OPERATING, INSTALLATION AND SERVICE MANUAL
FOR INSTALLATION IN RECREATIONAL VEHICLES AND MOBILE HOUSING
HOT WATER STORAGE HEATER MODELS
MANUFACTURED BY AIRXCEL, INC. - SUBURBAN DIVISION
DRAIN HEATER IF SUBJECTED TO FREEZING TEMPERATURES
WARNING: IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR
MAINTENANCE CAN CAUSE INJURY OR PROPERTY DAMAGE. REFER TO THIS
MANUAL FOR ASSISTANCE OR FOR ADDITIONAL INFORMATION CONSULT AN
AUTHORIZED INSTALLER OR SERVICE AGENCY.
DO NOT STORE OR USE PETROL, OR OTHER COMBUSTIBLE MATERIALS OR
LIQUIDS NEAR OR ADJACENT TO THIS HEATER OR ANY OTHER APPLIANCE.
THIS APPLIANCE SHALL NOT BE INSTALLED IN ANY OTHER LOCATION WHERE
FLAMMABLE LIQUIDS OR VAPORS ARE LIKELY TO BE PRESENT. WARNING! THIS
APPLIANCE IS UNSUITABLE FOR USE AS A POOL HEATER.
THIS APPLIANCE IS NOT INTENDED FOR USE BY YOUNG CHILDREN OR INFIRM PERSONS WITHOUT
SUPERVISION. YOUNG CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT THEY DO NOT PLAY WITH
THE APPLIANCE.
INSTALLER: AFFIX THESE INSTRUCTIONS TO OR ADJACENT TO THE WATER HEATER.
OWNER: RETAIN THESE INSTRUCTIONS AND WARRANTY FOR FUTURE REFERENCE.
ALL TECHNICAL AND WARRANTY QUESTIONS SHOULD BE DIRECTED TO THE COMPANY LISTED ON THE
WARRANTY, OR RATING PLATE WHICH CAME WITH YOUR HOT WATER HEATER.
All repairs should be performed by a qualified service agency.
SW5EA • SW7EA
FREEZE WARNING
ADDITIONAL SAFETY
Appliance repair is not a do it yourself type of repair.
Suburban Division
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Airxcel SW5EA
Summary of Contents for Airxcel SW5EA
- Page 1 FOR INSTALLATION IN RECREATIONAL VEHICLES AND MOBILE HOUSING HOT WATER STORAGE HEATER MODELS SW5EA • SW7EA Suburban Division MANUFACTURED BY AIRXCEL, INC. - SUBURBAN DIVISION FREEZE WARNING DRAIN HEATER IF SUBJECTED TO FREEZING TEMPERATURES WARNING: IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR MAINTENANCE CAN CAUSE INJURY OR PROPERTY DAMAGE.
-
Page 2: Installation Requirements
SPECIFICATIONS AND DATA FOR SUBURBAN STORAGE HOT WATER HEATER Specifications: Capacity: 17.7 Liters (SW5EA) 26.4 Liters (SW7EA) Maximum Working Pressure: 850 kPa Electrical: Heating Element 240 Volts 50 HZ A.C. 1440 Watts 6 Amp Width: 320mm Height: 320mm Depth: 450mm (SW5EA) 500mm (SW7EA) Location of hot water inlet is 70mm from top dead center. -
Page 3: Safety Warnings
B. The following is information regarding Hot Water Services and corrosion of the INNER COACH WALL tank in Australia. The single biggest factor is metal/water contact. 1. Mains Water Connection- For correct performance and warranty of the OUTER COACH WALL unit, when connected to mains water supply, pressure must be limited to approximately 350 KPA (50 PSI) by the use of a suitable pressure regulator. - Page 4 PRESSURE RELIEF VALVE 240 V.A.C. ONLY The temperature and pressure relief valve is designed to open if the temperature DISCONNECT POWER SUPPLY BEFORE REMOVING COVER of the water within the heater reaches 98.9 degrees Celsius, or if the water pressure in the heater reaches 850 kPa. Recreational vehicle water systems are SUBURBAN MANUFACTURING COMPANY;...
-
Page 5: To Turn Off Water Heater
ODOR FROM HOT WATER SYSTEM TO TURN OFF WATER HEATER Odor from the hot water system is not a service problem and many water supplies contain sufficient amounts of sulphur to produce an odor. The odor is similar to 1. Turn switch to “OFF” position. rotten eggs and is often referred to as “sulphur water”. -
Page 6: Troubleshooting Guide
PROVIDER. PARTS ILLUSTRATION AND REPLACEMENT PARTS LIST PARTS LIST FOR MODELS: SW5EA • SW7EA Only factory authorized parts are to be used. Do not attempt to repair defective parts. When ordering repair parts from your dealer or a distributor, always give the following information: 1. - Page 7 MODEL & SERIAL NO. PLATE Figure 8 INCORRECT INCORRECT Figure 9 Figure 10 CORRECT Figure 11...
- Page 8 RECREATIONAL VEHICLE WATER HEATER LIMITED WARRANTY THIS IS A LIMITED 24 MONTH WARRANTY ONLY!! This water heating product is warranted by Coast to Coast RV Services to the original purchaser to be free from defects in material and workmanship under normal use and maintenance for a period of 24 months from the date of purchase, regardless of the commencement date of use.
