G893-SD1-AAX3
G893-SD1-AAX5
HPC/AI Server - 5th/4th Gen Intel® Xeon® Scalable
8U DP NVIDIA HGX™ H200 8-GPU (AAX3)
8U DP NVIDIA HGX™ B200 8-GPU (AAX5)
User Manual
Rev. 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G893-SD1-AAX3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gigabyte G893-SD1-AAX3

Summary of Contents for Gigabyte G893-SD1-AAX3

  • Page 1 G893-SD1-AAX3 G893-SD1-AAX5 HPC/AI Server - 5th/4th Gen Intel® Xeon® Scalable 8U DP NVIDIA HGX™ H200 8-GPU (AAX3) 8U DP NVIDIA HGX™ B200 8-GPU (AAX5) User Manual Rev. 1.0...
  • Page 2 For GIGABYTE distributors and resellers, additional sales & marketing materials are available from our reseller portal: http://reseller.b2b.gigabyte.com For further technical assistance, please contact your GIGABYTE representative or visit https://esupport.gigabyte.com/ to create a new support ticket For any general sales or marketing enquiries, you may also message GIGABYTE server directly by email: server.grp@gigabyte.com...
  • Page 3 Conventions The following conventions are used in this user's guide: NOTE! Gives bits and pieces of additional information related to the current topic. CAUTION! Gives precautionary measures to avoid possible hardware or software problems. WARNING! Alerts you to any damage that might result from doing or not doing specific actions.

  • Page 4: Server Warnings And Cautions

    Server Warnings and Cautions Before installing a server, be sure that you understand the following warnings and cautions. WARNING! To reduce the risk of electric shock or damage to the equipment: • Do not disable the power cord grounding plug. The grounding plug is an important safety feature. •...

  • Page 5: Electrostatic Discharge (Esd)

    Electrostatic Discharge (ESD) CAUTION! ESD CAN DAMAGE DRIVES, BOARDS, AND OTHER PARTS. WE RECOMMEND THAT YOU PERFORM ALL PROCEDURES AT AN ESD WORKSTATION. IF ONE IS NOT AVAILABLE, PROVIDE SOME ESD PROTECTION BY WEARING AN ANTI-STATIC WRIST STRAP AT- TACHED TO CHASSIS GROUND -- ANY UNPAINTED METAL SURFACE -- ON YOUR SERVER WHEN HANDLING PARTS.

  • Page 6: Table Of Contents

    Table of Contents Chapter 1 Hardware Installation ..................9 Installation Precautions ..................9 Product Specifications ..................10 System Block Diagram ................... 13 PCIe Block Diagram ..................14 Chapter 2 System Appearance ..................15 Front View ...................... 15 Rear View ....................... 16 Top View ......................17 Front Panel LED and Buttons ................
  • Page 7 Motherboard Components ................49 Jumper Setting ....................51 Backplane Board Storage Connector ............52 4-3-1 CBPG641 .......................52 Chapter 5 BIOS Setup ....................56 The Main Menu ....................58 Advanced Menu ..................... 61 5-2-1 Trusted Computing ....................62 5-2-2 Serial Port Console Redirection ................63 5-2-3 SIO Configuration ....................66 5-2-4...
  • Page 8 5-4-2 View FRU Information ..................112 5-4-3 BMC VLAN Configuration ..................113 5-4-4 BMC Network Configuration .................114 5-4-5 IPv6 BMC Network Configuration .................115 Security Menu ....................116 5-5-1 Secure Boot ......................117 Boot Menu ....................120 Save & Exit Menu ..................122 BIOS Recovery .................... 124 - 8 -...

  • Page 9: Chapter 1 Hardware Installation

    Chapter 1 Hardware Installation Installation Precautions The motherboard/system contain numerous delicate electronic circuits and components which can become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read the user manual and follow these procedures: • Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or warranty sticker provided by your dealer.

  • Page 10: Product Specifications

    Product Specifications NOTE: We reserve the right to make any changes to the product specifications and product-related information without prior notice. System Š 447 x 351 x 900 (W x H x D, mm) Dimension Š Socket Security Server Operating Properties 5th Generation Intel®...
  • Page 11 Intel® SATA RAID 0/1/10/5 Š Socket Security Server Operating Properties System fan System fan System fan Power Supply Modular GPU G893-SD1-AAX3 NVIDIA HGX™ H200 with 8 x SXM GPUs Š System fan System fan System fan Power Supply Socket Security Server Operating Properties...
  • Page 12 The system power supply requires C19 power cord. [Note] GIGABYTE offers PSUs with various efficiency ratings and power outputs. Full redundancy may depend on your server configuration, and alternative PSU options may be needed. Please contact our sales representatives for the best power solution.

  • Page 13: System Block Diagram

    System Block Diagram Hardware Installation - 13 -...

  • Page 14: Pcie Block Diagram

    PCIe Block Diagram CPU0 Domain CPU1 Domain Rear Side B200 H200 GPU2 GPU0 GPU5 GPU7 GPU2 GPU0 GPU5 GPU7 SLOT 12 SLOT 2 SLOT 11 SLOT 1 NVSW1 NVSW2 GPU1 GPU3 GPU6 GPU4 GPU1 GPU3 GPU6 GPU4 NVSW0 NVSW1 NVSW2 NVSW3 HDD0 HDD4 HDD1...

  • Page 15: System Appearance

    Chapter 2 System Appearance Front View G893-SD1-AAX3 GPU_80 GPU_80 GPU_80 GPU_80 GPU_80 11/12 13/14 15/16 17/18 19/20 GPU_80 GPU_80 GPU_80 GPU_80 GPU_80 21/22 23/24 25/26 27/28 29/30 HDD0 HDD4 HDD1 HDD5 HDD2 HDD6 HDD3 HDD7 G893-SD1-AAX5 GPU_80 GPU_80 GPU_80 GPU_80...

  • Page 16: Rear View

    Rear View R_80 R_80 R_80 PSU12 PSU5 PSU11 PSU4 PSU10 PSU3 R_80 R_80 R_80 PSU9 11/12 9/10 PSU2 PSU8 PSU7 PSU6 PSU1 SLOT 12 SLOT 2 SLOT 11 SLOT 1 Description PCIe Card Cage x 2 PCIe Slot x 8 Management LAN Port System Appearance - 16 -...

  • Page 17: Top View

    Top View No. Description Power Supply Unit x 5 (Top) PCIe Slot x 2 (Bottom) Rear_BP_80_FAN_7/8 (Bottom) Power Supply Unit x 1 PCIe Slot x 8 Rear_BP_80_FAN_5/6 Rear_BP_80_FAN_3/4 Power Supply Unit x 1 SYS_40_FAN3/4 PCIe Slot x 2 (Bottom) Rear_BP_80_FAN_1/2 (Bottom) CPU0 DDR5 Memory CPU0 CPU1...

  • Page 18: Front Panel Led And Buttons

    Front Panel LED and Buttons Name Color Status Description Reset Button Press the button to reset the system. Press the button server generates a NMI to the processor NMI button if the multiple-bit ECC errors occur, which effectively halt the server. HDD locate Green Blink...

  • Page 19: Rot Leds

    2-4-1 RoT LEDs Status LED ID LED LED on Front panel (Note5) ID LED Status LED EC Firmware (FW) Authentication fail or not exit EC FW is broken or not exit (Note1) Authenticating/Recovering BMC/BIOS Images Authenticating Images Blinks Blue Blinks Green Recovering BMC Active Flash 4 times per 4 times per...
  • Page 20 Blinks Blue Blinks Green 2 times per 2 times per BMC : AUTH fail after doing recovery (Note3) second second [ON OFF OFF] [ON OFF OFF] Blinks Blue Blinks Amber 2 times per 2 times per BIOS : AUTH fail after doing recovery (Note3) second second...

  • Page 21: Front Panel System Lan Leds

    Front Panel System LAN LEDs Name Color Status Description Green 10 Gbps data rate 10GbE Yellow 5Gbps, 2.5Gbps, 1Gbps data rate Speed LED 100 Mbps data rate Link between system and network or no access Green 10GbE Link / Blink Data transmission or reception is occurring.

  • Page 22: Power Supply Unit (Psu) Led

    Power Supply Unit (PSU) LED NOTE! The power supply may be vary based on the system configuration. PSU LED State Description No AC power to all power supplies 1Hz Green Blinking AC present / only standby on / Cold redundant mode 2Hz Green Blinking Power supply firmware updating mode AC cord unplugged or AC power lost;...

  • Page 23: Hard Disk Drive Leds

    Hard Disk Drive LEDs HDD Present RAID SKU Rebuilding LED1 Locate HDD Fault Access (No Access) Disk LED Green ON(*1) BLINK (*2) (LED on Back Panel) Amber No RAID configuration Green ON(*1) (via PCH, HBA) Removed HDD Slot (LED on Back Panel) Amber Green BLINK (*2)

  • Page 24: Chapter 3 System Hardware Installation

    Chapter 3 System Hardware Installation Pre-installation Instructions Computer components and electronic circuit boards can be damaged by electrostatic discharge. Working on computers that are still connected to a power supply can be extremely dangerous. Follow the simple guidelines below to avoid damage to your computer or injury to yourself.

  • Page 25: Removing And Installing The Chassis Top Cover

    Removing and Installing the Chassis Top Cover Before you remove or install the chassis top cover • Make sure the system is not turned on or connected to AC power. Follow these instructions to remove/install the chassis top cover: Remove the screw securing the chassis cover. Push button to unlock the handle.

  • Page 26: Removing And Installing The Gpu Tray

    Removing and Installing the GPU Tray Before you remove or install the GPU tray: • Make sure the system is not turned on or connected to AC power. Follow these instructions to remove/install the GPU tray: Loosen the thumbnail screw securing the handles on both sides of the system. Pull the grip handles on both sides of the system slide the tray to the front of the system at the same time to pull out the tray.

  • Page 27: Removing And Installing The Motherboard Tray

    Removing and Installing the Motherboard Tray Before you remove or install the Motherboard tray: • Make sure the system is not turned on or connected to AC power. Follow these instructions to remove/install the Motherboard tray: Loosen the thumbnail screw securing the handles on both sides of the system. Pull the grip handles on both sides of the system slide the tray to the front of the system at the same time to pull out the tray.

  • Page 28: Removing The Heat Sink

    Removing the Heat Sink Read the following guidelines before you begin to remove/install the heat sink: • Always turn off the computer and unplug the power cord from the power outlet before installing the heat sink to prevent hardware damage. •...

  • Page 29: Installing The Cpu

    Installing the CPU Read the following guidelines before you begin to install the CPU: • Make sure that the motherboard supports the CPU. • Always turn off the computer and unplug the power cord from the power outlet before installing the CPU to prevent hardware damage.
  • Page 30 Carrier Types used for Package Types Package Type Xeon® SP XCC Xeon® SP MCC Xeon® SP+HBM Carrier Code NOTE! • The carrier code is marked on each carrier and matches a code laser marked on to the IHS(Integrated Heat Spreader) to ensure the right parts are used together •...

  • Page 31: Installing The Memory

    Installing the Memory Read the following guidelines before you begin to install the memory: • Make sure that the motherboard supports the memory. It is recommended that memory of the same capacity, brand, speed, and chips be used. • Always turn off the computer and unplug the power cord from the power outlet before installing the memory to prevent hardware damage.
  • Page 32 3-6-2 Installing the Memory Before installing a memory module, make sure to turn off the computer and unplug the power cord from the power outlet to prevent damage to the memory module. Be sure to install DDR5 DIMMs on this motherboard. Make sure your DIMM slots have a single latch or a double latch.

  • Page 33: Dimm Population Table

    3-6-3 DIMM Population Table Gen Intel Xeon Scalable Processors Memory Support Speed (MT/s); Voltage (V); DIMM per Channel (DPC) Ranks Per DIMM and DIMM Capacity (GB) Type Data Width 1DPC 2DPC 16Gb 24Gb 36Gb 1.1V SRx8 (RC D) 16GB 24GB SRx4 (RC C) 32GB 48GB...

  • Page 34: Installing The Pci Expansion Card

    Installing the PCI Expansion Card • Voltages can be present within the server whenever an AC power source is connected. This voltage is present even when the main power switch is in the off position. Ensure that the system is powered-down and all power sources have been disconnected from the server prior to installing a PCIe card.
  • Page 35 Middle PCIe Card Cage Loosen the thumbnail screws securing the handle of the PCIe card cage. Pull the cage out of the system. Lift the fan duct and remove it. Align the PCIe card with the slot and push it towards the arrow until it is securely seated in the PCIe card connector.
  • Page 36 Right PCIe Card Cage Loosen the thumbnail screw securing the handle of the PCIe card cage. Pull the cage out of the system. Remove the screws securing the MLAN tray, in the specified sequence. Lift the MLAN tray and remove it. Remove the screw securing the slot cover to the riser bracket.

  • Page 37: Installing The Hard Disk Drive

    Installing the Hard Disk Drive Read the following guidelines before you begin to install the hard disk drive: • Take note of the drive tray orientation before sliding it out. • The tray will not fit back into the bay if inserted incorrectly. •...

  • Page 38: Replacing The System Fan Module

    Replacing the System Fan Module CAUTION! Before you remove or install the system fans follow these steps: • Disconnect all necessary cable connections. Failure to observe these warnings could result in personal injury or damage to the equipment Follow these instructions to replace the GPU fan assembly: Loosen the thumbnail screw securing the handle of the fan module.
  • Page 39 Internal System Fan Remove the edge saddle by pulling it away from the fan assembly. Lift the fan assembly from the chassis. Reverse the previous steps to install the replacement fan assembly. System Hardware Installation - 39 -...

  • Page 40: Removing And Installing The Power Supply

    3-10 Removing and Installing the Power Supply CAUTION! Please see Section 2-2 "Rear View" for installation sequence. Follow these instructions to replace the power supply: Flip and then grasp the power supply handle. Press the retaining clip on the right side of the power supply in the direction indicated. Pull out the power supply using the handle.

  • Page 41: Installing The System Into The Cabinet

    3-11 Installing the System into the Cabinet Read the following guidelines before you begin to install the system into the cabinet: • Make sure the system is not turned on or connected to AC power. • A Lift Table is required. Place the system unit on Lift Table. •...

  • Page 42: Removing The System From The Cabinet

    3-12 Removing the System from the Cabinet Read the following guidelines before you begin to remove the system from the cabinet: • Always turn off the computer and unplug the power cord from the power outlet before removing the system from the cabinet. •...
  • Page 43 NOTE! • Before lifting the system, installing the four chassis handles on the system is required. Follow these instructions to install the chassis handles on the system: Attach the four chassis handles to the system. Push and lock the thumbnail screw to secure the chassis handle in place. System Hardware Installation - 43 -...

  • Page 44: Cable Connection

    3-13 Cable Connection CPU1 CPU0 Motherboard: F_USB3 Front USB 3.0 Cable Front IO Board: F_USB3_CON Motherboard: FP_IO Front IO Board Signal Cable Front IO Board: FP_IO Motherboard: VGA_CON Front IO VGA Cable Front IO Board: F_VGA1_CON Motherboard: FP_LAN Front IO Board LAN Cable Front IO Board: FP_MLAN Motherboard: FP_PWR Front IO Board Power Cable...
  • Page 45 CPU1 CPU0 Rear LAN Board: U2_PE1 Rear LAN to Motherboard Motherboard: Signal Cable A1: U2_P0_PE1A A2: U2_P0_PE1B Rear LAN Board: U2_PE1 Rear LAN to Motherboard Motherboard: Signal Cable B1: U2_P1_PE1A B2: U2_P1_PE1B Rear LAN Board: REAR_MLAN Rear LAN to Front IO LAN Signal Cable Front IO Board: CN_LAN_F System Hardware Installation...
  • Page 46 CPU1 CPU0 Motherboard: BP_1 HDD Backplane Board Signal Cable Front HDD Board: BP_1 Left Front HDD Board: BP_SERIES HDD Backplane Board Signal Cable Right Front HDD Board: BP_1 Motherboard: BP_PWR1 HDD Backplane Board Power Cable Left Front HDD Board: BP_PWR Motherboard: BP_PWR2 HDD Backplane Board Power Cable Right Front HDD Board: BP_PWR...
  • Page 47 CPU1 CPU0 Motherboard: SL_CN1 SATA Cable Left Front HDD Board: SL_CN1 Motherboard: SL_CN2 SATA Cable Right Front HDD Board: SL_CN1 System Hardware Installation - 47 -...
  • Page 48 CPU1 CPU0 HDD0 HDD4 HDD1 HDD5 HDD2 HDD6 HDD3 HDD7 Motherboard: Motherboard: U2_PEX0 U2_PEX2 NVMe 0-1 NVMe 4-5 Cable Cable Front HDD Board: Front HDD Board: U2_0 U2_0 Motherboard: Motherboard: U2_PEX1 U2_PEX3 NVMe 2-3 NVMe 6-7 Cable Cable Front HDD Board: Front HDD Board: U2_1 U2_1...

  • Page 49: Chapter 4 Motherboard Components

    Chapter 4 Motherboard Components Motherboard Components BMC2 BMC1 BIOS2 BIOS1 13 12 CPU1 CPU0 Item Description 2 x 4 Pin Front Panel Power Connector (FP_PWR) 2 x 3 Backplane Power Connector (BPB_PWR2) FAN_11/FAN_12 Connector FAN_9/FAN_10 Connector FAN_7/FAN_8 Connector FAN_5/FAN_6 Connector Battery Cable Connector FAN_3/FAN_4 Connector FAN_1/FAN_2 Connector...
  • Page 50 Item Description MCIO Connector (U2_P0_PE1A/PCIe Gen5) SlimLine Connector (HDD Backplane Board SATA Signal/SL_CN2) SlimLine Connector (HDD Backplane Board SATA Signal/SL_CN1) M.2 Slot (PCIe Gen3 x2, Support NGFF-22110) Front USB 3.2 Gen1 Connector Motherboard Power Connector (MB_PWR1/MB_PWR2) Power Distribution Board Connector (PDB_IO) PCIe Signal Connector (EX_SXMJ3-6) Guide Pin Connector (GP1) PCIe Signal Connector (EX_SLT1_3/EX_SLT2_3_EX_SLT4)

  • Page 51: Jumper Setting

    Jumper Setting Clear CMOS Enable CLR_CMOS Default SW_PLD SW_PLD2 CPU1 CPU0 SW_PLD HSMB_SEL BMC Control PCH [Default] SPD_SW BMC Control PCH [Default] S3_MASK Stop initial power on when BMC is not ready Normal [Default] FORCE_PWRON Force power on mode Normal [Default] SW_PLD2 ME_UPDATE ME force update mode...

  • Page 52: Backplane Board Storage Connector

    Backplane Board Storage Connector 4-3-1 CBPG641 Item Description MCIO 8i (SFF-TA-1016 / U2_1 MCIO 8i (SFF-TA-1016 / U2_0) MCIO 4i (SFF-TA-1016 / SL_CN1) - 52 - Motherboard Components...

  • Page 53: Chapter 5 Bios Setup

    Chapter 5 BIOS Setup BIOS (Basic Input and Output System) records hardware parameters of the system in the EFI on the motherboard. Its major functions include conducting the Power-On Self-Test (POST) during system startup, saving system parameters, loading the operating system etc. The BIOS includes a BIOS Setup program that allows the user to modify basic system configuration settings or to activate certain system features.

  • Page 54: Server Management

     Main This setup page includes all the items of the standard compatible BIOS.  Advanced This setup page includes all the items of AMI BIOS special enhanced features. (ex: Auto detect fan and temperature status, automatically configure hard disk parameters.) ...

  • Page 55: The Main Menu

    The Main Menu Once you enter the BIOS Setup program, the Main Menu (as shown below) appears on the screen. Use arrow keys to move among the items and press <Enter> to accept or enter other sub-menu. Main Menu Help The on-screen description of a highlighted setup option is displayed on the bottom line of the Main Menu.
  • Page 56 Parameter Description BIOS Information Project Name Displays the project name information. Project Version Displays version number of the BIOS setup utility. Build Date and Time Displays the date and time when the BIOS setup utility was created. BMC Information (Note1) BMC Firmware Version Displays BMC firmware version information.
  • Page 57 Parameter Description Memory Frequency Displays the frequency information of the installed memory. Onboard LAN Information (Note3) LAN# MAC Address Displays LAN MAC address information. System Date Sets the date following the weekday-month-day-year format. System Time Sets the system time following the hour-minute-second format. (Note3) The number of LAN ports listed will depend on the motherboard / system model.

  • Page 58: Advanced Menu

    Advanced Menu The Advanced Menu displays submenu options for configuring the function of various hardware components. Select a submenu item, then press <Enter> to access the related submenu screen. BIOS Setup - 61 -...

  • Page 59: Trusted Computing

    5-2-1 Trusted Computing Parameter Description Configuration Enable/Disable BIOS support for security device. OS will not show security device. TCG EFI protocol and INT1A interface will not be TPM v1.2 Support available. Options available: Disable, Enable. Default setting is Enable. BIOS Setup - 62 -...

  • Page 60: Serial Port Console Redirection

    5-2-2 Serial Port Console Redirection Parameter Description Console redirection enables the users to manage the system from a COM1 Console remote location. Redirection (Note) Options available: Enabled, Disabled. Default setting is Disabled. Press [Enter] to configure advanced items. Please note that this item is configurable when COM1 Console Redirection is set to Enabled.
  • Page 61 Parameter Description Parity Š – A parity bit can be sent with the data bits to detect some transmission errors. – Even: parity bit is 0 if the num of 1's in the data bits is even. – Odd: parity bit is 0 if num of 1's in the data bits is odd. –...
  • Page 62 Parameter Description Serial Port for Out-of-Band Management / Windows EMS console redirection allows the user to configure Console Redirection Emergency Management Settings to support Out-of-Band Serial Port management. Services (EMS) Console Options available: Enabled, Disabled. Default setting is Disabled. Redirection (Note) Press [Enter] to configure advanced items.

  • Page 63: Sio Configuration

    5-2-3 SIO Configuration Description Parameter Displays the AMI SIO driver version information. AMI SIO Driver Version Super IO Chip Logical Device(s) Configuration Press [Enter] to configure advanced items. Use This Device Š – When set to Enabled allows you to configure the serial port settings. When set to Disabled, displays no configuration for the serial port.

  • Page 64: Pci Subsystem Settings

    5-2-4 PCI Subsystem Settings BIOS Setup - 67 -...
  • Page 65 Parameter Description PCI Bus Driver Version Displays the PCI Bus Driver version information. When enabled, this setting will initialize the device expansion SLOT_# I/O ROM ROM for the related PCIe slot. (Note1) Options available: Enabled, Disabled. Default setting is Enabled. When enabled, this setting will initialize the device expansion SMX_# I/O ROM (Note2)

  • Page 66: Usb Configuration

    5-2-5 USB Configuration Parameter Description USB Configuration USB Devices: Displays the USB devices connected to the system. Enable/Disable the XHCI (USB 3.0) Hand-off support. XHCI Hand-off Options available: Enabled, Disabled. Default setting is Enabled. USB Mass Storage Driver Enable/Disable the USB Mass Storage Driver Support. Support Options available: Enabled, Disabled.

  • Page 67: Network Stack Configuration

    5-2-6 Network Stack Configuration Parameter Description Enable/Disable the UEFI network stack. Network Stack Options available: Enabled, Disabled. Default setting is Enabled. Enable/Disable the Ipv4 PXE feature. Ipv4 PXE Support Options available: Enabled, Disabled. Default setting is Enabled. Enable/Disable the Ipv4 HTTP feature. Ipv4 HTTP Support Options available: Enabled, Disabled.

  • Page 68: Post Report Configuration

    5-2-7 Post Report Configuration Parameter Description Post Report Configuration Error Message Report Enable/Disable the POST Error Message support. Post Error Message Options available: Enabled, Disabled. Default setting is Enabled. Halt On Options available: No Error, All Error. Default setting is No Error. BIOS Setup - 71 -...

  • Page 69: Kmip Server Configuration

    5-2-8 KMIP Server Configuration Parameter Description KMIP Server Configuration KMIP Server IP address KMIP TCP Port Number Enter the correct timem zone for this server. Time Zone Default setting is GMT+8. Use User and password credentials to authenticate the Client. Client Credentials Options available: Enabled, Disabled, Clear.

  • Page 70: Kms Policy Configuration

    5-2-9 KMS Policy Configuration Parameter Description Options available: KMS with KMIP, Disabled. KMS Option Default setting is KMS with KMIP. KMS KMIP Server Retry Count Define KMS KMIP Server Retry Count. BIOS Setup - 73 -...

  • Page 71: Nvme Configuration

    5-2-10 NVMe Configuration Parameter Description NVMe Configuration Displays the NVMe devices connected to the system. BIOS Setup - 74 -...

  • Page 72: Chipset Configuration

    5-2-11 Chipset Configuration Parameter Description Defines the power state to resume to after a system shutdown that is due to an interruption in AC power. When set to Last State, the system will return to the active power state prior to shutdown. When set to Restore on AC Power Loss (Note1) Power Off, the system remains off after power shutdown.
  • Page 73 Parameter Description Enable/Disable the chassis intrusion alert function. Chassis Opened Warning (Note2) Options available: Enabled, Disabled, Clear. Default setting is Disabled. Enable/Disable the chassis intrusion alert function. Power Button 1s Shutdown Options available: Enabled, Disabled, Clear. Default setting is Disabled. (Note2) Functions available on selected models.

  • Page 74: Tls Auth Configuration

    5-2-12 Tls Auth Configuration Parameter Description Press [Enter] for configuration of advanced items. Enroll Cert Š – Press [Enter] to enroll a certificate • Enroll Cert Using File • Cert GUID Server CA Configuration Input digit character in 1111111-2222-3333-4444-1234567890ab format. –...

  • Page 75: Iscsi Configuration

    5-2-13 iSCSI Configuration Parameter Description Press [Enter] configure advanced items. Attempt Priority Š Attempt Priority – Use arrow keys to select the attempt, then press +/- keys to move the attempt up/down in the attempt order list. Commit Changes and Exit Š...
  • Page 76 5-2-14 Intel(R) Ethernet Controller X710 for 10GBASE-T BIOS Setup - 79 -...
  • Page 77 Description Parameter Press [Enter] to view device firmware version information Firmware Image Properties Press [Enter] to configure advanced items. Link Speed Š – Allows for automatic link speed adjustment. – Options available: Auto Negotiated, 100 Mbps Half, 100 Mbps Full, 1000 Mbps Half, 1000 Mbps Full.
  • Page 78 Description Parameter Displays the technical specifications for the Network Interface Controller. Device Name Displays the technical specifications for the Network Interface Controller. Chip Type Displays the technical specifications for the Network Interface Controller. PCI Device ID Displays the technical specifications for the Network Interface Controller. PCI Address Displays the technical specifications for the Network Interface Controller.

  • Page 79: Vlan Configuration

    5-2-15 VLAN Configuration Parameter Description Press [Enter] to configure advanced items. Create new VLAN Š VLAN ID Š – Sets VLAN ID for a new VLAN or an existing VLAN. – Press the <+> / <-> keys to increase or decrease the desired values. –...

  • Page 80: Mac Ipv6 Network Configuration

    5-2-16 MAC IPv6 Network Configuration Parameter Description Press [Enter] to configure advanced items. Displays the MAC Address information. Š Interface ID Š – The 64 bit alternative interface ID for the device. The string is colon separated. e.g. ff:dd:88:66:cc:1:2:3. DAD Transmit Count Š...

  • Page 81: Mac Ipv4 Network Configuration

    5-2-17 MAC IPv4 Network Configuration Parameter Description Indicates whether network address is configured successfully or not. Configured Options available: Enabled, Disabled. Default setting is Disabled. Options available: Enabled, Disabled. Default setting is Disabled. Enable DHCP Local IP Address Press [Enter] to configure local IP address. Press [Enter] to configure local NetMask.

  • Page 82: Driver Health

    5-2-18 Driver Health Parameter Description Driver Health Displays driver health status of the devices/controllers if installed BIOS Setup - 85 -...

  • Page 83: Chipset Menu

    Chipset Menu Chipset Setup menu displays submenu options for configuring the function of Platform Controller Hub(PCH). Select a submenu item, then press <Enter> to access the related submenu screen. BIOS Setup - 86 -...

  • Page 84: Processor Configuration

    5-3-1 Processor Configuration BIOS Setup - 87 -...
  • Page 85 Description Parameter Processor Configuration Press [Enter] to configure advanced items. CPU Socket 0/1 Configuration Š – Core Disable Bitmap(Hex) • Number of Cores to enable. 0 means all cores. FFFFFFF Pre-Socket Configuration means to disable all cores. The maximum value depends on the number of CPUs available.
  • Page 86 Description Parameter Enable/Disable memory encryption (TME). Memory Encryption (TME) (Note) Options available: Enabled, Disabled. Default setting is Disabled. Total Memory Encryption Options available: Enabled, Disabled. Default setting is Disabled. Multi-Tenant (TME-MT) Press [Enter] to configure advanced items. Provision S3M CFR Š...

  • Page 87: Common Refcode Configuration

    5-3-2 Common RefCode Configuration Parameter Description Common RefCode Configuration Enable or disable Non uniform Memory Address (NUMA). Numa Options available: Enable, Disable. Default setting is Enable. Divide physical NUMA nodes into evenly sized virtual NUMA nodes in ACPI table. This may improve Windows performance on CPUs Virtual Numa with more than 64 logical processors.

  • Page 88: Upi Configuration

    5-3-3 UPI Configuration Description Parameter Press [Enter] to configure advanced items. UPI Status Š – Press [Enter] to view the Uncore status. Link Frequency Select Š – Selects the UPI link frequency. – Options available: 12.8GT/s, 14.4GT/s, 16.0GT/s, Auto, Use Per Link Setting.
  • Page 89 Description Parameter MMIO High Base Š – Options available: 56T, 40T, 32T, 24T, 16T, 4T, 2T, 1T, 512G, 3584T. Default setting is 32T. MMIO High Granularity Size Š UPI General Configuration – Selects the allocation size used to assign mmioh resources. (continued) –...

  • Page 90: Memory Configuration

    5-3-4 Memory Configuration Description Parameter Integrated Memory Controller (iMC) When set to Enable, the system enforces Plan Of Record restrictions for DDR frequency programming. Enforce DDR Memory Frequency POR Options available: POR, Disable. Default setting is POR. Configures the maximum memory frequency. If Enforce POR is disabled, user will be able to run at higher frequencies than the Memory Frequency memory support (limited by processor support).
  • Page 91 Description Parameter Enable/Disable Assert ADR on S5. Assert ADR on S5 Options available: Enabled, Disabled. Default setting is Disabled. Auto is the detected SPD value and use it, otherwise use BIOS Build-in. Get Memory Timing Options available: Auto, BIOS Build-in. Default setting is BIOS Build-in. Enable or disable CXL type 3 device using CXL type 2 flow.
  • Page 92 Description Parameter Leaky bucket time window based interface (Note) Š – Enable/Disable leaky bucket time window based interface. – Options available: Disabled, Enabled. Default setting is Disabled. Leaky bucket time window based interface Hour Š – Leaky bucket time window based interface hour used for DDR (0-24).

  • Page 93: Iio Configuration

    5-3-5 IIO Configuration Description Parameter IIO Configuration Press [Enter] to configure advanced items. ® Intel VT for Directed I/O Š – Enable/Disable the Intel VT for Directed I/O (VT-d) support function by reporting the I/O device assignment to VMM through DMAR ACPI Tables.
  • Page 94 Description Parameter Interrupt Remapping Š – Enable/Disable the interrupt remapping support function. – Options available: Auto, Enable, Disable. Default setting is Auto ® Intel VT for Directed I/O (VT-d) x2APIC Opt Out Š (continued) – Options available: Enable, Disable. Default setting is Disable. Pre-boot DMA Protection Š...

  • Page 95: Advanced Power Management Configuration

    5-3-6 Advanced Power Management Configuration Description Parameter Press [Enter] to configure advanced items. Activate SST-BF Š – Options available: Enable, Disable. Default setting is Disable. Configure SST-BF Š – This option allows BIOS to configure SST-BF High Priority Cores so that SW does not have to configure –...
  • Page 96 Description Parameter Press [Enter] to configure advanced items. Hardware P-States Š – When this item is disabled, the processor hardware chooses a P-state based on OS Request (Legacy P-States). – In Native mode, the processor hardware chooses a P-state based Hardware PM State Control on OS guidance.
  • Page 97 Description Parameter Press [Enter] to configure advanced items. PL1 Power Limit Š – Press the <+> / <-> keys to increase or decrease the desired values. PL1 Timer Window Š – Configure PL1 Timer Window. SOCKET RAPL Config PL2 Power Limit Š...

  • Page 98: Pch Configuration

    5-3-7 PCH Configuration Description Parameter PCH-IO Configuration Press [Enter] to configure advanced items. SATA Configuration Š – Enable/Disable SATA controller. – Options available: Enabled, Disabled. Default setting is Enabled. SATA Mode Selection Š – Configures on chip SATA type. – AHCI Mode: When set to AHCI, the SATA controller enables its AHCI functionality.
  • Page 99 Description Parameter Port 0/1/2/3/4/5/6/7 Š – Enable/Disable Port 0/1/2/3/4/5/6/7 device. – Options available: Enabled, Disabled. Default setting is Enabled. Hot Plug (for Port 0/1/2/3/4/5/6/7) Š – Enable/Disable HDD Hot-Plug function. SATA And RST – Options available: Enabled, Disabled. Default setting is Enabled. Configuration (continued) Spin Up Device (for Port 0/1/2/3/4/5/6/7) Š...

  • Page 100: Miscellaneous Configuration

    5-3-8 Miscellaneous Configuration Description Parameter Miscellaneous Configuration Selects the active video type. Options available: Auto, Onboard Device, PCIE Device, Specific PCIE Active Video Device. Default setting is Onboard Device. Enables Spread spectrum - only affects external clock generator. Options available: SSC Off, SSC = -0.3%, SSC = -0.5%, Hardware. External SSC - CK440 Default setting is SSC Off.

  • Page 101: Server Me Configuration

    5-3-9 Server ME Configuration Parameter Description General ME Configuration Oper. Firmware Version Displays the operational firmware version. ME Firmware Status #1/#2 Displays ME Firmware status information. Current State Displays ME Firmware current status information. Error Code Displays ME Firmware status error code. Recovery Cause Displays ME Firmware recovery cause.

  • Page 102: Runtime Error Logging Settings

    5-3-10 Runtime Error Logging Settings Description Parameter Runtime Error Logging Enable/Disable system error logging function. System Errors Options available: Enable, Disable. Default setting is Enable. Press [Enter] to configure advanced items. WHEA (Windows Hardware Error Architecture) Support Š Whea Settings –...
  • Page 103 Description Parameter Press [Enter] to configure advanced items. PCIE Error Š – Enable/Disable PCIE error. – Options available: Enable, Disable. Default setting is Disable. Uncorrected Error (Note) Š – Enables and escalates Uncorrectable/Recoverable Errors to error pins. – Options available: Enable, Disable. Default setting is Enable. Fatal Error Enable (Note) Š...

  • Page 104: Power Policy

    5-3-11 Power Policy Description Parameter Selects a Power Policy Quick Setting. Options available: Standard, Best Performance, Energy Efficient. Default Power Policy Quick Settings setting is Standard. Conventional Intel SpeedStep Technology switches both voltage and frequency in tandem between high and low levels in response to processor SpeedStep (Pstates) load.
  • Page 105 Description Parameter Enables Logical processor (Software Method to Enable/Disable Logical Processor threads). Enable LP [Global] Options available: ALL LPs, Single LP. Default setting is ALL LPs. Options available: Enable, Disable. Default setting is Enable. Hardware Prefetcher Options available: Enable, Disable. Default setting is Enable. Adjacent Cache Prefetch Options available: Enable, Disable.

  • Page 106: Server Management Menu

    Server Management Menu Parameter Description Enable/Disable FRB-2 timer (POST timer). FRB-2 Timer Options available: Enabled, Disabled. Default setting is Enabled. FRB-2 Timer Configures the FRB2 Timer timeout. The value is between 1 to 30 minutes. (Note1) timeout Default setting is 6 minutes. Configures the FRB2 Timer policy.
  • Page 107 Parameter Description System Event Log Press [Enter] to configure advanced items. View FRU Press [Enter] to view the FRU information. Information BMC VLAN Press [Enter] to configure advanced items. Configuration BMC network Press [Enter] to configure advanced items. Configuration IPv6 BMC Network Press [Enter] to configure advanced items.

  • Page 108: System Event Log

    5-4-1 System Event Log Parameter Description Enabling / Disabling Options Change this item to enable or disable all features of System Event SEL Components Logging during boot. Options available: Enabled, Disabled. Default setting is Enabled. Erasing Settings Choose options for erasing SEL. Options available: No, Erase SEL Yes, On next reset,...

  • Page 109: View Fru Information

    5-4-2 View FRU Information The FRU page is a simple display page for basic system ID information, as well as System product information. Items on this window are non-configurable. (Note) The model name will vary depends on the product you purchased BIOS Setup - 112 -...

  • Page 110: Bmc Vlan Configuration

    5-4-3 BMC VLAN Configuration Description Parameter BMC VLAN Configuration Select to configure BMC VLAN ID. The valid range is from 0 to 4094. When BMC VLAN ID set to 0, BMC VLAN ID will be disabled. Select to configure BMC VLAN Priority. The valid range is from 0 to 7. BMC VLAN Priority When BMC VLAN ID is set to 0, BMC VLAN Priority will not be selected.

  • Page 111: Bmc Network Configuration

    5-4-4 BMC Network Configuration Parameter Description BMC network configuration Select NCSI and Dedicated Options available: Do Nothing, Model1(Dedicated), Model2(NCSI), Mode3(Failover). Default setting is Do Nothing. Lan Channel 1 Selects to configure LAN channel parameters statically or dynamically (DHCP). Configuration Address source Options available: Unspecified, Static, DynamicBmcDhcp.

  • Page 112: Ipv6 Bmc Network Configuration

    5-4-5 IPv6 BMC Network Configuration Parameter Description IPv6 BMC network configuration IPv6 BMC Lan Channel 1 Enable/Disable IPv6 BMC LAN channel function. When this item is disabled, the system will not modify any BMC network during BIOS IPv6 BMC Lan Option phase.

  • Page 113: Security Menu

    Security Menu The Security menu allows you to safeguard and protect the system from unauthorized use by setting up access passwords. There are two types of passwords that you can set: • Administrator Password Entering this password will allow the user to access and change all settings in the Setup Utility. •...

  • Page 114: Secure Boot

    5-5-1 Secure Boot The Secure Boot feature is applicable if supported by your Operating System. If your Operating System is not supporting Secure Boot, the system will hang when starting the Operating System. Parameter Description System Mode Displays if the system is in User mode or Setup mode. Enable/ Disable the Secure Boot function.
  • Page 115 Parameter Description Press [Enter] to configure advanced items. Please note that this item is configurable when Secure Boot Mode is set to Custom. Factory Key Provision Š – Allows to provision factory default Secure Boot keys when system is in Setup Mode.
  • Page 116 Parameter Description Authorized TimeStamps (DBT) Š – Displays the current status of the Authorized TimeStamps Database. – Press [Enter] to configure a new DBT or load additional DBT from storage devices. Key Management – Options available: Update, Append. (continued) OsRecovery Signatures Š...

  • Page 117: Boot Menu

    Boot Menu The Boot menu allows you to set the drive priority during system boot-up. BIOS setup will display an error message if the legacy drive(s) specified is not bootable. BIOS Setup - 120 -...
  • Page 118 Parameter Description Boot Configuration Number of seconds to wait for setup activation key. 65535 (0xFFFF) Setup Prompt Timeout means indefinite waiting. Press the numeric keys to input the desired values. Enable/Disable the Bootup NumLock function. Bootup NumLock State Options available: On, Off. Default setting is On. Enable/Disable showing the logo during POST.

  • Page 119: Save & Exit Menu

    Save & Exit Menu The Save & Exit menu displays the various options to quit from the BIOS setup. Highlight any of the exit options then press <Enter>. Parameter Description Save Options Saves changes made and closes the BIOS setup. Save and Exit Options available: Yes, No.
  • Page 120 Parameter Description Loads the default settings for all BIOS setup parameters. Setup Defaults are quite demanding in terms of resources consumption. If you are using low-speed memory chips or other kinds of low-performance components Restore Defaults and you choose to load these settings, the system might not function properly.

  • Page 121: Bios Recovery

    BIOS Recovery The system has an embedded recovery technique. In the event that the BIOS becomes corrupt the boot block can be used to restore the BIOS to a working state. To restore your BIOS, please follow the instructions listed below: Recovery Instruction: 1.

This manual is also suitable for:

G893-sd1-aax5

Table of Contents
