Mediroyal NRX STRAP Web Space Manual

NRX® Strap Web Space
Material
Web space strap: 60 mm NRX® Strap Neptune
Wrist anchor: 80 mm NRX® Strap PLUS
• NRX® Heat Tape 22 mm · EU490001
• NRX® Loop Heat Tape 50 mm · EU490090
• NRX® Thermoplastic kit for Heat Tape · EU490080
• Hook parts
1
Cut a circular wrist anchor of the 80 mm NRX®
Strap PLUS. Take the measurement around the
wrist, add 5 cm to that. Slid the end into two
straps and add hook parts.
3
Attach four hook strips where the thermoplastic
lamination should be positioned.
© Mediroyal Nordic AB 2024
Mediroyal Nordic AB · Box 7052 · 192 07 Sollentuna · Sweden · Tel +46 8 506 766 00 · info@mediroyal.se · www.mediroyal.se
2
Cut a 60 mm NRX® Strap Neptune, should be attached on the volar part
of the anchor and be extended with stretch over to the dorsal side and
attached.
4
Position the material flat with the hook strips in position. Cut an NRX®
Loop Heat Tape to fit in between strips and round the edges. Use one
of the mini sheets in the NRX® Thermoplastic kit for Heat Tape and cut a
piece that fits over the Loop heat tape. Make sure that you have at least
3 mm overlap between. Remove the protection paper and stick the two
materials together and position them between the hook strips. Remove
the strips before lamination.
– One strap, unlimited options!
