- Page 1 BASKET COVER VERSION EN 24.1 Instruction sheet Basket cover...
-
Page 2: General Information
That's why we have developed a lightweight basket cover that can be folded so small that it fits into a basket bag. Space-saving as it is, the basket cover can always be taken along to keep purchases and parcels dry during transportation. -
Page 3: Safety Instructions
This manual uses the following text types and lists: WARNING: Risk of falling and injury Instructions for action (in a fixed order) The muli basket cover only serves to cover → Instructions for action (in any order) the top of the basket and is not designed for transporting loads or people on it. - Page 4 INSTRUCTION SHEET BASKET COVER Assembly Instructions Fitting the basket cover Insert the Loxx screw from the outside of the basket through the perforated plate in the position shown in Fig. 2. Place the washer M5 and the self-locking nut M5 on the thread of the...
- Page 5 INSTRUCTION SHEET BASKET COVER Fit the front press studs at the position shown in Fig. 3. Insert the screw through the push button and guide it through the hole indicated. Fasten the screw from the inside with the M4 washer and the M4 self-locking nut. Use a 3 mm Allen key and 7 mm open-end wrench.
- Page 6 INSTRUCTION SHEET BASKET COVER Covering the open basket To attach the basket cover to the open basket, stretch the basket cover over the basket so that the Velcro fastener points backwards towards the steering tube. (Fig. 5) Important! Always use at least one locking bar...
- Page 7 The Loxx screws in the upper area remain unused. (Fig. 8) Then place the Velcro fastener around the steering tube above the top tube and fix the basket cover. (Fig. 9) FIG.8 FIG.9...
- Page 8 INSTRUCTION SHEET BASKET COVER Imprint BA-EX-14V24.1 © muli cycles GmbH Widdersdorfer Str. 190 50825 Köln Text and graphics muli cycles GmbH Photography Tim Kaiser Illustration Markus Färber Design Friederike Wolf, Frieder Oelze...
- Page 9 INSTRUCTION SHEET www.muli-cycles.com...
