MOISWELL Explorer V320 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Explorer V320
USER
MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Explorer V320 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MOISWELL Explorer V320

Summary of Contents for MOISWELL Explorer V320

  • Page 1 Explorer V320 USER MANUAL...
  • Page 3 Welcome Thank you for selecting MOISWELL as your trusted dehumidifier provider! At MOISWELL, we take pride in offering premium commercial and industrial dehumidifiers, available in both vertical and horizontal orientations. Our dehumidifiers are designed to swiftly reduce humidity levels, making them ideal for a wide range of applications, including excess water removal, rapid construction drying, and water damage restoration.

  • Page 4: Before First Use

    BEFORE FIRST USE: Please leave the dehumidifier standing upright and outside the box for 24 HOURS before plugging it in. The dehumidifiers may have been tilted or placed upside down during shipping. Leave the dehumidifier to stand upright for 24 hours so the oil in the compressor can settle from the move, not doing so can affect the performance or lifespan of the dehumidifier.

  • Page 5: Table Of Contents

    CONTENTS Warning For Using R32 Refrigerant ..................1 Parts Identification ........................11 Operation Instructions ......................12 1. Install the Handle ................................... 12 2. Position Your Dehumidifier ............................... 13 3. Set Up the Drainage ..................................13 4. Plug in Electrical Cord .................................. 13 5.

  • Page 6: Warning For Using R32 Refrigerant

    WARNING for Using R32 Refrigerant: Transportation, marking and storage for units that employ flammable refrigerants 1. General The following information is provided for units that employ FLAMMABLE REFRIGERANTS. 2. Transport of equipment containing flammable refrigerants Attention is drawn to the fact that additional transportation regulations may exist with respect to equipment containing flammable gas.
  • Page 7 Qualification of workers The manual shall contain specific information about the required qualification of the working personnel for maintenance, service and repair operations. Every working procedure that affects safety means shall only be carried out by competent persons. Examples for such working procedures are: •...
  • Page 8 a) Commissioning • Ensure that the floor area is sufficient for the REFRIGERANT CHARGE or that the ventilation duct is assembled in a correct manner. • Connect the pipes and carry out a leak test before charging with refrigerant. • Check safety equipment before putting into service. b) Maintenance •...
  • Page 9 --Evacuate the refrigerant circuit. --Purge the refrigerant circuit with nitrogen for 5 min. --Evacuate again. --Fill with nitrogen up to atmospheric pressure. --Put a label on the equipment that the refrigerant is removed. e) Disposal • Ensure sufficient ventilation at the working place. •...
  • Page 10 7. No ignition sources No person carrying out work in relation to a REFRIGERATING SYSTEM which involves exposing any pipe work shall use any sources of ignition in such a manner that it may lead to the risk of fire or explosion.
  • Page 11 Initial safety checks shall include: • that capacitors are discharged: this shall be done in a safe manner to avoid possibility of sparking; • that no live electrical components and wiring are exposed while charging, recovering or purging the system; •...
  • Page 12 15. Removal and evacuation When breaking into the refrigerant circuit to make repairs -or for any other purpose-conventional procedures shall be used. However, for flammable refrigerants it is important that best practice be followed, since flammability is a consideration. The following procedure shall be adhered to: --safely remove refrigerant following local and national regulations;...
  • Page 13 a) Become familiar with the equipment and its operation. b) Isolate system electrically. c) Before attempting the procedure, ensure that: • Mechanical handling equipment is available, if required, for handling refrigerant cylinders; • All personal protective equipment is available and being used correctly; •...
  • Page 14 The recovered refrigerant shall be processed according to local legislation in the correct recovery cylinder, and the relevant waste transfer note arranged. Do not mix refrigerants in recovery units and especially not in cylinders. If compressors or compressor oils are to be removed, ensure that they have been evacuated to an acceptable level to make certain that flammable refrigerant does not remain within the lubricant.
  • Page 15 11. Contact authorized service technician for repair or maintenance of this unit. 12. Do not pull deform. or modify the power supply cord, or immerse it in water. Pulling or misuse of the power supply cord can result in damage to the unit and cause electrical shock. 13.

  • Page 16: Parts Identification

    Parts Identification Handle Control Panel Air Outlet Air Inlet Drain Outlet Power Cord Caster Note: Do not obstruct the air inlet and/or outlet. P.11...

  • Page 17: Operation Instructions

    Operation Instructions 1. Install the Handle 1) Get the handle from the bottom packing foam. 2) Install the handle as illustrated below, please note to align the holes on the handle with the holes on the dehumidifier. 3) Use a screwdriver to tighten the screws until the handle is firmly attached to the dehumidifier. P.12...

  • Page 18: Position Your Dehumidifier

    2.Position Your Dehumidifier For optimal outcomes, use your dehumidifier in a confined space. Shut all entryways and windows. Position it clear of obstructions and avoid anything that could obstruct airflow in or out of the dehumidifier. Note: Place the dehumidifier on a flat surface to minimize vibration or noise. 3.

  • Page 19: Understand The Control Panel

    5. Understand the Control Panel The control panel of the dehumidifier features a user-friendly interface with 4 buttons and an LED screen. Press the POWER Button to turn the dehumidifier on. After turning on the dehumidifier, the LED screen will display the readouts. Power LED Display Timing...

  • Page 20: General Operation Instructions

    Defrosting icon: It illuminates when the dehumidifier detects frost on the interior. During defrosting, the fan operates while the compressor does not, and the defrost icon flashes until the frost melts. The dehumidifier will automatically begin to dehumidify and the “Defrost” icon will disappear once the defrosting process is complete.

  • Page 21: Timer Setting

    7. Timer Setting It enables you to either delay the auto-on or auto-off function of the dehumidifier from 1 to 24 hours. -Set AUTO-ON: When the dehumidifier is off, press the Timer button to set a desired time it begins to work. -Set the dehumidifier AUTO-OFF: When the dehumidifier is on, press the Timer button to set a desired time it shuts off.

  • Page 22: Maintenance

    Maintenance ！ Ensure the dehumidifier is turned OFF and the plug is removed from the power socket before cleaning or maintenance is carried out. (1) Cleaning the Dehumidifier To clean the dehumidifier body, use a soft damp cloth. Do not submerge or pour water on the dehumidifier or control panel, as water can damage the electronic components.

  • Page 23: Trouble Shooting Guide

    Below chart will help you solve common problems may occur. If the problem coming across can not be fixed after troubleshooting or not being listed in the below troubleshooting chart, please contact MOISWELL customer service to get professional support at service@moiswell.com. Problem...
  • Page 24 Problem Possible Cause Solution Set the target humidity percentage value at 10RH%, the dehumidifier works Humidity reading normally, which means this remains at 10RH%, Humidity sensor failure failure does not affect the ( far from the actual function of this dehumidifier. room humidity) Repair and replace the humidity sensor.

  • Page 25: Warranty

    These are our general tems for warranty service, but we always urge our customers to reach out to us with any issue, regardless of warranty terms. If you have an issue with a MOISWELL product, please contact us at service@moiswell.com, and we will do our best to resolve it for you.
  • Page 28 Dehumidify Like a Pro with Moiswell ! 3070400126 2D307-00675（01） 3070400126 2D307-00675(02)
