- Page 1 CARRIER VERSION EN 24.1 Instruction sheet muli carrier...
-
Page 2: General Information
The luggage carrier is compatible with all muli models with interchangeable dropouts from model year 2020. As luggage carrier bags are available in a wide range of formats and sizes, we recommend testing the bag on your bike before buying. -
Page 3: Safety Instructions
Text types/lists used Safety instructions This manual uses the following text types and lists: WARNING! Risk of falling and injury The luggage carrier is designed for a maxi- Instruction for action (in a fixed order) → Instructions for action (in any order) mum load of 27 kg. -
Page 4: Tools Required
CAUTION! Risk of injury muli st, px, muscle When using a suitable child seat, it must only be attached to the luggage carrier and not to the seat tube. Otherwise the seat tube may be damaged and accidents may occur. - Page 5 (Fig. 4) Fasten the rear light with the washers and nuts to the retaining plate provided on the luggage carrier. Use an 8 mm open-end wrench for this. (Fig. 5) Attach the cable connectors of the luggage carrier to the rear light.
- Page 6 MONTAGEANLEITUNG CARRIER FIG.5 FIG.7 FIG.6 FIG.8...
- Page 7 5 mm Allen key. Press on the square nut on the inside with one finger. Now place the carrier over the wheel so that the screw-on points of the carrier and frame are on top of each other.
- Page 8 MONTAGEANLEITUNG CARRIER Attach the carrier to the top at the junction of the seat stays. Always use the new stainless steel bolt supplied for this. (Fig. 11) Pull the supplied heat-shrink tubing over the two cables on the front part of the luggage carrier.
- Page 9 MONTAGEANLEITUNG CARRIER In the last step, pull the heat-shrink tubing over the plug connections and heat it with a hot air gun or a lighter so that the heat-shrink tubing fits tightly around the plug connection. (Fig. 14) Lay the cables as shown in Fig. 15.
- Page 10 MONTAGEANLEITUNG CARRIER Assembly instructions st pro FIG.16 BAGGAGE CARRIER SCREWS 2 x M6x20 steel screws 1 x steel screw M6x16 2 x M6 washers 2 x square nut M6 TOOLS REQUIRED 1 x Hexagon socket 4 mm 1 x Hexagon socket 5 mm...
- Page 11 Then loosen the screw connection of the reflector with the Phillips screwdriver. Then remove the reflector from the retaining plate. (Fig. 18) Then attach the reflector to the retaining plate provided on the luggage carrier. (Fig. 19) FIG.18 FIG.17 FIG.19...
- Page 12 Press on the square nut on the inside with one finger. (Fig. 20) Now place the carrier over the wheel so that the screw-on points of the carrier and frame are on top of each other. (Fig. 21)
- Page 13 MONTAGEANLEITUNG CARRIER Imprint FIG.23 BA-EX-13V24.1 ©muli cycles GmbH Widdersdorfer Str. 190 50825 Cologne Text und graphics muli cycles GmbH Photography Tim Kaiser Design Friederike Wolf, Frieder Oelze...
- Page 14 MONTAGEANLEITUNG www.muli-cycles.com...
