Summary of Contents for Vantrue E360

  • Page 1 E360 User Manual...

  • Page 3: Table Of Contents

    Contents 1. What’s in the box? 2. Component Instructions 2.1 Camera Overview 2.2 Screen Overview 3. Installation Instructions 3.1 Installing a Memory Card 3.2 Installing the Car Charger 3.3 Installing the Split Adhesive Mount 3.4 Installing the Rear Camera Cable 3.5 Installing the Rear Camera 3.6 Handheld Record Mode Installation 4.
  • Page 4 This product requires a SD card for operation, please use a functioning SD card. Do not disassemble the dash cam or repair it yourself. If the product malfunctions, please contact Vantrue official support. Do not install the dash cam on the position that may obstructs your driving view.

  • Page 5: What's In The Box

    1. What’s in the box? Standard Accessories: A.Vantrue E360 B. GPS Mount C. Car Charger Main Camera （11.5ft） *This device is non-waterproof, please keep it away from water. D. Cable Clip E. Electrostatic F. USB Data Cable Stickers (3.3ft) G. 3M Adhesive...

  • Page 6: Component Instructions

    2. Component Instructions 2.1 Camera Overview 1. Display Screen 10. Power Port 2. Cabin Camera 11. Handheld Mount Battery 3. Emergency Lock Button Indicator (Power Button) 12. Handheld Mount Power 4. Reset Button Button 5. Front Camera 13. Handheld Mount 6.

  • Page 7: Screen Overview

    15. Handheld Mount Fixing Screw 16. Rear Camera 17. Rear Camera Indicator 18. Rear Camera Connection Port Main Camera Indicator Always On In standby status Flashing Slowly Camera is recording Flashing Rapidly Firmware is upgrading Rear Camera Indicator Always On Power on Power off 2.2 Screen Overview...

  • Page 8: Installation Instructions

    3.1 Installing a Memory Card Please insert a memory card into the card slot according to the direction shown in the diagram. We recommend using Vantrue SD card or other SD card with U3 data transfer speed. 3.2 Installing the Car Charger Insert the car charger into the cigarette lighter socket and tuck the cable into the gap along the car's A-pillar.

  • Page 9: Installing The Split Adhesive Mount

    3.3 Installing the Split Adhesive Mount E360 comes with a split adhesive mount. Please remove the base of split adhesive mount and connect the mount to main camera according to the diagram. When installing the mount base, please refer to the recommended installation area shown in the diagram.
  • Page 10 Peel off the protective film from the mount base, attach the mount to the electrostatic stickers and press firmly. Electrostatic Stickers Finally, connect the E360 main camera to the mount. - 6 - - 6 -...

  • Page 11: Installing The Rear Camera Cable

    3.4 Installing the Rear Camera Cable (Rear camera Cable is optional and needs to be purchased separately. It is included in E360 Plus or Ace Bundle.) Please install the rear camera cable following the instructions in the diagram. Adjusting the cable...

  • Page 12: Handheld Record Mode Installation

    4. Menu Overview 4.1 Touchscreen Operation Instructions The menu of E360 dash cam is mainly operated in touch control mode. The following are the touchscreen operation instructions. Start / Pause Recording...
  • Page 13 Note: In handheld mode, default setting is that it will not automatically start recording. Please manually click the recording icon on the screen to start recording. Adjust Screen Display In the recording interface, it can be swiped left or right to switch the screen display.
  • Page 14 Menu Setup Operation After entering the second menu, swipe up or down to browse the menu options. Click a menu option to enter the corresponding menu settings. Click to go back to the previous menu. Drive Record Setup Resolution Drive Record Loop Setup Recording...
  • Page 15 Click the handheld record mode icon to quickly set the handheld record mode resolution. Quick Menu Icon Instructions Click to switch to 5.2K Panorama View 30FPS resolution. Click to switch to Dual Fisheye Lens 30FPS resolution. Click to switch to 1440P+1440P 30FPS 16:9 resolution.
  • Page 16 Quick Menu Icon Instructions In front and cabin recording mode, click to switch to 5.2K Panorama View 30FPS resolution. In front, cabin and rear recording mode, click to switch to 5.2K Panorama View+1440P 30FPS resolution. In front and cabin recording mode, click to switch to Dual Fisheye Lens 30FPS resolution.

  • Page 17: Menu Instructions

    4.2 Menu Instructions 4.2.1 Drive Record Setup Drive Record Setup a. Resolution: The E360 dash cam supports the following resolutions for drive record mode: Front + Cabin + Rear Recording: 5.2K Panoramic View+1440P 30FPS Dual Fisheye Lens+1944P 30FPS Dual Fisheye Lens+1440P 30FPS...
  • Page 18 1440P+1080P 30FPS 1080P+1080P 30FPS Front Recording: Fisheye 30FPS 2592x1944P 30FPS 2592x1944P 60FPS 2560x1440P 30FPS 2560x1440P 60FPS 1920x1080P 30FPS Loop Recording: Default setting is 1 Minute. There are 4 options for you to select: Off, 1 Minute, 3 Minutes and 5 Minutes. IR LEDs: The IR LED lights switch mode for front camera and cabin camera can be set separately.
  • Page 19 Stamp: Enable or disable the watermark stamp on videos and photos. The watermark stamp includes time and date label, VANTRUE label, license plate number, GPS location information, and speed label. All enabled by default. Time Lapse: Default setting is Off. There are 5 options for you to select: Off, 1FPS, 5FPS, 10FPS and 15FPS.
  • Page 20 4.2.2 Handheld Record Setup Handheld Record Setup Resolution: Handheld Record Mode only supports setting the resolution for front and cabin cameras, it contains 8 options: 5.2K Panoramic View 30FPS Dual Fisheye Lens 30FPS Fisheye+Fisheye 30FPS 1944P+1944P 30FPS 4:3 1440P+1440P 30FPS 16:9 1440P+1440P 60FPS 16:9 1440P+1440P 30FPS 9:16 1440P+1440P 60FPS 9:16...
  • Page 21 VANTRUE label, license plate number, GPS location information, and speed label. All enabled by default. The default setting for the E360 dash cam is drive record mode, please swipe up from the bottom of recording interface to enter the quick menu and select handheld record mode.
  • Page 22 Wi-Fi needs to be turned on manually if you select “Off”. Wi-Fi Mode: Default setting is 5G. After turning on, you can connect the Wi-Fi and operate the E360 dash cam through phone. Wi-Fi Info: Wi-Fi name and password can be checked here.
  • Page 23 50Hz or 60Hz frequency according to your region. System Info: Check the current model, firmware version and Vantrue official website URL. Certification Info: The certification information of the dash cam can be checked here. Default Settings: Reset the dash cam to its default system settings.
  • Page 24 10:12:27 2024/10/30 10:12:27 00:30 01:07 Different types of files in the E360 dash cam are displayed as below, you can find relevant files based on the corresponding type. File Type Instructions: A Front camera video file B Cabin camera video file 20300128_140933_00008_N_A.MP4...

  • Page 25: Function Instructions

    5. Function Instructions This section mainly introduces the connection between the E360 dash cam and the APP, the main functions of the APP, drive record mode and handheld record mode, to help users quickly understand and use the E360 dash cam.
  • Page 26 The initial WiFi password is 12345678. If you forget the set password, it can be restored to the initial password by resetting the dash cam to its default settings. - 22 -...
  • Page 27 To avoid privacy leaks, it is recommended that users change the initial WiFi password. The WiFi password can be set in the Vantrue APP. - 23 -...

  • Page 28: Main Functions Of App

    5.2 Main Functions of APP Setup Click to turn on Mileage 360 display Statistics mode. Lens Full Screen Calibration Switch Line Microphone Switch Start/Pause Recording Lens Switch Snapshot View Files After entering the live preview interface of the APP, you can perform the following operations: Video Preview: Once the APP is connected successfully, it will enter the live preview interface.
  • Page 29 Lens Calibration Line: Calibrate lens balance by the precise cross-line, ensuring that the recording image will not be skewed. OTA Upgrade: Upgrade the E360 dash cam via the APP. - 25 -...
  • Page 30 Share Video: After downloading the video, you can edit it in the playback interface and share it on social media platforms. Share 2021/12/16 11:5:35 X4S 2024/10/30 11:5:35 E360 000.000000. 000.000000. 36MK/H 000.000000. 000.000000. 36MK/H Album Facebook Youtube Twitter Instagram Behance...

  • Page 31: Drive Record Mode

    5.3 Drive Record Mode The E360 dash cam primarily operates in drive record mode when driving. The following are the main functions Instructions of drive record mode: ---Loop Recording The dash cam will automatically enter loop recording mode upon startup, and it will save video files in the standard video folder based on the preset loop duration.

  • Page 32: Voice Control

    automatically saved in the event video folder, and the snapshot photos will be saved in the photo folder. 5.2K +1440P 30FPS 00:00:37 2024/10/30 14:09:07 MP/H ---Voice Control Users can control the dash cam by voice commands such as Take Photo, Video Start, Turn On/Off Wi-Fi, Lock The Video,etc.
  • Page 33 • GPS information is recorded in the video. To view it, please download and install the Vantrue APP and Vantrue GPS Player. GPS Automatic Update for Time & Date is turned on by default. Please select the correct time zone. For example, if in Los Angeles, please choose GMT-08:00.

  • Page 34: Parking Mode

    Vantrue hardwire kit or other external battery with stable and constant power. • Please use the Vantrue ACC hardwire kit. The ACC hardwire kit from other brands might not work due to different ACC detection PIN positions.
  • Page 35 When triggered by a collision, the dash cam will record for 1 minute and save the video file in the parking video folder. The video can be playbacked via the Vantrue APP on phone or the Vantrue GPS player on computer. 5.2K...
  • Page 36 Mode 3: Low Bitrate Mode In low bitrate mode, all camera’s resolution will automatically switch to 1080P 15FPS or 720P 15FPS with a recording duration of 3 minutes. The video will be saved in the parking video folder. 5.2K +1440P 30FPS 5.2K +1440P 30FPS 00:00:37...
  • Page 37 ---Parking Monitor Settings This feature allows the adjustment of various parking monitor settings to enhance accuracy and flexibility. Parking Monitor Drive Record Setup Settings Detection Lens Parking Mode Setting Parking Monitor Low Light Night Settings Vision in Parking Mode Setting 1: Detection Lens Setting After enabling any of parking modes, all cameras can detect.

  • Page 38: Handheld Record Mode

    Collision Detection Quick Start Mode in Parking Mode 5.4 Handheld Record Mode ---The E360 dash cam supports various scenarios. It can be removed from the windshield and used with a handheld mount for easy recording of camping, gatherings, meetings, and more.
  • Page 39 5.2K +1440P 30FPS 00:00:37 2024/10/30 14:09:07 MP/H ---The handheld mount can be charged by Vantrue Hardwire kit, car charger, external battery pack, etc. Vantrue Car Charger Hardwire Kit External Battery Pack - 35 -...

  • Page 40: Firmware Upgrade

    5.5 Firmware Upgrade To constantly optimize the features of E360 dash cam, we will periodically update the firmware. Please check it on Vantrue official website and upgrade the firmware in a timely manner. Upgrade Method 1: File Upgrade Download the newest firmware file from Vantrue...
  • Page 41 Upgrade Method 2: OTA(Over the Air) Upgrade Open the APP, you will receive a firmware update push notification. After confirming the upgrade, it will jump to the OTA upgrade interface, where you can follow the guide to complete the upgrade. - 37 -...

  • Page 42: Specifications

    • downloading firmware. For file upgrade, please format the memory card on • the E360 dash cam before placing the firmware file into it. 6. Specifications To provide users with a better using experience, we may upgrade the product specifications without prior notice.

  • Page 43: Warranty & Support

    -4℉ to 158℉(-20℃ to 70℃) Temperature 7. Warranty & Support The Vantrue E360 dash cam comes with a 12-month warranty. If you register the dash cam on Vantrue official website (http://www.vantrue.net/register), the warranty can be extended to 18 months. If you have...
