
YOUNG CHILDREN OR INFIRM PERSONS WITHOUT
SUPERVISION.
YOUNG CHILDREN SHOULD BE
SUPERVISED TO ENSURE THAT THEY DO NOT
PLAY WITH THE APPLIANCE.
INSTALLER: AFFIX THESE INSTRUCTIONS TO OR
•
ADJACENT TO WATER HEATER. OWNER: RETAIN
THESE INSTRUCTIONS AND WARRANTY FOR
FUTURE REFERENCE.
OWNER: RETAIN THESE INSTRUCTIONS AND
•
WARRANTY FOR FUTURE REFERENCE.
ALL TECHNICAL AND WARRANTY QUESTIONS
•
SHOULD
BE
DIRECTED
LISTED ON THE WARRANTY OR RATING PLATE
WHICH CAME WITH YOUR WATER HEATER. GAS
APPLIANCE REPAIR IS NOT A DO IT YOURSELF
TYPE OF REPAIR.
PERFORMED BY A QUALIFIED SERVICE AGENCY.
MODELS:
ST-42A, ST-60A
alteration,
service,
TO
THE
COMPANY
ALL REPAIRS SHOULD BE
Advertisement
Table of Contents
Related Manuals for Airxcel Suburban ST-42A
Summary of Contents for Airxcel Suburban ST-42A
- Page 1 VENT GAS WITH DIRECT SPARK IGNITION ST-42A, ST-60A FOR INSTALLATION IN RECREATIONAL VEHICLES 676 Broadway Street | Dayton, TN 37321 USA 423.775.2131 | www.Airxcel.com/Suburban FREEZE WARNING WARNING Drain or fill with RV approved antifreeze if subject If the information in these instructions is not to freezing temperatures when storing for winter.
-
Page 2: Table Of Contents
Never operate the appliance if you smell gas. Do not assume that the smell of gas in your RV TABLE OF is normal. Any time you detect the odor of gas, it CONTENTS is to be considered life threatening and corrected immediately. -
Page 3: Product Overview
the unit. The thermostat on your water heater is adjustable. It is a temperature sensing limit designed to maintain a water High Pressure Protection - A built-in pressure relief valve • protects the unit from surges of high water pressure. temperature from 95°F (35°C) to 122°F (50°C)(See Operating Instructions.) Water temperatures over 125°F (52°C) can cause severe burns instantly or death rom... - Page 4 any pressure testing of that system at test pressures in in Figure 4. On Mesa or Yoder type sidewalls, flatten the excess of 1/2 PSI (3.5 kPa). wall area around the opening to ensure a proper seal. • The appliance must be isolated from the gas supply 5.
-
Page 5: Operating Safety Information
MAKING WATER CONNECTIONS WARNING WARNING Before leaving - Check all connections for gas leaks This appliance may deliver water at high with soap and water. DO NOT use a naked flame temperature. Refer to the plumbing code of for detecting leaks. Ignite the burner at high and Australia (PCA), local... -
Page 6: Operating Instructions
• This unit has an automatic gas valve, no adjustments are temperature, the ignition cycle is reduced to necessary. Do not attempt to repair the gas valve. This approximately 5 seconds. may result in a fire or explosion. b. Burners will stay ON until the water flow is shut OFF. •... -
Page 7: Maintenance
hot and cold connections to isolate the appliance from the plumbing system. With the bypass valves open, compressed air of pressure no greater than 40 PSI (276 MAINTENANCE kPa) can be used to force water out of the appliance and through a drain line. -
Page 8: Troubleshooting
TROUBLESHOOTING NOTE: There must be a demand of at least 0.7 GPM (2.65 LPM) for the burner to operate and allow water flow. This will continue until the water flow is turned OFF and the system goes dormant. PROBLEM SOLUTION NO WATER FLOWS FROM Be sure water supply is turned ON and there are no water restrictions. - Page 9 Figure 1 Figure 4 SILICONE OR CAULKING AROUND OPENING FRAME DOOR EXHAUST GASKET SCREW DANGER! CORRECT LOCATION INCORRECT LOCATIONS DOOR FRAME Figure 2 CAULKING FRAMED OPENING INNER COACH WALL FRAMING WATER HEATER HOUSING OUTER COACH WALL FLOORING DETAIL A DEMAND WATER HEATER A=330mm +3mm -0mm (13"+1/8"-0") Figure 5 B=330mm +3mm -0mm (13"+1/8"-0")
- Page 10 Figure 6 More information https://www.caravansplus.com.au...
- Page 11 Figure 7 SYMBOL FUNCTION DESCRIPTION WATER This icon is displayed when water is flowing FLOW through the unit (i.e. hot water demand). This icon is displayed when the blower is BLOWER running. FLAME This icon is displayed when the burners are on. OUTLET WATER This icon displays the outlet water temperature...
-
Page 12: Parts Illustration And Parts List
PARTS ILLUSTRATION AND PARTS LIST More information https://www.caravansplus.com.au... - Page 13 ITEM NO. DESCRIPTION MODEL NO. PART NUMBER MODULE BOARD LID 090722 MODULE BOARD HOUSING 090721 MODULE BOARD ST-42 AUSTRALIA ST-42 521453 MODULE BOARD ST-60 AUSTRALIA ST-60 521454 VALVE, GAS 161357 AIRFLOW SENSOR 233658 LIMIT SWITCH (MANUAL RESET) 233676 SENSOR, ANTIFREEZE THERMOSTAT 233675 FLAME SENSOR 233681...
- Page 14 Coast RV Pty Ltd trading as Coast to Coast RV Services ABN 49 097 104 492 - ACN 101 461 330 PO Box 6287, Silverwater NSW 1811 AUSTRALIA Ph (02) 9645 7600 - Fax (02) 9645 7699 Email: warranty@coastrv.com.au Web: www.coastrv.com.au Coast to Coast RV Services PO Box 58-054, Botany AUCKLAND 2163 NEW ZEALAND...
- Page 15 WARRANTY LIMITATIONS The Supplier makes no warranties or representations other than those set out in this warranty document except as is required by law. The Supplier will not be liable under this warranty:- to the Client or any other person for any consequential, direct or indirect loss, damage or costs incurred or suffered by the Client or any other person, including but not limited to damage to persons, other property, loss of turnover, loss of profits, loss of business or goodwill;...
-
Page 16: Warranty Claim Form
WARRANTY CLAIM FORM Warranty Providers Name: Coast RV Pty Ltd trading as Coast to Coast RV Services ABN 49 097 104 492 - ACN 101 461 330 Warranty Providers Address: PO Box 6287, Silverwater NSW 1811 Australia OR; PO Box 58-054 Botany AUCKLAND 2163 New Zealand Client: Contact No.
